  • Page 1 Operating manual Wärtsilä JOVYSTAR COMPACT S 30/40/50 kVA BAX 5452...
  • Page 2 Index Date Name Alternation note 2015-11-11 D. Busboom First edition 2016-01-28 D. Busboom 16/047 2016-11-02 D. Busboom 16/494 2016-11-30 D. Busboom 16/539 2017-01-10 D. Busboom 17/008 2017-01-24 D. Busboom 17/037 2017-06-26 D. Busboom 17/196...

  • Page 3: Table Of Contents

    Contents Introduction General instructions Overview of warning information Description of the System Functional description 2.1.1 Rectifier 2.1.2 Inverter 2.1.3 Battery 2.1.4 Static bypass 2.1.5 Internal, manual bypass Operating states 2.2.1 Normal operation 2.2.2 Inverter fault 2.2.3 Rectifier fault 2.2.4 Mains failure 2.2.5 Manual bypass Installation...
  • Page 4 5.1.1 Problems during commissioning Decommissioning Commissioning from the internal, manual bypass Decommissioning in the internal manual bypass Servicing Maintenance 6.1.1 Visual inspection 6.1.2 Functional test 6.1.3 Battery inspection Repairs 6.2.1 Spare parts list Dismantling and cleaning up Appendix Technical data Other technical documents...

  • Page 5: Introduction

    1 Introduction Congratulations on purchasing a UPS unit from our JOVYSTAR series. The static UPS you have chosen incorporates the latest state of technology in power electronics and digital signal processing. It provides an ideal solution to the problems of supplying power to electronic data processing systems. Our JOVYSTAR UPS systems are true online systems that protect your consumers.

  • Page 6: Overview Of Warning Information

    Overview of warning information Proper operation and maintenance as well as adherence to the safety requirements are required to protect personnel and to ensure continuous readiness for use. All personnel installing/dismantling, commissioning, operating and maintaining this equipment must be familiar with and observe these safety regulations. Only trained and qualified personnel may carry out the described work and they must use the proper, intact tools, equipment, test equipment and materials.

  • Page 7: Description Of The System

    2 Description of the System Ensuring a reliable power supply is one of many major issues when using electronic data processing and process control systems. The main causes of many interruptions to power supply are: Spikes produced by switching devices on the mains distribution ...

  • Page 8: Functional Description

    Functional description The block diagram shows the functional design of a JOVYSTAR UPS. It comprises the component groups "rectifier", "battery", "inverter", "static switch". The "RCB", "SBCB", "MBCB", "BCB" and "OCB" switches are used to start and shut down the UPS as well as to switch over to the bypass. Additionally, for maintenance purposes the battery can be disconnected from the UPS.

  • Page 9: Operating States

    Operating states 2.2.1 Normal operation Normal operation is divided into two further operating modes. For sensitive loads, online operation via the inverter provides a stable AC voltage. For loads that are less susceptible to mains fluctuations, eco mode offers a better efficiency rating.

  • Page 10: Inverter Fault

    2.2.2 Inverter fault The mains feeds the rectifier.  The rectifier provides the DC voltage for the inverter and charges the batteries.  The load at the output is transferred to the bypass without interruption via the static switch.  Inverter fault: load supplied via the bypass 2.2.3 Rectifier fault...

  • Page 11: Mains Failure

    2.2.4 Mains failure The battery provides the DC voltage for the inverter (for the duration of the stored energy time).  The inverter supplies the load at the output with the necessary energy via the static switch.  If there is any threat of a deep battery discharge, the system automatically shuts down completely and ...

  • Page 12: Installation

    3 Installation Remove the packaging immediately after receiving the UPS and check the system for transport damages. The transport company must be informed immediately after receipt of the UPS in the event of any damage caused during transportation. If the UPS is not installed immediately it must be stored in an upright position as indicated on
the packaging and kept in a dry, well ventilated room.

  • Page 13: Positioning And Installation

    Positioning and Installation The UPS must be installed indoor, in a clean and dry room, preferably without dust or humidity infiltrations. For the environmental conditions in the place of installation, in compliance with the current legislation, please refer to the “Overall dimensions, minimum distances from the walls and ventilation” section. Special environmental conditions It is necessary to implement specific protective measures in case of unusual environmental conditions:...

  • Page 14: Overall Dimensions, Clearances And Ventilation

    3.2.2 Overall Dimensions, Clearances and Ventilation Leistung (kVA) L – mm D – mm H – mm 1505 Wärtsilä JOVYSTAR COMPACT S BAX 5452 14 -...
  • Page 15 The UPS must be so installed as to ensure its serviceability and to allow a correct air flow as much as possible. With regard to the minimum distances from the walls, for all of the UPS sizes the same installation conditions apply as indicated in the table below.

  • Page 16: Environmental Installation Conditions

    3.2.3 Environmental Installation Conditions The air is classified by the EN 60721-3-3 standard (Classification of environmental parameters and their severities – Stationary use at weather-protected locations) based on climatic and biological conditions as well as on mechanically and chemically active substances. Therefore the place of installation must meet specific requirements to ensure compliance with the conditions for which the UPS was designed.

  • Page 17: Electrical Connections, Cross Sections, Fuses

    Electrical connections, cross sections, fuses The electrical connection of the UPS unit is the task of the electrician providing the electrical installation services. This task is not carried out by the UPS manufacturer. For this reason, the following recommendations are only an indication, as the UPS manufacturer is
not responsible for the electrical installation.

  • Page 18: Connections To The Ups

    3.3.2 Connections to the UPS Bolt M6 8,3 - 11,1Nm PE BOLT M8, 9 Nm Max. 4mm² 0,5 - 0,8Nm Max. 25mm² Max. 25mm² Max. 35mm² 4 - 4,5Nm 4 - 4,5Nm 2,8 - 3Nm 30/40kVA Bolt M6 8,3 - 11,1Nm PE BOLT M8, 9 Nm Max.

  • Page 19: Ups-Options (Optional Equipment)

    3.3.3 UPS-Options (Optional equipment) Following UPS-Options are described in the operating manual BAX 4834: Relay card   SNMP adapter PROFIBUS  MODBUS   Battery symmetry supervision Parallel redundant systems  Wärtsilä JOVYSTAR COMPACT S BAX 5452 19 -...

  • Page 20: Mounting And Connecting The Battery

    3.3.4 Mounting and connecting the battery 3.3.4.1 Battery 7/9/11Ah 12V installation 1) Remove the 4 screws to open the left/right lateral cover and access the battery trays (total trays are 4 and each contain three rows of 10 batteries, see picture). Trays 7/9/11Ah 12V battery lateral view One raw 7/9/11Ah 12V battery top view Wärtsilä...
  • Page 21 2) Install the batteries received in a separate packages and install it in accordance with the picture 11 and picture 7/9/11Ah 12V battery connection tray top view 7/9/11Ah 12V battery connection tray front view 3) After the connection re-insert the battery trays on the internal of UPS. 4) Put back and fix the left/right cover with the four screws.
  • Page 22 Wärtsilä JOVYSTAR COMPACT S BAX 5452 22 -...

  • Page 23: Operation

    4 Operation Front Panel The front panel of the UPS, consisting of four rows alphanumeric display plus 5 function keys, allows the complete monitoring of the UPS status. The mimic flow helps to understand the operating status of the UPS. UPS front panel Wärtsilä...

  • Page 24: Function Buttons

    4.1.1 Function Buttons The front panel of the UPS is provided with 5 buttons whose functions are indicated in the following table: Button Assigned functions  Scrolls up the menus  Increases the values by one unit  Selects a value ...

  • Page 25: Mimic Panel / Led

    4.1.2 Mimic Panel / LED UPS mimic panel AC line on rectifier input within tolerance GREEN LED 1 AC mains failure / Wrong phase rotation GREEN AC bypass line within tolerance GREEN LED 2 Wrong phase rotation GREEN AC bypass line out of tolerance / failure Rectifier off or faulty GREEN LED 3...

  • Page 26: Led-Bar

    4.1.3 LED-Bar LED bar AC line on rectifier input within tolerance GREEN Wrong phase rotation (fast blinking) GREEN LED 11 Unbalanced AC voltage (slow blinking) GREEN AC mains failure Circuit breaker BCB closed and battery charging GREEN Battery discharging or under TEST (fast blinking) ORANGE LED 12 Circuit breaker BCB open (slow blinking)

  • Page 27: Menu Structure

    Menu structure The following figure shows the complete structure in a clear format. The main menu is divided into four areas: "Measures", "Alarms", "Special" and "Info" This means the required information/reports and measures can be displayed quickly and various settings made. Details of the options available are given in the sections below. JOVYSTAR MEASURES ALARMS...

