Installation Guide
Make sure to position the bottom of the headboard cross member no more than
3 inches (76.2 mm) between the headboard and the top of the mattress.
ssemble the Headboard Bracket
STEP 10.
i.
Use the remote to elevate the head of the bed so
the bed base frame is reachable.
ii.
Slide the inner headboard bracket (D) into the C-channel
frame. (The bracket opening and the C-channel opening should
face each other to create a box shape.) Insert a retainer bolt (G)
fitted with a 5/16 inch washer (I) into one of the predrilled holes
in the C-channel frame and through the inner headboard
bracket. Tighten in place with a 5/16 inch washer (I) and 5/16
inch nut (J). Repeat on the other side.
iii.
Place the open side of the outer headboard bracket (E) onto
the exposed square tube of the inner headboard bracket (D) to
create a tight fit between (D) and (E). Insert a retainer bolt (G)
fitted with a 5/16 inch washer (I) into the outer headboard
bracket (E) and through the inner headboard bracket (D). Hand
tighten using a 5/16 inch washer (I) and a 5/16 inch nut (J).
(Leave loose enough for adjusting.) Repeat on
the other side.
iv.
When headboard brackets are assembled, make sure there is a space of 1.5 (38.1 mm) to 2 inches (50.8 mm)
between the edge of the bed base and the headboard brackets.
v.
Securely fasten the headboard bolts (not included with your adjustable bed) to the end of the headboard bracket assembly.
vi.
Measure the distance from the center of one mounting hole in the headboard to the center of the other.
vii.
Measure the distance from the center of one mounting hole in the headboard bracket assembly to the center of the other.
viii.
If you need to adjust the headboard brackets, unscrew the bolts holding the outer headboard brackets and move them
the necessary distance. Reinstall the bolts and securely tighten.
STEP 11.
Place your mattress on the adjustable bed frame surface. Your adjustable bed and headboard installation is now complete.
If the bed comes with a programming option, turn to the Wireless Hand Control Operation Guide to proceed.
IMPORT NT NOTES:
Failure to follow the installation steps as they appear in this guide
could result in damage to your adjustable bed frame.
The "MULTI-FLEX"
Wireless djustable Bed
