Product Overview
inserting batteries into your DHM-301t Keypad
ƒ Slide and remove the battery cover on the back of the keypad, then insert 2 AAA batteries as indicated.
ƒ Replace the battery cover.
Pairing the DHM-301t Keypad
ƒ Press and hold the pairing button on the DHM-401T Gateway until you hear a beep and the Online Status LED
flashes green. You now have 60 seconds to pair sensors to the gateway.
ƒ Press and hold the 1 and 2 buttons on the DHM-301T Keypad at the same time.
ƒ When the 2 devices have successfully paired, the DHM-401T gateway will beep 2 times, and the DHM-301T Key-
pad will beep 4 times.
Mounting the DHM-301t Keypad (optional)
ƒ You can hang the keypad 2 different ways.
ƒ You can push in and slide the D-Link logo up to uncover 2 screw holes you can use to mount the keypad to a wall
using the included screws.
ƒ Alternatively, you can insert the included screws into a wall, then use the mounting holes on the back of the key-
pad to hang it on the screws.