  • Page 28: Measures

    4.2.1 Measures The measured data of the UPS are saved in the main menu under “Measures”. It can be displayed the input, output and bypass values, as well as data about the assemblies rectifier, inverter and battery. Main menu Sub menu Display „UPS-NAME“...
  • Page 29 Main menu Sub menu Display OUTPUT EXIT MEASURES BYPASS VOLTAGE xxx yyy zzz V BYPASS RESET Voltage is based on N-connector BYPASS FREQUENCY xx.x Hz BYPASS EXIT MEASURES INVERTER VOLT/CURR INVERTER xxx yyy zzz V RESET Voltage is based on N-connector INVERTER FREQUENCY xx.x Hz INVERTER...

  • Page 30: Alarms

    4.2.2 Alarms The menu “Alarms” displays the status of the UPS and the alarms. All active alarms and status reports will be displayed in the sub menu „UPS Status“. If a fault occurs, the status menu automatically appears and presents the relevant report on the display.

  • Page 31: Special

    4.2.3 Special Different settings to the UPS can be made in the „Special“-menu. For that a password entry is necessary, to prevent a change of the system data by unauthorized persons. Then the following settings can be made: Reset of the UPS, set Date/Time, select language, perform an UPS test, enter battery data, perform a battery test, install new battery, delete history, set modbus address and reset running time.
  • Page 32 Main menu Sub menu Display SPECIAL BAT CAPACITY SETTING BATTERY SETTING xxx.x Ah RESET CURSOR-Keys: Selection of a digit (0-9) Set the battery properties: RETURN: Confirmation of a digit Capacity, charging current, autonomy time RESET: Cancel current selection of digit and back to previous digit (4x) CONFIRM BATT CAP.?
  • Page 33 Main menu Sub menu Display SPECIAL NEW BATTERY INSTAL? NEW BATTERY INSTALL YES / NO RESET Set autonomy time of the new installed CURSOR-Keys: Selection YES/NO battery to 100 % RETURN: Confirmation YES/NO SPECIAL RESET HISTORY? RESET HISTORY YES / NO RESET CURSOR-Keys: Selection YES/NO Delete history...

  • Page 34: Info

    4.2.4 Info The menu „Info“ include all relevant information of the UPS as the serial numbers (Device and job number), the device type (Online-/Eco mode and single or parallel system), the device data at a parallel system (Only active, if available), the modbus address, the versions of the installed firmware, the service remark (Only active, if available) and the running time.
  • Page 35 Main menu Sub menu Display INFO PARALLEL PARALLEL x / y RESET Parallel menu only visible, if the UPS Position of the current UPS in the parallel belongs to a parallel system! system/Number of UPS devices in the parallel system PARALLEL MASTER Possibility: Master/Slave...
  • Page 36 Main menu Sub menu Display MODBUS EXIT INFO FIRMWARE RELEASE FIRMWARE RELEASE DSP1 R: vv.xx.yy.zz RESET Digital signal processor of the rectifier FIRMWARE RELEASE DSP2 I: vv.xx.yy.zz Digital signal processor of the inverter FIRMWARE RELEASE uC S: vv.xx.yy.zz Microcontroller of the static switch FIRMWARE RELEASE EXIT INFO...

  • Page 37: Alarm Messages And Status Reports In The Display

    Alarm messages and status reports in the display The status reports describe the operating condition of individual components, whereas alarm messages indicate special states or faults described in detail below. The descriptions of alarm messages additionally show possible causes and recommend initial actions that may be taken to resolve the problem. 4.3.1 Description of status reports RECTIFIER OK...

  • Page 38: Description Of Alarm Messages

    4.3.2 Description of alarm messages MAINS FAILURE Alarm The voltage or frequency of the input line is out of tolerance. Description Mains instability or failure. Possible causes Wrong phase rotation. 1. Check the connections to the mains. Solutions 2. Check the stability of mains voltage. 3.
  • Page 39 SHORT-CIRCUIT Alarm Description The current sensor has detected a short-circuit at the output. Load problem. Possible causes Measuring circuit failure. 1. Check the loads connected to the UPS output. Solutions 2. If the alarm persists, contact our Technical Support Service. SHORT-CIRCUIT TIMEOUT STOP Alarm Inverter shutdown due to an extended short-circuit during a power failure, or due to an over current on the inverter...
  • Page 40 THERMAL IMAGE Alarm The thermal image protection has been activated after an extended inverter overload. The inverter is shut down for 30 Description minutes and then restarted. Output overload. Possible causes Measuring circuit failure. 1. Check the loads connected to the UPS output. Solutions 2.
  • Page 41 BUS EPO (Electronic Power Off) Alarm Description The system is blocked due to the activation of the electronic power off button. Possible causes Activation of the (local or remote) electronic power off button. 1. Release the electronic power off button and reset the alarm. Solutions 2.
  • Page 42 HIGH SSW TEMPERATURE Alarm Description High temperature of the static switch heat sink. Fault of the heat sink cooling fans. Possible causes The room temperature or cooling air temperature is too high. 1. Check the fans operation. 2. Clean the ventilation grids and the air filters, if any. Solutions 3.
  • Page 43 STARTING SEQUENCE BLOCKED Alarm Description During the UPS start-up a failure prevented the proper execution of the sequence. Control devices in wrong position or operated improperly. Possible causes Possible internal fault. 1. Make sure the position of the control devices (isolators, selectors) is as specified in the procedures (see „Installation and Solutions start-up“...

  • Page 44: Commissioning And Decommissioning Procedures

    5 Commissioning and decommissioning procedures The procedures explain what to do when starting up, shutting down and switching between normal operation/bypass operation of the UPS. The sequence of actions must be adhered to exactly. Not adhering to the sequence may lead to serious faults and/or destruction of the UPS. In the event of queries, please contact our Technical Support Service (see contact details).

  • Page 45: Problems During Commissioning

    5.1.1 Problems during commissioning This paragraph contains essential information should an alarm occur during the start-up procedure. If the problem cannot be solved using this information, please contact our Technical Support Service. No information in the display after closing the RCB Check the phase sequence from the mains ...

  • Page 46: Commissioning From The Internal, Manual Bypass

    Commissioning from the internal, manual bypass This switchover procedure starts the UPS from the internal manual bypass. Before doing so, the following two preconditions must be checked. The bypass switch is in the bypass position  The MBCB is closed. ...

  • Page 47: Servicing

    6 Servicing Maintenance To maintain constant availability and operational reliability, we recommend that you carry out regular visual and functional tests on the UPS as well as inspecting the battery charge status. A log should be kept for verification. CAUTION: Maintenance work must sometimes be performed when the UPS is connected to the power supply.

  • Page 48: Repairs

    Repairs Despite the use of predominantly wear-free components, we recommend that you should store spare parts that are relevant to the operation of the UPS unit. This will assist the permanent operational readiness of your UPS. When ordering spare parts, please quote the designation (code) and order/device number. 6.2.1 Spare parts list The spare parts list will be submitted.

  • Page 49: Appendix

    8 Appendix The following pages contain technical documents, including drawings and technical specifications for the UPS unit. Technical data JOVYSTAR COMPACT S Online UPS-Type 30 kVA 40 kVA 50 kVA Output Output apparent power (cos φ = 0,9) 30 kVA 40 kVA 50 kVA Output active power (cos φ...

  • Page 50: Other Technical Documents

    Other technical documents We provide you through our website on the product page of the UPS the following documents available to download:  Battery data sheets Battery operating instructions  Material safety data sheet   CE – Compliance Declaration Download at: http://www.jovyatlas.com/ja/Waertsilae-JOVYSTAR-COMPACT,120-93-2 http://www.jovyatlas.com/Batteries...
  • Page 51 Operating Manual Wärtsilä JOVYSTAR COMPACT M 60kVA – 160kVA BAX 5480...

  • Page 52: D. Busboom

    Index Date Name Remarks 2015-12-12 Chr. Fechteler 2016-05-24 D. Busboom 16/285 2016-12-01 D. Busboom 16/540 2017-01-10 D. Busboom 17/008 2017-01-24 D. Busboom 17/037 2017-08-24 D. Busboom 17/274 2017-10-16 D. Busboom 17/364 Wärtsilä JOVYSTAR COMPACT M BAX 5480 - 2 -...
  • Page 53 Table of Contents Conventions Used ..........................5 Documentation Notes ........................6 Contact ............................. 6 Factory Warranty ..........................7 Limitation of Liability ......................... 9 Scope ............................... 9 Safety Rules and Warnings ......................10 Use of the UPS ........................10 Special Safety Warnings ....................... 10 Environmental Protection ......................
  • Page 54 15.2 Service Information ........................ 73 Faults and Alarms ........................74 16.1 Operating Status Definition ....................75 16.2 Troubleshooting ........................76 Technical Data ........................... 84 Service and Download ....................... 85 Wärtsilä JOVYSTAR COMPACT M BAX 5480 - 4 -...

