Installation Guide

STEP 1
.
For safety reasons, the following should be performed by 2 people.
Carefully lift the bed frame unit out of the shipping carton with the
top side facing downward.
ssembling Bed Legs
STEP 2.
For this step, you will need: 4 bed legs (C and M), Knob bolts (N),
and spring washers (O), which can be found in the ccessories box.
First turn the two (C) bed legs in a clockwise direction into the holes
in the frame as shown above. Next thread each Lounger bed leg (M)
into the C-channel frame. Make sure the leg opening is facing inside
the frame. Then, insert a Knob bolt (N) fitted with a spring washer
(O) into the predrilled hole in the C-channel frame and through the
lounger bed leg. Tighten the Knob bolt in place. Repeat with the
remaining Lounger bed leg.
DO NOT OVERTIGHTEN THE BED LEGS.
NOTE :
Bed may be equipped with special locking
casters. To prevent movement of this product, all four
casters should be in the locked position. It is recom-
mended that rubber caster cups or carpet squares (not
included) are placed under casters in addition to locking
them inplace. Casters will not roll when locked, but may
slide on an uncarpeted surface.
STEP 3
.
Remove and extend the power cord from the frame.
Important!
M KE SURE POWER CORDS DO NOT OBSTRUCT
NY DJUST BLE BED MECH NISMS.
STEP 4
.
Take plastic wrapping off the base frame.
The "MULTI-FLEX"
Wireless djustable Bed
STEP 5
.
Carefully rotate the base frame over so the top side is facing upward.
Be careful not to rest the frame on its side. The weight may damage
the legs.
STEP 6
.
Plug the power cord into a grounded electrical outlet.
NOTE :
For optimal safety, a surge protector should be
used (not supplied with this djustable Bed).
STEP 7
.
Install batteries in remote.
If the remote is a wired remote, no batteries are needed.
Try all functions on the hand control to
ensure all features are operational.
If the bed does not work, refer to Troubleshooting on p.14.
STEP 8
.
Return bed to flat or level position.
ssembling
STEP 9.
The Mattress Retainer Bracket
Fasten the mattress retainer bracket (B) to the front of the bed frame
using the retainer bolts (F) and 1/4 inch Retainer washers (H), as
shown in the diagram below.
NOTE :
Use ONLY the allen wrench to fasten the retainer
bolts. DO NOT use a power screwdriver as it may over tighten the
bolts. Mattress retainer hardware must NOT be over tightened.
If the adjustable frame is to be set up without a headboard,
simply install a mattress on the frame.Installation is now complete.
If a headboard is to be installed, proceed to step 10 on next page.
