Defi -Link Advance Operation Manual page 45

Caution
This product is designed for use on 12V vehicles. Do not install
this product on vehicles with 24V systems.
Insulate any unused wires. If any wires or connectors loosen during installa-
tion, please make sure they are correctly reattached.
Do not drop any of the components of this product. It may result in dam-
age to the product.
Do not apply excessive force on switches/terminals. It may result in dam-
age to the product.
Do not use wires other than the provided wires.
Do not attach wires on the body of the vehicle or engine parts as this may
result in damage to the product.
Install wires away from ignition and also radio signal frequency interference
as this could cause the gauges to malfunction.
Please set it up so that the equipment such as the wireless machines and
cellular phones that emit electric waves should not touch the unit. It may
result in incorrect operation.
Do not place wires near the engine, exhaust pipe or turbine. It may result in
damage or fusion of wires.
Make sure the waterproof processing is done when diverging wires in the
engine compartment.
Do not lay the gauge face down due to oil leakage.
Angle "A" must be more than 90 degrees.
When installing the sensor, do not bend the wire near the sensor body.
Wear gloves to avoid burns when soldering and cuts when installing wires,
sharp edges of parts.
Do not expose the unit to moisture, dust or direct sunlight, or place product
directly in front of heat vents.
Install sensors away from hot or wet places.
When using sunshade, put sunshade between products and windshield to
avoid direct sun exposure .
Use a dried soft cloth for cleanup. Do not use cleaners except neutral deter-
gent. It may damage the product.
44
24V
Over 90°
A
