Sentera Controls RSTHM-2 Mounting And Operating Instructions

Combined t and rh room transmitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RSTHM-2
COMBINED T AND RH
ROOM TRANSMITTER
Mounting and operating instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RSTHM-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Sentera Controls RSTHM-2

Summary of Contents for Sentera Controls RSTHM-2

  • Page 1 RSTHM-2 COMBINED T AND RH ROOM TRANSMITTER Mounting and operating instructions...

  • Page 2: Table Of Contents

    INTENDED AREA OF USE TECHNICAL DATA STANDARDS OPERATIONAL DIAGRAMS MOUNTING & OPERATING INSTRUCTIONS IN STEPS OPERATING INSTRUCTIONS VERIFICATION OF INSTALLATION INSTRUCTIONS MODBUS REGISTER MAPS TRANSPORT AND STORAGE WARRANTY AND RESTRICTIONS MAINTENANCE MIW-RSTHM-2-EN-000 - 15 / 01 / 2019 2 - 10 www.sentera.eu...

  • Page 3: Safety And Precautions

    In case there are any questions that are not answered, please contact your technical support or consult a professional. MIW-RSTHM-2-EN-000 - 15 / 01 / 2019 3 - 10 www.sentera.eu...

  • Page 4: Product Description

    Protection standard: IP30 (according to EN 60529) ■ Operating ambient conditions: ► temperature: 0—50 °C ► rel. humidity: 5—85 % rH, (non-condensing) ■ Storage temperature: -10—60 °C MIW-RSTHM-2-EN-000 - 15 / 01 / 2019 4 - 10 www.sentera.eu back to the table of contents...

  • Page 5: Standards

    LED indications refer to T (default) or rH, depending on the selected parameter MOUNTING & OPERATING INSTRUCTIONS IN STEPS Before you start mounting the RSTHM-2 room transmitter, read carefully “Safety and Precautions”. Choose a smooth surface for installation (a wall, panel and etc.).
  • Page 6 8 mm 24 VDC 8 mm RJ45 8 mm 8 mm Put back the cover and snap it in. Switch on the mains supply. MIW-RSTHM-2-EN-000 - 15 / 01 / 2019 6 - 10 www.sentera.eu back to the table of contents...

  • Page 7: Operating Instructions

    When the red LED is on, the measured value (temperature or relative humidity) is below the minimum measurement range value or above the maximum value. Blinking red LED indicates loss of communication with a sensor (Fig 6 - 3). MIW-RSTHM-2-EN-000 - 15 / 01 / 2019 7 - 10 www.sentera.eu...

  • Page 8: Verification Of Installation Instructions

    After switching on the power supply one of the LEDs light up according to the status of the measured variable. If this is not the case, check the connections. MIW-RSTHM-2-EN-000 - 15 / 01 / 2019 8 - 10 www.sentera.eu...
  • Page 9 (Min. range + 50) – 500 500 = 50,0 °C range temperature rang e plus 5ºC MIW-RSTHM-2-EN-000 - 15 / 01 / 2019 9 - 10 www.sentera.eu back to the table of contents...

  • Page 10: Transport And Storage

    In case of heavy pollution, clean with a non-aggressive product. In these circumstances the unit should be disconnected from the supply. Pay attention that no fluids enter the unit. Only reconnect it to the supply when it is completely dry. MIW-RSTHM-2-EN-000 - 15 / 01 / 2019 10 - 10 www.sentera.eu...