  • Page 55: Conventions Used

    Thank you for choosing a Wärtsilä JOVYATLAS product. This section of the manual contains indications regarding the symbols used in the UPS documentation as well as basic information about the product, including the factory warranty terms. Conventions Used The following symbols have been used to indicate potential dangers and to highlight useful information, so as to minimize the risks to persons and property.

  • Page 56: Documentation Notes

    Documentation Notes Storing documentation This manual and any other supporting technical documentation relating to the product must be stored and made accessible to personnel in the immediate vicinity of the UPS. Further information In the event that the information provided in this manual is not sufficiently exhaustive, please contact the manufacturer of the device, whose details are available in the “Contacts”...

  • Page 57: Factory Warranty

    Factory Warranty The factory warranty provided by Wärtsilä JOVYATLAS EUROATLAS GmbH is subject to the terms indicated below. Validity a) The present warranty terms only apply to the UPS systems manufactured by JOVYATLAS and to their storage batteries, when supplied by JOVYATLAS. Duration a) The factory warranty provided by Wärtsilä...
  • Page 58 c) In case entry permits are necessary in order to enter the installation site, Wärtsilä JOVYATLAS EUROATLAS GmbH must be notified of the time necessary to obtain the documentation required, if any. d) In case of customer’s non-compliance, Wärtsilä JOVYATLAS EUROATLAS GmbH reserves the right to refuse warranty service.

  • Page 59: Limitation Of Liability

    Limitation of Liability All the information contained in the present documentation is the exclusive property of Wärtsilä JOVYATLAS EUROATLAS GmbH. Written consent by Wärtsilä JOVYATLAS EUROATLAS GmbH is required in order to wholly or partially publish or disclose this information. ...

  • Page 60: Safety Rules And Warnings

    Safety Rules and Warnings 7.1 Use of the UPS Congratulations on choosing a product from JOVYATLAS for the safety of your equipment. To obtain the best performance from your JOVYSTAR COMPACT m 60 - 160 kVA UPS system (Uninterruptible Power Supply), we suggest that you take your time to read the following manual. The purpose of this manual is to give a short description of the parts composing the UPS and to guide the installer or the user through the installation of the unit in its using environment.
  • Page 61 Please inspect the device before installing it. In case any damage is noticed from the conditions of the package and/or from the outside appearance of the equipment, contact the shipping company or your dealer immediately. The damage statement must be made within 6 days from receipt of the product and must be notified to the shipping carrier directly.
  • Page 62 7.2.4 Installation The product must be installed in strict compliance with the instructions contained in the technical back- up documentation, including the present safety instructions. In particular, the following points must be taken into account:  The product must be placed on a base suitable to carry its weight and to ensure its vertical position;...
  • Page 63 7.2.5 Electrical connection The UPS connection to the AC power must be carried out in compliance with the current regulations. Make sure the indications specified on the identification plate correspond to the AC power system and to the actual electrical consumption of all of the equipment connected. Check the conformity to the Standards The UPS must be installed in compliance with the standards in force in the country of installation.
  • Page 64 7.2.6 Operation The installations to which the UPS systems belong must comply with all the current safety standards (technical equipment and accident-prevention regulations). The device can be started, operated and disconnected only by authorized personnel. The settings can only be changed using the original interface software. Injury hazard due to electric shock! During operation, the UPS converts power characterized by high voltages and currents.
  • Page 65 7.2.7 Maintenance Service and repairs must be carried out by skilled and authorized personnel. Before carrying out any maintenance operation, the UPS must be disconnected from AC and DC supply sources. The device is provided with internal isolators which allow to isolate the internal power circuits. However the voltages of the supply sources are present on the terminals.

  • Page 66: Environmental Protection

    7.3 Environmental Protection 7.3.1 Recycling of packing materials Packing materials must be recycled or disposed of in compliance with applicable local and national laws and regulations. 7.3.2 Device disposal At the end of their product life, the materials composing the device must be recycled or disposed of in compliance with the current local and national laws and regulations.

  • Page 67: Handling Of The Ups

    8.2 Handling of the UPS The UPS is packed on a pallet. It is handled from the transport vehicle to the installation (or storage) place via a fork lift. The device has a heavy weight  Avoid turnover during the transport of the UPS. ...

  • Page 68: Positioning And Installation

    8.3 Positioning and Installation The UPS must be installed indoor, in a clean and dry room, preferably without dust or humidity infiltrations. For the environmental conditions in the place of installation, in compliance with the current legislation, please refer to the “Overall dimensions, minimum distances from the walls and ventilation” section.
  • Page 69 8.3.2 Overall Dimensions, Clearances and Ventilation Picture 4 – Overall dimensions Picture 5 – Clearances Wärtsilä JOVYSTAR COMPACT M BAX 5480 - 19 -...
  • Page 70 The UPS must be so installed as to ensure its serviceability and to allow a correct air flow as much as possible. With regard to the minimum distances from the walls, for all of the UPS sizes the same installation conditions apply as indicated in the table below.
  • Page 71 8.3.3 Environmental Installation Conditions The air is classified by the EN 60721-3-3 standard (Classification of environmental parameters and their severities – Stationary use at weather-protected locations) based on climatic and biological conditions as well as on mechanically and chemically active substances. Therefore the place of installation must meet specific requirements to ensure compliance with the conditions for which the UPS was designed.

  • Page 72: Positioning And Connection Of The Batteries

    8.4 Positioning and Connection of the Batteries Risk of electric shock A battery can present a risk for electrical shock and high short circuit current. The following precautions should be observed when working on batteries: a) Remove watches, rings or other metal objects; b) Use tools with insulated handles;...

  • Page 73: Electrical Connection

    Electrical connection The electrical connection is part of the work which is normally provided by the company that carries out the product installation. For this reason, the UPS manufacturer shall not be held responsible for any damages due to wrong connections. Use qualified personnel only All the operations related to the electric connection must be carried out by qualified and trained personnel.

  • Page 74: Connection Of The Power Cables

    Mains connection The connection to the mains must be carried out with protection fuses between the mains and the UPS. The use of differential protection devices in the line supplying the UPS is unadvisable. The leakage current to ground due to the RFI filters is rather high and it can cause spurious tripping of the protection device.

  • Page 75: Backfeed Protection Device

    Should larger cable cross-sections be required for the installation than the maximum cross-section of the UPS terminals, a socket or a terminal box can be installed near the UPS. From there to the UPS, a cable laying with a smaller cross-section can be possible (better laying conditions such as installation type, cable length, ...).

  • Page 76: Terminal Boards

    9.3 Terminal Boards The UPS is provided with terminal boards for the connection of power cables and of auxiliary connections. UPS OUTPUT Picture 6 – Terminal board 60 – 80kVA Picture 7a – Terminal board 100 kVA Picture 7b – Terminal board 125 - 160 kVA Wärtsilä...

  • Page 77: Battery

    9.4 Battery CAUTION A battery can present a risk for electrical shock and high short circuit current. The following precautions should be observed when working on batteries: a) Remove watches, rings or other metal objects; b) Use tools with insulated handles; c) Wear rubber gloves and boots;...
  • Page 78 Internal batteries The UPS can have internal batteries.  Servicing of batteries should performed by qualified personnel only.  Replace the batteries with the same number of block and capacity.  Replace only with original type.  CAUTION: do not dispose of batteries in fire. The battery may explode. ...
  • Page 79 9.4.1.1 Battery 7/9/11Ah 12V installation – 60-80 kVA 1) Remove the six screws to open the left/right lateral cover and access the battery trays (total trays are 6 and each contain three rows of 10 batteries, see picture 9 & 10). Screw to fix the tray Picture 9 - Trays 7/9/11Ah 12V battery lateral view Picture 10 –...
  • Page 80 2) Install the batteries received in a separate packages and install it in accordance with the picture 11 and picture 12. Picture 11- 7/9/11Ah 12V battery connection tray top view Picture 12- 7/9/11Ah 12V battery connection tray front view 3) After the connection re-insert the battery trays on the internal of UPS. 4) Put back and fix the left/right cover with the four screws.
  • Page 81 9.4.1.2 Battery 12/14Ah 12V battery installation – 60-80 kVA 1) Remove the six screws to open the left/right lateral cover and access the battery trays (total trays are 6 and each contain two rows of 7 batteries and one rows of 6 batteries, see picture 13 &...
  • Page 82 2) Install the batteries received in a separate packages and install it in accordance with the picture 15 and picture 16. Picture 15- 12/14Ah 12V battery connection tray top view Picture 16-12/14Ah 12V battery connection tray front view 3) After the connection re-insert the battery trays on the internal of UPS. 4) Put back and fix the left/right cover with the four screws.

