Rize Extreme M33G Assembly Instructions

Extreme Bed Frame Assembly Instructions
Use with models:M33G, M33R, M46G, M46R, M50G, M50R, M66G, M66R, M60G, M60R

Parts included:

All frames include:
(2) Side Rails
(2) Cross Rails
(2) Center Rails (None with Twin)
(2) End Caps
1
Set side rails out with the headboard brackets on the
same end. Take the cross rail and insert one end into the
slot at the top of the leg attached to the right side rail.
Make sure the leg in the middle of the cross rail is facing
towards the inside of the frame.
2
With one hand, hold the side rail so that the attached leg is vertical
and the hook on the cross rail directly aligns to the slot on the
side rail. Then, with the other hand, push straight down on the
cross rail until it clicks into the plastic locking cap. Repeat with the
other side, and with the other cross rail at the foot of the frame.
3
Install the sockets on the legs, including on the center rail. Then
insert the glide OR roller into the sockets on all legs.
Socket
Roller
5
For all sizes except Twin, the center rails will be attached
last. After any headboard or footboard has been attached
to the frame (using hardware included with the headboard/
footboard), insert the ends of the first center rail into the
slots in the legs at the middle of the cross rails. Press down.
The rails will not lock. Then, do the same with the other
center rail. The two center rails should be back to back.
Foot parts for M33G
(4) Plastic Sockets
(4) Glides
Foot parts for M33R
(4) Plastic Sockets
(4) Rollers
Leg
www.rizebeds.com | 1-844-545-8865 | orders@rizebeds.com
Foot parts for M46G, M50G, M66G, M60G
(6) Plastic Sockets
(6) Glides
Foot parts for M46R, M50R, M66R, M60R
(6) Plastic Sockets
(6) Rollers
Cross Rail
4
Slip the end caps over the foot ends of the side rails
(opposite the headboard brackets).
Glide

To Disassemble the Bed Frame:

• Lift out the center rails.
• Locate the plastic locking cap that connects the
cross rails to the side rails.
• Pull outward and up on the bottom of the plastic
locking cap, and lift out the cross rail. Repeat on
all rails.
3
Side Rail
Copyright Rize 11/1/2019
