IN1808 • Setup Guide (Continued)
Mounting and Cabling
Step 1 — Mount the device
a. Turn off or disconnect all equipment power sources.
b. Mount the IN1808 to a rack using the pre-installed side mounting brackets, or remove the brackets and use an optional
19-inch rack under-desk mounting kit (see the mounting instructions provided with the kit, available at www.extron.com).
The IN1808 base model has a 1U high, full rack wide enclosure. The IN1808 IPCP models have 2U, full rack enclosures.
Step 2 — Connect inputs
Make the following input connections as needed:
•
Connect a DP source to the Input 1 DisplayPort connector (see
•
Connect HDMI or DVI (with an appropriate adapter) sources to HDMI input connectors 2 through 6 (
•
Connect DTP transmitters to the DTP2/XTP RJ-45 input connectors 7 and 8 (
powering of DTP transmitters. You can configure the TP inputs for XTP mode via SIS commands, the on-screen
display (OSD), or PCS (see the IN1808 Series Help File). For cable wiring and recommendations, see
Recommendations for DTP, XTP, and HDBaseT Communication
•
Connect analog audio sources to:
•
The 5-pole captive screw line audio input connectors 3 and 4 (
unbalanced stereo audio. The Aux Line input is shared and can be associated with one or more video inputs.
•
Connect balanced or unbalanced mic or line level inputs to 3-pole Mic/Line captive screw connectors 1 and 2 (
These inputs support optional +48 VDC phantom power, which is indicated by the LEDs at the left of the connectors.
Step 3 — Connect outputs
Make the following output connections as needed:
•
Connect an HDMI, or DVI with an appropriate adapter, display to HDMI/CEC output connector 1A (
•
Connect a DTP/XTP matrix switcher/HDBaseT compatible receiver to output connector 1B (
recommendations, see
•
To pass infrared data, connect a control device to the 3-pole IR Over DTP captive screw connector (see
on the next page). Alternatively, insert RS-232 communication to a DTP/HDBaseT endpoint via Ethernet (see the IN1808
Series User Guide for more information).
•
Connect balanced or unbalanced analog audio output devices to one or both 5-pole captive screw output connector pairs
J
1 and 2 or 3 and 4 (
•
For IPCP models, connect speakers to the amplifier module via the 5 mm 4-pole stereo (IN1808 IPCP SA) or 2-pole mono
(IN1808 IPCP MA 70) Amplified Output connector (
Step 4 — Connect control devices
•
To control the base model through Ethernet, connect a LAN or WAN to the LAN connector (
to the cable, see Twisted Pair Recommendations for DTP, XTP, and HDBaseT
For the IPCP models, connect a LAN or WAN to any of the AV LAN connectors on the IPCP Pro control processor (
default IP address of the scaler is 192.168.254.254. The default subnet mask is 255.255.255.0. The default gateway address
is 0.0.0.0.
•
For serial RS-232 control, connect a host device to the 3-pole captive screw connector (
•
For control through USB, connect a host device to the front panel USB mini-B port (see
Step 5 — Set up the IPCP Pro 355M control processor (IPCP models only)
The Extron IPCP Pro 355M control processor (see
such as projectors and lights. See the IPCP Pro Series Setup Guide, available at www.extron.com, for installation details.
Step 6 — Connect power
Connect a 100 to 240 VAC, 50-60 Hz power source to the AC power connector (
2
Twisted Pair Recommendations for DTP, XTP, and HDBaseT
). See Audio Wiring on the next page for more information.
N
figure
B
figure 1, , on the previous page).
D ). These connectors allow for remote
on the next page.
H
) and the Aux connector (
).
Communication.
1, P
) provides monitoring and control of a variety of external devices,
A
).
Q ).
Twisted Pair
O
) for balanced or
I
E
).
F ). For cable wiring and
Communication.
IR Over TP Wiring
R ). To wire the RJ-45 connector
P
K
). The default baud rate is 9600.
figure 2, H
on page 4).
).
). The