  • Page 83: Connection Of The Auxiliary Cables

    9.5 Connection of the Auxiliary Cables The UPS systems can be connected to external controls/components specifically designed to improve the safety and reliability of the device. External manual bypass (MBCB); External Normal/Bypass selector switch; External output switch (OCB); Remote emergency power off button (EPO); Auxiliary battery contact (BCB).

  • Page 84: Serial Interfaces And External Connections

    9.5.4 Remote emergency power off (EPO) Auxiliary EPO contact on terminals X10-7/8. The voltage supply to the loads can be interrupted from a remote location by using this contact (i.e. for safety requirements). A normally closed contact is required; when this contact is open the static inverter and by-pass switches are opened so that the output supply is interrupted.
  • Page 85  RS232/USB: it is used for connection to the proprietary programming and control software.  SRC-2 (OPTIONAL): relay card, used for the remote signalizations of status and alarms.  PARALLEL (OPTIONAL): it is used for communication between paralleled UPS units. ...

  • Page 86: Relay Card Connection (Optional)

    9.7 Relay Card Connection (Optional) The UPS, in its full configuration, is provided with a relay card for repeating alarms and operating statuses remotely. The electric connection is carried out directly on the terminals located on the front of the interfaces slot SRC-2. Picture 19 –...

  • Page 87: Ups-Options (Optional Equipment)

    9.8 UPS-Options (Optional equipment) Following UPS-Options are described in the operating manual BAX 4834: SNMP adapter  PROFIBUS  MODBUS  Battery symmetry supervision  Parallel redundant systems  Wärtsilä JOVYSTAR COMPACT M BAX 5480 - 37 -...

  • Page 88: Startup And Shutdown

    10 Startup and Shutdown Read the technical documentation Before installing and using the device, make sure you have read and understood all the instructions contained in the present manual and in the technical supporting documentation. Further information In the event that the information provided in this manual is not sufficiently exhaustive, please contact the manufacturer of the device, whose details are available in the “Contacts”...

  • Page 89: Start-Up Procedure

    10.2 Start-Up Procedure EPO push-button and phase rotation Before switching the UPS on, make sure that: 1) the emergency power off “EPO” push-button, if installed, is not pressed. If not, press it back to the rest position; 2) the input and output phase rotation is correct. Circuit breaker BCB Do not close the battery breaker BCB before it’s required by the front panel.
  • Page 90 Action Checks Blank CLOSE RCB After operating switch RCB the pre-charging phase of the capacitive bank will start. The control logic will be started and the front panel is activated. BOOT LOADER “BOOT” phase where the UPS firmware can be updated following the appropriate procedure.

  • Page 91: Basic Troubleshooting

    10.3 Basic Troubleshooting This paragraph provides the basic information if any problems occur during the start-up procedure. In case the problem cannot be solved, contact the service department. 1) After closing RCB the LCD display is still blank  Check the phase rotation of supply voltage. ...

  • Page 92: Switching To Manual Bypass

    10.4 Switching to Manual Bypass The load is transferred to Manual Bypass with no interruption of supply to the loads. In this configuration, the system can be restarted via the return procedure from load on manual bypass, without the need to de-energize the loads. Manual bypass To perform the switching procedure correctly, make sure no alarms are present on the system.

  • Page 93: Restart From Manual Bypass

    10.5 Restart from Manual Bypass Before restarting the UPS from manual by-pass, make sure the “Bypass_SW" selector is in BYPASS position and the MBCB isolator is closed. ACTION Checks BLANK Close RCB BOOT LOADING “BOOT” phase where the UPS firmware can be updated following the appropriate procedure.

  • Page 94: General Ups Description

    11 General UPS Description 11.1 Typology The UPS described in this manual is on-line, double conversion; the inverter included in the UPS always supplies energy to the load, whether mains is available or not (according to the battery autonomy time). This configuration guarantees the best service to the User, as it supplies clean power uninterruptedly, ensuring voltage and frequency stabilization at nominal value.
  • Page 95 11.2.2 Inverter It converts the direct voltage coming from the rectifier or from the DC battery into alternating AC voltage stabilized in amplitude and frequency. The inverter uses IGBT technology with a high switching frequency of approximately 8 kHz. hat, thanks to its processing capability, generates an excellent output sine-wave.

  • Page 96: Operating Status

    11.3 Operating Status The UPS has five different operating modes, as described below:  Normal operation  Green Conversion  Bypass operation  Battery operation  Manual bypass 11.3.1 Normal operation During normal operation all the circuit breakers/isolators are closed, except for MBCB (maintenance bypass).
  • Page 97 The battery charge is controlled by a specific algorithm. In case no mains outage events have occurred, and so no battery discharges have occurred too, the control logic provides to start a charging cycle once every 25 days. The battery-charger restores the capacity lost due to the self- discharge and remains in floating charge for additional 12 hours.
  • Page 98 The system restart from the black-out condition can be customized based on the requirements of the plant, in three different modes:  Bypass loads are supplied as soon as the bypass line is available (factory  configuration).  Inverter loads are supplied by the inverter (even if the bypass line is available) ...
  • Page 99 Wiring of the auxiliary contacts Carry out a proper electrical installation by wiring the auxiliary contacts of the manual bypass and output isolators to the dedicated terminals on board the UPS. This will allow the control logic to acquire the status of the switches and guide the operator during the start-up and manual bypass procedures.

  • Page 100: Control And Operation Devices

    11.4 Control and Operation Devices The control and operation devices of the UPS are indicated below:  Isolator on rectifier input (RCB)  Isolator on bypass input (SBCB)  Isolator on UPS output (OCB)  Manual bypass isolator (MBCB)  Battery Isolator / Circuit breaker (BCB) - External, inside the battery cabinet ...
  • Page 101 Supply reset Reset the output supply only when the causes which led to the emergency shutdown have been eliminated and you are sure that there is no hazard to persons and things. 11.4.3 Normal/Bypass Selector The Normal/Bypass selector is installed externally, on the rear of UPS. It is generally used during the manual bypass procedure, when it is necessary to isolate the UPS for maintenance or repair.

  • Page 102: Front Panel

    12 Front Panel The front panel of the UPS, consisting of four rows alphanumeric display plus 5 function keys, allows the complete monitoring of the UPS status. The mimic flow helps to understand the operating status of the UPS. Picture 27 – UPS front panel Wärtsilä...

  • Page 103: Function Buttons

    12.1 Function Buttons The front panel of the UPS is provided with 5 buttons whose functions are indicated in the following table: Button Assigned functions  Scrolls up the menus  Increases the values by one unit  Selects a value ...

  • Page 104: Mimic Panel / Led

    12.2 Mimic Panel / LED Picture 28 – UPS mimic panel AC line on rectifier input within tolerance GREEN LED 1 AC mains failure / Wrong phase rotation GREEN AC bypass line within tolerance GREEN LED 2 Wrong phase rotation GREEN AC bypass line out of tolerance / failure Rectifier off or faulty...

  • Page 105: Led-Bar

    12.3 LED-Bar Picture 29 – LED bar AC line on rectifier input within tolerance GREEN Wrong phase rotation (fast blinking) GREEN LED 11 Unbalanced AC voltage (slow blinking) GREEN AC mains failure Circuit breaker BCB closed and battery charging GREEN Battery discharging or under TEST (fast blinking) ORANGE LED 12...

  • Page 106: Handling The Operating Panel

    13 Handling the Operating Panel 13.1 Main Menus Main screen (nominal power of the UPS) UPS NAME xxx kVA UPS measures regarding basic parameters UPS NAME (voltage, current, etc.) MEASURES UPS operating status, possible alarms present and UPS NAME alarms history ALARMS Setting of parameters and special functions UPS NAME...

