- Page 1 USER MANUAL HoME MoNitoRiNg StARtER Kit DHM-901t VERSioN 1.0...
- Page 2 Preface D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Revision Date Description November 15, 2010 DHM-901T Revision A1 with firmware version 1.00...
-
Page 3: Table Of Contents
Hardware Overview: Motion Sensor ...... 11 Hardware Installation: Gateway ......12 Hardware Installation: Keypad ....... 13 Hardware Installation: Contact Sensor ....14 Hardware Installation: Motion Sensor ....15 Appendix A - technical Specifications ....16 Technical Specifications ........16 D-Link DHM-901T User Manual... -
Page 4: Product Overview
ƒ DHM-401T Gateway ƒ DHM-301T Keypad ƒ DHM-303T Contact Sensor ƒ DHM-304T Motion Sensor ƒ Stand for DHM-401T ƒ Power adapter for DHM-401T ƒ Bracket for DHM-304T ƒ Batteries for DHM-301T/303T/304T ƒ Mounting kits for DHM-301T/303T/304T ƒ Ethernet cable ƒ Quick Installation Guide If any of the above items are missing, please contact your reseller. -
Page 5: System Requirements
Product Overview System Requirements ƒ A computer with Windows XP SP2/Vista/7 or higher for configuration D-Link DHM-901T User Manual... -
Page 6: Features
The two USB ports allow you to expand your home monitoring system by adding adapters such as a DWM-156 3G dongle for a 3G fallback Internet connection, or a DHM-101 Z-Wave USB Dongle to allow for connection to Z-Wave devices. D-Link DHM-901T User Manual... -
Page 7: Hardware Overview: Gateway (Front)
Product Overview Hardware overview: gateway (Front) LEDs - Status - Alarm - Online - Event D-Link DHM-901T User Manual... -
Page 8: Hardware Overview: Gateway (Back)
Hardware overview: gateway (Back) LAN Port Connects to your router. USB Ports Connect to compatible USB devices, such as the DHM-101 Z-Wave USB Dongle. Learn/Reset Button Turns on pairing mode. Power Connector Connects to the included power adapter. D-Link DHM-901T User Manual... -
Page 9: Hardware Overview: Keypad
Product Overview Hardware overview: Keypad LEDs - Active/Operation Status Button - Status - Alarm/Error Armed Home Button Armed Away Button Help Button Clear Events Button D-Link DHM-901T User Manual... -
Page 10: Hardware Overview: Contact Sensor
Product Overview Hardware overview: Contact Sensor Pairing Button and LED Contact Sensor Piece D-Link DHM-901T User Manual... -
Page 11: Hardware Overview: Motion Sensor
Product Overview Hardware overview: Motion Sensor Pairing Button and LED D-Link DHM-901T User Manual... -
Page 12: Hardware Installation: Gateway
Connect the DHM-401t gateway ƒ Connect one end of the included Ethernet cable to an available LAN port on your router, and connect the other end to the WAN port on the DHM-401T. ƒ Connect the power adapter to the DHM-401T. -
Page 13: Hardware Installation: Keypad
Mounting the DHM-301t Keypad (optional) ƒ You can hang the keypad 2 different ways. ƒ You can push in and slide the D-Link logo up to uncover 2 screw holes you can use to mount the keypad to a wall using the included screws. -
Page 14: Hardware Installation: Contact Sensor
ƒ Replace the top cover of the contact sensor and make sure the two halves snap together. Pairing the DHM-303t Contact Sensor ƒ Press and hold the pairing button on the DHM-401T Gateway until you hear a beep and the Online Status LED flashes green. You now have 60 seconds to pair sensors to the gateway. -
Page 15: Hardware Installation: Motion Sensor
ƒ Replace the battery cover. Pairing the DHM-304t Motion Sensor ƒ Press and hold the pairing button on the DHM-401T Gateway until you hear a beep and the Online Status LED flashes green. You now have 60 seconds to pair sensors to the gateway. -
Page 16: Appendix A - Technical Specifications
ƒ Detection Angle: 90 degrees ƒ Transmission Range: Minimum 70 metres in free space ƒ Power: 2 x AAA batteries ƒ Battery Life: 1 year with alkaline batteries ƒ LED: Pairing/Status ƒ Dimensions: 83 x 58 x 40.5 mm D-Link DHM-901T User Manual... - Page 17 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