  • Page 107: Measures Display

    13.2 Measures Display The Measures-menu is structured as follows: Picture 30 – Structure of MEASURES menu (1 of 2) Wärtsilä JOVYSTAR COMPACT M BAX 5480 - 57 -...
  • Page 108 Picture 31 – Structure of MEASURES menu (2 of 2) Sub-menu Displayed data Accuracy Rectifier input voltage (1) (2) Rectifier input current INPUT Frequency 0.1 Hz Input power 1 kVA Voltage (1) (2) Current Frequency 0.1 Hz OUTPUT Active power 1 kW Apparent power 1 kVA...

  • Page 109: Basic Diagnostics

    13.3 Basic Diagnostics The ALARMS menu allows to display the current operating status of the device and to access the event log, based on the following structure. Picture 32 – Structure of ALARMS menu Sub-menu Displayed data UPS STATUS Alarms present and operating statuses HISTORY Event log The LCD panel displays the ALARMS menu automatically whenever an alarm occurs.
  • Page 110 13.3.1 Display of alarms history All the events are recorded in the alarms history. UPS STATUS HISTORY HISTORY: xxx/yyy Alarm code Date/time The first event shown is the latest one in order of time; a new event makes all the other events automatically shift one position, clearing the oldest event.
  • Page 111 13.3.2 Alarms and operating status ALARMS MAINS FAULT CRITICAL FAULT INPUT WRONG SEQ MAINTENANCE REQ BOOSTER STOPPED COMMON ALARM BOOSTER FAULT MBCB BUS CLOSED DC VOLTAGE FAULT EPO BUS CLOSED BATTERY IN TEST ASYMMETRIC LOAD BCB OPEN SERVICE REQUIRED BATTERY DISCHARGE DIESEL MODE BATTERY AUT END DC FASTSHUTDOWN...
  • Page 112 Status BOOSTER OK BATT STANDBY BATTERY OK BATT CHARGING INVERTER OK BATT FLOATING INVERTER --> LOAD INV BYPASS SYNC BYPASS OK BYPASS --> LOAD INV MASTER SYNC Display and recording mode of alarms  The statuses are always displayed in ascending order when the ALARMS – STATUSES menu is entered.

  • Page 113: Settings And Advanced Operations

    14 Settings and Advanced Operations Some operating parameters of the UPS can be set via the SPECIAL menu, which is structured as follows: Picture 33 – Structure of SPECIAL menu Wärtsilä JOVYSTAR COMPACT M BAX 5480 - 63 -...
  • Page 114 Sub-menu Programmable data RESET Reset of failure conditions CLOCK SETTINGS System date and time SELECT LANGUAGE Display language setting UPS TEST Performs a commutation test BATTERY SETTING Battery parameter setting BATTERY TEST Performs a battery test NEW BATTERY INSTALL Sets autonomy to 100% RESET HISTORY Event log reset MODBUS...

  • Page 115: Setting Date And Time

    14.1 Setting Date and Time Date and time may be set via the CLOCK menu. The single digits can be modified via the arrow keys CLOCK SETTINGS ) and confirmed by pressing (ENTER). DD-MM-YY hh : mm Setting the current date and time correctly The correct setting of the date and time is essential for the recording of the event log.
  • Page 116 Access the menu by pressing the button (ENTER). The single digits can be modified via the arrow keys BAT CAPACITY SETTING ) and confirmed by pressing (ENTER). 0120 Confirmation screen of the parameter set CONFIRM BATT CAP.? The single digits can be modified via the arrow keys BAT RECHAR CURR SET ) and confirmed by pressing (ENTER).

  • Page 117: Setting Modbus Parameters

    Setting all the parameters To save all the parameters it is necessary to reach the end of the guided procedure until the last screen previously shown. If the procedure is interrupted earlier, none of the parameters previously set will be saved. 14.5 Setting Modbus Parameters The parameters regarding the communication via RS485 interface can be set in the MODBUS menu.

  • Page 118: Battery Test

    14.7 Battery Test The BATTERY TEST menu allows to carry out a short discharge test of the battery. In case the battery is not efficient, the alarm “A10 – Battery fault” is generated at the end of the test. The value on the second line is ready to be changed BATTERY TEST? (1x) The parameter is changed.

  • Page 119: Reset Alarm History

    The failure conditions which impose a manual reset are:  Static switch re-transfer block (alarm A17)  Inverter shutdown due to the operation of the IGBT desaturation sensor (alarm A44)  Inverter shutdown due to short-circuit timeout (alarm 12)  Inverter shutdown due to thermal image protection (alarm 21) ...

  • Page 120: System Information

    15 System Information The INFO menu provides general information regarding the UPS based on the structure indicated below. Picture 34 – Structure of INFO menu All data shown in the various sections are set by the factory via a special interface software and cannot be altered, except by personnel authorized by the manufacturer.

  • Page 121: Parallel Operation Information

    Sub-menu Displayed data SERIAL NUMBER Device serial number given by the manufacturer and by an OEM distributor, if any DEVICE TYPE The device type can be: ON LINE - UPS FREQUENCY CONVERTER ECO MODE - UPS SINGLE UPS PARALLEL PARALLEL Data regarding the parallel configuration MODBUS MODBUS address of device...
  • Page 122 15.1.3 Communication Bus Monitoring PARALLEL 1-[ M ] 2- S 3- S 4- S The second line of this menu gives a general indication regarding the communication between the UPS units composing the system.  The numbers represent the single UPS units. ...

  • Page 123: Service Information

    15.1.5 Message Statistics The statistics section regarding the messages exchanged on the communication buses consists of three different menus. CAN STATISTICS SSW MSG RX: 32564 100.0% Number of messages received and percentage of reception accuracy regarding the status of the static switches.

  • Page 124: Faults And Alarms

    16 Faults and Alarms As indicated in the previous chapters, the system is provided with basic diagnostics which allow immediate visualization of the operating conditions. The LCD panel displays the alarms screen immediately, and an audible indicator is activated (if enabled).

  • Page 125: Operating Status Definition

    16.1 Operating Status Definition BOOSTER OK Status Description The rectifier section is working properly. Operating The rectifier supplies the inverter and keeps the battery charged. condition BATTERY OK Status Description The battery is connected to the UPS. Operating The battery is kept charged by the rectifier and is ready to feed the inverter. condition INVERTER OK Status...

  • Page 126: Troubleshooting

    BATT STANDBY Status Description The battery is in standby mode. Operating The battery static switch is open and the battery is disconnected from the DC bus. condition BATT CHARGING Status Description The battery is charging. Operating The battery is connected to the DC bus and absorbing charging current. condition BATT FLOATING Status...
  • Page 127 DC VOLTAGE FAULT Alarm Description The measured DC voltage is out of tolerance. Possible  The battery has reached the discharge voltage due to a power failure. causes  Measuring circuit failure. Solutions 1. Check the actual value of the measured DC voltage. 2.
  • Page 128 STOP TIMEOUT SC Alarm Description Inverter shutdown due to an extended short-circuit during a power failure, or due to an overcurrent on the inverter bridge input. Possible  Short-circuit on the loads during a power failure. causes  Inverter bridge fault. ...
  • Page 129 OCB OPEN Alarm Description The output isolator is open. Possible  Output isolator open. causes Solutions 1. Check the status of the output isolator. 2. Check the functionality of the auxiliary contact of the isolator. 3. If the alarm persists, contact our Technical Support Service. Alarm OVERLOAD Description...
  • Page 130 Alarm INVERTER OFF Description The inverter is blocked due an operation failure. Possible  Various. causes Solutions 1. Reset the system. 2. If the alarm persists, contact our Technical Support Service. COMMUNIC ERROR Alarm Description Internal error. Possible  Microcontroller communication problems. causes Solutions 1.
  • Page 131 EPO BUS CLOSED Alarm Description The system is blocked due to the activation of the emergency power off button. Possible  Activation of the (local or remote) emergency power off button. causes Solutions 1. Release the emergency power off button and reset the alarm. 2.
  • Page 132 SSI FAULT Alarm Description The system has detected a failure in the static inverter switch. Possible  Possible problems on the loads. causes  Static switch fault. Solutions 1. Check the absorption of the loads and the presence of DC components, if any, on AC current.
  • Page 133 TEST MODE ERROR Alarm Description Internal error. Possible  Microcontroller communication problems. causes Solutions 1. Contact our Technical Support Service. SSW BLOCKED Alarm Description The static switch is blocked. The load is no longer supplied. Possible  Loads failure. causes ...

  • Page 134: Technical Data

    17 Technical Data JOVYSTAR COMPACT m Online UPS-Type 60 kVA 80 kVA 100 kVA 125 kVA 160 kVA Output Output apparent power (cos φ = 1) 60 kVA 80 kVA 100 kVA 125 kVA 160 kVA Output active power (cos φ = 1) 60 kW 80 kW 100 kW...

  • Page 135: Service And Download

    18 Service and Download Following documents are available at our website:  Battery data sheets  Battery operating instructions Material safety data sheet  CE – Compliance Declaration  http://www.jovyatlas.com/ja/Waertsilae-JOVYSTAR-COMPACT,120-93-2 http://www.jovyatlas.com/Batteries S E R V I C E – H O T L I N E ! Telefon: 04958 - 9394 - 30 Telefax: 04958 - 9394 - 10 E-Mail:...
  • Page 136 Operating Manual Wärtsilä JOVYSTAR COMPACT L 200kVA BAX 5624...

  • Page 137: D. Busboom

    Index Date Name Remarks 2016-11-23 D. Busboom 2017-01-10 D. Busboom 17/008 2017-01-24 D. Busboom 17/037 Wärtsilä JOVYSTAR COMPACT L BAX 5624 - 2 -...
  • Page 138 Table of Contents Conventions Used ..........................4 Documentation Notes ........................5 Contact ............................. 5 Factory Warranty ..........................6 Limitation of Liability ......................... 8 Scope ............................... 8 Safety Rules and Warnings ......................9 Use of the UPS ........................9 Special Safety Warnings ......................9 Environmental Protection ......................

  • Page 139: Conventions Used

    Thank you for choosing a Wärtsilä JOVYATLAS product. This section of the manual contains indications regarding the symbols used in the UPS documentation as well as basic information about the product, including the factory warranty terms. Conventions Used The following symbols have been used to indicate potential dangers and to highlight useful information, so as to minimize the risks to persons and property.

  • Page 140: Documentation Notes

    Documentation Notes Storing documentation This manual and any other supporting technical documentation relating to the product must be stored and made accessible to personnel in the immediate vicinity of the UPS. Further information In the event that the information provided in this manual is not sufficiently exhaustive, please contact the manufacturer of the device, whose details are available in the “Contacts”...

  • Page 141: Factory Warranty

    Factory Warranty The factory warranty provided by Wärtsilä JOVYATLAS EUROATLAS GmbH is subject to the terms indicated below. Validity a) The present warranty terms only apply to the UPS systems manufactured by JOVYATLAS and to their storage batteries, when supplied by JOVYATLAS. Duration a) The factory warranty provided by Wärtsilä...
  • Page 142 d) In case of customer’s non-compliance, Wärtsilä JOVYATLAS EUROATLAS GmbH reserves the right to refuse warranty service. Wärtsilä JOVYATLAS EUROATLAS GmbH will not accept any product returned for repair or replacement without prior agreement. Exclusions a) Our warranty does not cover the products which are faulty or damaged due to: ...

  • Page 143: Limitation Of Liability

    Limitation of Liability All the information contained in the present documentation is the exclusive property of Wärtsilä JOVYATLAS EUROATLAS GmbH. Written consent by Wärtsilä JOVYATLAS EUROATLAS GmbH is required in order to wholly or partially publish or disclose this information. ...

  • Page 144: Safety Rules And Warnings

    Safety Rules and Warnings 7.1 Use of the UPS Congratulations on choosing a product from JOVYATLAS for the safety of your equipment. To obtain the best performance from your JOVYSTAR COMPACT L 200 kVA UPS system (Uninterruptible Power Supply), we suggest that you take your time to read the following manual. The purpose of this manual is to give a short description of the parts composing the UPS and to guide the installer or the user through the installation of the unit in its using environment.
  • Page 145 Please inspect the device before installing it. In case any damage is noticed from the conditions of the package and/or from the outside appearance of the equipment, contact the shipping company or your dealer immediately. The damage statement must be made within 6 days from receipt of the product and must be notified to the shipping carrier directly.
  • Page 146 7.2.4 Installation The product must be installed in strict compliance with the instructions contained in the technical back- up documentation, including the present safety instructions. In particular, the following points must be taken into account:  The product must be placed on a base suitable to carry its weight and to ensure its vertical position;...
  • Page 147 7.2.5 Electrical connection The UPS connection to the AC power must be carried out in compliance with the current regulations. Make sure the indications specified on the identification plate correspond to the AC power system and to the actual electrical consumption of all of the equipment connected. Check the conformity to the Standards The UPS must be installed in compliance with the standards in force in the country of installation.
  • Page 148 7.2.6 Operation The installations to which the UPS systems belong must comply with all the current safety standards (technical equipment and accident-prevention regulations). The device can be started, operated and disconnected only by authorized personnel. The settings can only be changed using the original interface software. Injury hazard due to electric shock! During operation, the UPS converts power characterized by high voltages and currents.
  • Page 149 7.2.7 Maintenance Service and repairs must be carried out by skilled and authorized personnel. Before carrying out any maintenance operation, the UPS must be disconnected from AC and DC supply sources. The device is provided with internal isolators which allow to isolate the internal power circuits. However the voltages of the supply sources are present on the terminals.

  • Page 150: Environmental Protection

    7.3 Environmental Protection 7.3.1 Recycling of packing materials Packing materials must be recycled or disposed of in compliance with applicable local and national laws and regulations. 7.3.2 Device disposal At the end of their product life, the materials composing the device must be recycled or disposed of in compliance with the current local and national laws and regulations.

  • Page 151: Handling Of The Ups

    8.2 Handling of the UPS The UPS is packed on a pallet. It is handled from the transport vehicle to the installation (or storage) place via a fork lift. The device has a heavy weight  Avoid turnover during the transport of the UPS. ...

  • Page 152: Positioning And Installation

    8.3 Positioning and Installation The UPS must be installed indoor, in a clean and dry room, preferably without dust or humidity infiltrations. For the environmental conditions in the place of installation, in compliance with the current legislation, please refer to the “Overall dimensions, minimum distances from the walls and ventilation” section.
  • Page 153 Power (kVA) Weight (kg) Static load (kg/m^2) 1120 8.3.2 Overall Dimensions, Clearances and Ventilation OUTLET AIR OPENINGS INLET AIR OPENINGS Picture 4 – Overall dimensions Wärtsilä JOVYSTAR COMPACT L BAX 5624 - 18 -...
  • Page 154 Picture 5 – Clearances The UPS must be so installed as to ensure its serviceability and to allow a correct air flow as much as possible. With regard to the minimum distances from the walls, for all of the UPS sizes the same installation conditions apply as indicated in the table below.
  • Page 155 8.3.3 Environmental Installation Conditions The air is classified by the EN 60721-3-3 standard (Classification of environmental parameters and their severities – Stationary use at weather-protected locations) based on climatic and biological conditions as well as on mechanically and chemically active substances. Therefore the place of installation must meet specific requirements to ensure compliance with the conditions for which the UPS was designed.

  • Page 156: Positioning And Connection Of The Batteries

    8.4 Positioning and Connection of the Batteries Risk of electric shock A battery can present a risk for electrical shock and high short circuit current. The following precautions should be observed when working on batteries: a) Remove watches, rings or other metal objects; b) Use tools with insulated handles;...

  • Page 157: Electrical Connection

    Electrical connection The electrical connection is part of the work which is normally provided by the company that carries out the product installation. For this reason, the UPS manufacturer shall not be held responsible for any damages due to wrong connections. Use qualified personnel only All the operations related to the electric connection must be carried out by qualified and trained personnel.

  • Page 158: Connection Of The Power Cables

    Mains connection The connection to the mains must be carried out with protection fuses between the mains and the UPS. The use of differential protection devices in the line supplying the UPS is unadvisable. The leakage current to ground due to the RFI filters is rather high and it can cause spurious tripping of the protection device.
  • Page 159 Details of the electrical connections Power (kVA) Input fuses [A] Rectifier Bypass Power connections Type Aluminium bars Conductor max. cross section [mm2] Max. number of conductors Fixing bolt dimensions Tightening torque [Nm] 4 ÷ 4,5 Bolt M10 (19 Nm) Rated current (at full load and battery recharging) Power (kVA) Rectifier input [A] Bypass input / Output [A]...

  • Page 160: Backfeed Protection Device

    9.2 Backfeed Protection Device The UPS is provided (as option) with voltage-free contacts, which can be used to operate the shunt trip coil (undervoltage release type) of the external sectioning device; the external device is not part of the UPS supply and is provided and installed at customer care. The following table shows the main electrical characteristics of the external sectioning device.

  • Page 161: Battery

    9.4 Battery CAUTION A battery can present a risk for electrical shock and high short circuit current. The following precautions should be observed when working on batteries: a) Remove watches, rings or other metal objects; b) Use tools with insulated handles; c) Wear rubber gloves and boots;...

  • Page 162: Connection Of The Auxiliary Cables

    9.5 Connection of the Auxiliary Cables The UPS systems can be connected to external controls/components specifically designed to improve the safety and reliability of the device.  External manual bypass (MBCB);  External bypass switch (selector normal/bypass);  External output switch (OCB); ...

  • Page 163: Serial Interfaces And External Connections

    9.5.4 Remote emergency power off (EPO) Auxiliary EPO contact on terminals X10-7/8. The voltage supply to the loads can be interrupted from a remote location by using this contact (i.e. for safety requirements). A normally closed contact is required; when this contact is open the static inverter and by-pass switches are opened so that the output supply is interrupted.
  • Page 164  RS232/USB: it is used for connection to the proprietary programming and control software.  SRC-2 (OPTIONAL): relay card, used for the remote signalizations of status and alarms.  PARALLEL (OPTIONAL): it is used for communication between paralleled UPS units. ...

  • Page 165: Relay Card Connection (Optional)

    9.7 Relay Card Connection (Optional) The UPS, in its full configuration, is provided with a relay card for repeating alarms and operating statuses remotely. The electric connection is carried out directly on the terminals located on the front of the interfaces slot SRC-2. Picture 9 –...

  • Page 166: Startup And Shutdown

    10 Startup and Shutdown Read the technical documentation Before installing and using the device, make sure you have read and understood all the instructions contained in the present manual and in the technical supporting documentation. Further information In the event that the information provided in this manual is not sufficiently exhaustive, please contact the manufacturer of the device, whose details are available in the “Contacts”...

  • Page 167: Start-Up Procedure

    10.2 Start-Up Procedure EPO push-button and phase rotation Before switching the UPS on, make sure that: 1) the emergency power off “EPO” push-button, if installed, is not pressed. If not, press it back to the rest position; 2) the input and output phase rotation is correct. Circuit breaker BCB Do not close the battery breaker BCB before it’s required by the front panel.
  • Page 168 Close the rectifier input switch RCB. After some seconds the touch screen will start and will show the UPS mimic diagram. Picture 10 – UPS start-up page After the software loading phase the control logic will acquire the system status and the operation of the RCB switch, and will show the operating sequences.
  • Page 169 Picture 12 – Inverter start-up As the inverter is correctly started-up, close the bypass switch SBCB when indicated by the display. The logic will check the correctness of the bypass phase sequence and RMS voltage value. Picture 13 – Bypass start-up Close the battery switch BCB when indicated by the display.
  • Page 170 Picture 14 – Battery start-up Operation on BCB switch The switch BCB, located in the external battery cabinet, can only be closed if the DC voltage is in tolerance. Serious damages both to the battery and the equipment may occur if the breaker is closed before the front panel requires it.

  • Page 171: Shut-Down Procedure

    Picture 16 – Start-up end 10.3 Shut-down procedure Open the switch OCB. Open the switch BCB. Open the switch SBCB. Open the switch RCB. 10.4 SWITCHING PROCEDURE TO MANUAL BYPASS The load is transferred to Manual Bypass with no interruption of supply to the loads. In this configuration, the system can be restarted via the return procedure from load on manual bypass, without the need to de-energize the loads.

  • Page 172: Restart From Manual Bypass

    10.5 Restart from Manual bypass Before restarting the UPS from manual bypass, make sure the “Bypass_Sw" selector is in BYPASS position and the MBCB isolator is closed. Close the rectifier input switch RCB. After some seconds the touch screen will start and will show the UPS mimic diagram.
  • Page 173 Close the battery switch BCB when indicated by the display. Picture 19 – Connecting the battery Close the output switch OCB when required and immediately after the display will require to open the manual bypass switch MBCB. The inverter will start. Picture 20 –...
  • Page 174 Picture 21 – Opening the manual bypass switch Picture 22 – Inverter start-up As soon as the inverter is started it will be possible to transfer the load. Move the bypass switch as required by the display to complete the UPS start-up. Wärtsilä...
  • Page 175 Picture 23 – Transferring the load Picture 24 – Re-start from manual bypass completed Wärtsilä JOVYSTAR COMPACT L BAX 5624 - 40 -...

  • Page 176: General Ups Description

    11 General UPS Description 11.1 Typology The UPS described in this manual is on-line, double conversion; the inverter included in the UPS always supplies energy to the load, whether mains is available or not (according to the battery autonomy time). This configuration guarantees the best service to the User, as it supplies clean power uninterruptedly, ensuring voltage and frequency stabilization at nominal value.
  • Page 177 11.2.2 Inverter It converts the direct voltage coming from the rectifier or from the DC battery into alternating AC voltage stabilized in amplitude and frequency. The inverter uses a 3-level power conversion bridge with IGBT technology in order to work with a high switching frequency of approximately 8 kHz.

  • Page 178: Operating Status

    11.3 Operating Status The UPS has five different operating modes, as described below:  Normal operation  Green Conversion  Bypass operation  Battery operation  Manual bypass 11.3.1 Normal operation During normal operation all the circuit breakers/isolators are closed, except for MBCB (maintenance bypass).
  • Page 179 When the Green Conversion algorithm is active the rectifier operates at reduced DC voltage and supplies the inverter alone, since the battery is disconnected from the DC bus. The battery charge is controlled by a specific algorithm. In case no mains outage events have occurred, and so no battery discharges have occurred too, the control logic provides to start a charging cycle once every 25 days.
  • Page 180 11.3.4 Battery operation In case of power failure or rectifier fault, the battery feeds the inverter without interruption. The battery voltage drops based on the amplitude of the discharging current. The voltage drop has no effect on the output voltage, which is kept constant by changing the PWM modulation. An alarm is activated when the battery is near the minimum discharge value.
  • Page 181 11.3.5 Manual bypass The manual bypass operation is necessary whenever the UPS functionality is tested, or during maintenance or repair work. Picture 30 – Manual bypass for functional checks Follow the procedures contained in the manual The sequence of manual bypass switching and return must be carried out with respect to the procedure indicated in the installation and start-up section.

  • Page 182: Control And Operation Devices

    11.4 Control and Operation Devices The control and operation devices of the UPS are indicated below:  Isolator on rectifier input (RCB)  Isolator on bypass input (SBCB)  Isolator on UPS output (OCB)  Manual bypass isolator (MBCB)  Battery Isolator / Circuit breaker (BCB) - External, inside the battery cabinet ...
  • Page 183 Supply reset Reset the output supply only when the causes which led to the emergency shutdown have been eliminated and you are sure that there is no hazard to persons and things. 11.4.3 Normal/Bypass Selector The Normal/Bypass selector is installed externally, on the rear of UPS. It is generally used during the manual bypass procedure, when it is necessary to isolate the UPS for maintenance or repair.

  • Page 184: Control Panel

    CONTROL panel The UPS control panel is a 10.1" touch screen which dialogues with the I/O module control logic via serial protocol. The main page (Home) shows the system flow diagram, from which all the UPS operating variables can be displayed. Picture 32 –...
  • Page 185 12.1.1 Icons colours The icons can take on different colours on the basis of the UPS operating condition; in general the basic colours are:  Light blue  It indicates that the section is related to the UPS.  Grey  The keys turn grey (disabled) when the key specific section is entered. ...

  • Page 186: Touch Screen - Managing The Ups

    Touch screen – Managing the UPS The UPS operating parameters can be managed by entering the various sections of the control panel from the Home page directly. 13.1 Displaying the measures Press on the Measures icon to enter the main page. Picture 33 –...
  • Page 187 The list of all the available measures is given below. Sub-page Displayed data Accuracy Rectifier input voltage Rectifier input current INPUT Frequency 0,1 Hz Input power 1 kVA Voltage Current Load percentage OUTPUT Active power 1 kW Apparente power 1 kVA Frequency 0,1 Hz Voltage...

  • Page 188: Basic Diagnostics

    13.2 Basic diagnostics Pressing the Alarms icon will open the page where either the UPS operating status or the history log can be selected. Picture 35 – ALARMS section 13.2.1 Displaying the operating status Press UPS status to show the UPS operating status, which includes possible active alarms. Picture 36 –...
  • Page 189 13.2.2 Icons colours The icons Alarms and Home take on different colours on the basis of both the UPS operating condition and the displayed page. Icon Colour Meaning Light blue No active alarms Dark blue No active alarms Grey A page of the Alarms section is currently displayed Active alarm;...
  • Page 190 The first event shown is the latest one in order of time; a new event makes all the other events automatically shift one position, clearing the oldest event. Each line shows the number of the event (position within the list), the alarm code and date and time; an asterisk indicates the automatic reset of the alarm.
  • Page 191 ALARMS MAINS FAULT MAINTENANCE REQ INPUT WRONG SEQ COMMON ALARM BOOSTER STOPPED MBCB BUS CLOSED BOOSTER FAULT EPO BUS CLOSED DC VOLTAGE FAULT ASYMMETRIC LOAD BATTERY IN TEST SERVICE REQUIRED BCB OPEN DIESEL MODE BATTERY DISCHARGE DC FASTSHUTDOWN BATTERY AUT END INV -->...
  • Page 192 Display and recording mode of alarms  The statuses are always displayed in ascending order when the ALARMS – STATUS menu is entered.  The alarms are shown when they are present and must be silenced with the buzzer.  The alarms remain displayed whilst they are present and they are automatically stored in the event log with date and time.

  • Page 193: Settings And Advanced Operations

    13.3 Settings and advanced operations Pressing the Settings icon will show the setting section access page, protected by password. Picture 40 – Access password to the Settings section Picture 41 – SETTINGS section, page 1 The arrow in the upper main bar indicates that the section contains further pages. Wärtsilä...
  • Page 194 Picture 42 – SETTINGS section, page 2 Password-protected access The SETTINGS menu is protected by a password set by the factory in order to prevent access to unauthorized personnel.  We recommend minimum disclosure of the access password.  Changes to the operating parameters and starting operations on the UPS may be potentially dangerous for the device and for persons.
  • Page 195 13.3.2 Setting date and time Date and time may be set via the CLOCK page. Picture 43 – Clock manual setting Setting the current date and time correctly The correct setting of the date and time is essential for the recording of the event log. The system also allows the setting of a NTP server for the synchronization of date and time.
  • Page 196 Picture 44 – Clock automatic setting The NTP server access parameters can be configured via the Network configuration pages in the Settings section. In case the server does not respond or the LAN connection is lacking, the message NTP ERROR will be displayed. 13.3.3 Setting the display language The following picture shows the languages that can be set.
  • Page 197 13.3.4 Resetting the history log The history log can be reset by entering the HISTORY RESET section; the operation requires a further confirmation. Loss of data The alarms history contains very important data to monitor the device behaviour over time. We recommend to save the data before deleting it.
  • Page 198 The various parameters setting pages are similar to each other and requires the operator to enter and confirm the value; the setting page of the battery capacity is given below as a reference. Picture 47 – Battery parameters setting 13.3.8 Battery test The BATTERY TEST section allows to carry out a short discharge test of the battery.
  • Page 199 Picture 48 – Touch screen network parameters setting 13.3.9.1 Setting the LAN parameters The LAN network parameters which can be set are the following:  IP address  Network mask  Network gateway  Primary DNS server  Secondary DNS server ...
  • Page 200 13.3.9.2 Setting the NTP parameters The NTP service parameters which can be set are the following:  Primary NTP server address  Primary NTP server address  NTP Enabling / Disabling Picture 50 – NTP parameters setting 13.3.9.3 Modifying the parameters The modification of the parameters is performed pressing on the field that is to be modified;...
  • Page 201 The fields related to the NTP servers may either be numerical (IP address of the remote server) or alphanumerical when the remote server can be reached via a web address. In such case the keypad that will appear in the page is complete. Picture 52 –...

  • Page 202: System Information

    13.4 System information The INFO section provides general information about the UPS; press the related icon to open the main page. Picture 53 – INFO section All the data shown in the various sections are set during the factory test via a specific interface software and cannot be modified by anyone, except for personnel authorized by the manufacturer.
  • Page 203 Sub-page Displayed data Serial number assigned by the manufacturer and by a SERIAL NUMBER possible OEM distributor DEVICE TYPE Device type (ON LINE, ECO,ecc.) It may be SINGLE, or PARALLEL in case the system is in MODE OPERATION parallel with other UPS's RUNNING HOURS Equipment operating hours CLOCK...
  • Page 204 13.4.2.3 System status (communication bus monitoring) This field gives a general indication regarding the communication between the UPS units composing the system.  The numbers represent the single UPS units.  The letters M and S stand for MASTER and SLAVE respectively. ...
  • Page 205 13.4.3 Firmware release Picture 57 – Firmware release The second page of the firmware release info contains the license contract related to the touch screen operating software. 13.4.4 Service information The SERVICE menu provides important information regarding the technical service on the UPS. The information is displayed via a text string which chows the contact main details.

  • Page 206: Faults And Alarms

    14 Faults and Alarms As indicated in the previous chapters, the system is provided with basic diagnostics which allow immediate visualization of the operating conditions. The alarms icon turns red and the buzzer is activated (if enabled). The UPS status page shows the alarm code and a brief description of the alarm itself.

  • Page 207: Operating Status Definition

    14.1 Operating Status Definition BOOSTER OK Status Description The rectifier section is working properly. Operating The rectifier supplies the inverter and keeps the battery charged. condition BATTERY OK Status Description The battery is connected to the UPS. Operating The battery is kept charged by the rectifier and is ready to feed the inverter. condition INVERTER OK Status...

  • Page 208: Troubleshooting

    14.2 Troubleshooting MAINS FAULT Alarm Description The voltage or frequency of the input line are out of tolerance. Possible  Mains instability or failure. causes  Wrong phase rotation. Solutions 1. Check the connections to the mains. 2. Check the stability of mains voltage. 3.
  • Page 209 BCB OPEN Alarm Description The battery isolator is open. Possible  Battery isolator open. causes Solutions 1. Check the status of the battery isolator. 2. Check the functionality of the auxiliary contact of the isolator. 3. Check the connection between the auxiliary contact of the isolator and the auxiliary terminals of the UPS (if provided).
  • Page 210 BYPASS WR SEQ Alarm Description The phase rotation of the bypass line is wrong. Possible  Wrong connection of power cables. causes Solutions 1. Check the phase rotation. 2. If the alarm persists, contact our Technical Support Service. BYPASS FAULT Alarm Description The voltage or frequency of the bypass line are out of tolerance.
  • Page 211 THERMAL IMAGE Alarm Description The thermal image protection has been activated after an extended inverter overload. The inverter is shut down for 30 minutes and then restarted. Possible  Output overload. causes  Measuring circuit failure. Solutions 1. Check the loads connected to the UPS output. 2.
  • Page 212 CRITICAL FAULT Alarm Description An alarm has been activated which causes the shutdown of part of the UPS (rectifier, inverter, static switch). Possible  System failure. causes Solutions 1. Check which alarms are present and carry out the indicated procedures. 2.
  • Page 213 DC FASTSHUTDOWN Alarm Description Inverter shutdown due to the operation of the protection sensor as a result of sudden DC voltage variations. Possible  Battery fault. causes Solutions 1. Check the battery. 2. Reset the system. 3. If the alarm persists, contact our Technical Support Service. Alarm INV -->...
  • Page 214 PAR LOST REDUND Alarm Description This alarm is only active on PARALLEL systems. Continuity is not ensured in the event of a fault on one of the UPS units. Possible  The total load is higher than the maximum expected value. causes ...
  • Page 215 PAR CABLE DISC Alarm Description Parallel cable doesn't communicate. Possible  Parallel cable disconnected or damaged. causes Solutions 1. Check the connection of cable 2. Contact our Technical Support Service. MAINS UNBALANCE Alarm Description The rectifier input voltage is unbalanced. Possible ...

  • Page 216: Technical Data

    15 Technical Data JOVYSTAR COMPACT L Online UPS-Type 200 kVA Output Output apparent power (cos φ = 1) 200 kVA Output active power (cos φ = 1) 200 kW Rated output voltage 3 x 380/220 V/3 x 400/230 V/3 x 415/240 V - Tolerance static, symmetric load ±1 % - Tolerance static, asymmetric load...

  • Page 217: Service And Download

    16 Service and Download Following documents are available at our website:  Battery data sheets  Battery operating instructions Material safety data sheet  CE – Compliance Declaration  http://www.jovyatlas.com/ja/Waertsilae-JOVYSTAR-COMPACT,120-93-2 http://www.jovyatlas.com/Batteries S E R V I C E – H O T L I N E ! Telefon: 04958 - 9394 - 30 Telefax: 04958 - 9394 - 10 E-Mail:...

Table of Contents
