- Page 1 947AV METAL LATHE Original: Operating Instructions France Schweiz / Suisse JPW (TOOL) AG TOOL France / PROMAC Tämperlistrasse 5 57, rue du Bois Chaland, Z.I. du Bois Chaland CH-8117 Fällanden Switzerland case postale 2935 FR-91029 Evry Cedex www.promac.ch www.promac.fr M-BD-947VA-M...
- Page 2 CE‐Conformity Declaration CE‐Konformitätserklärung Déclaration de Conformité CE Product / Produkt / Produit: Metal Lathe Metalldrehbank Tour à métaux 947VA Brand / Marke / Marque: PROMAC Manufacturer / Hersteller / Fabricant: JPW (Tool) AG, Tämperlistrasse 5, CH‐8117 Fällanden Schweiz / Suisse / Switzerland We hereby declare that this product complies with the regulations Wir erklären hiermit, dass dieses Produkt der folgenden Richtlinie entspricht Par la présente, nous déclarons que ce produit correspond aux directives suivantes 2006/42/EC Machinery Directive Maschinenrichtlinie Directive Machines 2014/30/EU electromagnetic compatibility elektromagnetische Verträglichkeit compatibilité électromagnétique designed in consideration of the standards und entspechend folgender zusätzlicher Normen entwickelt wurde et été développé dans le respect des normes complémentaires suivantes EN ISO 12100:2010 EN ISO 23125:2015 EN 60204‐1:2006+A1:2009 EN 61000‐6‐2:2005 EN 61000‐6‐4:2007+A1:2011 Responsible for the Documentation / Dokumentations‐Verantwortung / Résponsabilité de Documentation: ...
-
Page 4: Table Of Contents
Table of Contents INTRODUCTION........................4 MAIN PARAMETERS……………………………………………………………………..5 SECTION 1: SAFETY.......................7 SECTION 2: POWER SUPPLY....................9 Availability………………………………………………………………………9 Circuit Requirements…………………………………………………………..9 Grounding & Plug Requirements…………………………………………….10 Extension Cords……………………………………………………………….10 SECTION 3: SETUP……………………………………………………………………...…11 Unpacking……………………………………………………………………...11 Inventory………………………………………………………………………11 Clean Up……………………………………………………………………….12 Installation Dimensions……………………………………………………….12 Check Gearbox Oil……………………………………………………………12 Open the Cover………………………………………………………………..13 Install belt and Chang speeds………………………………………………...13 Test Run Lathe………………………………………………………………...14 SECTION 4: OPERATE……………………………………………………………………..15 General…………………………………………………………………………15... -
Page 5: Introduction
IDENTIFICATION The following is a list of controls and components on the lathe. Please take time to become familiar with each term and its location. These terms will be used throughout the manual and knowing them is essential to understanding the instructions and terminology used in this manual. -
Page 6: Main Parameters
Model 947VA Main Parameters Product Dimensions: Weight..........................315 kg Width (side-to-side) x Depth (front-to-back) x Height........140x 53 x 129 cm Shipping Dimensions: Type..........................Wood Crate Content..........................Machine Weight..........................387 kg. Length x Width x Height..................163 x 86 x 155.cm Electrical: Minimum Circuit Size......................12 amp Switch........................Forward/Reverse... - Page 7 Tailstock Info Tailstock Taper........................MT#3 Tailstock Barrel Diameter....................Φ38 mm Tailstock Barrel Travel......................80mm Threading Info of Metric Lathe Number of Longitudinal Feeds....................14 Range of Longitudinal Feeds..................0.03 – 0.3 mm. Number of Cross Feeds......................14 Range of Cross Feeds..................0.015 – 0.15 mm Number of Inch Threads......................
-
Page 8: Section 1: Safety
SECTION 1: SAFETY READ MANUAL BEFORE OPERATING MACHINE. FAILURE TO FOLLOW INSTRUCTIONS BELOW WILL RESULT IN PERSONAL INJURY. Standard Safety Instructions 1. Thoroughly read the Instruction Manual before operating your machine. Learn the applications, limitations and potential hazards of this machine. Keep the manual in a safe and convenient place for future reference. - Page 9 12. Do not force tool. The machine will do a safer and better job at the rate for which it was designed. 13. Use correct tool. Do not force machine or attachment to do a job for which it was not designed. 14.
-
Page 10: Section 2: Power Supply
ECTION 2: POWER SUPP LY Availability Circuit Requirements Before installing the machine, consider the This machine is prewired to operate on a availability and proximity of the required 110V power supply circuit that has a power supply circuit. If an existing circuit verified ground and meets the following does not meet the requirements for this requirements:... -
Page 11: Grounding & Plug Requirements
Grounding & Plug Requirements This machine MUST be grounded. In the event of certain malfunctions or Voltage:220V-240V Minimum Gauge Size....2 mm ² breakdowns, grounding reduces the risk of electric shock by providing a path of least Maximum Length………………….6 m. resistance for electric current. This machine is equipped with a power cord that has an equipment-grounding wire and a grounding plug. -
Page 12: Section 3: Setup
ECTION 3: SETUP This machine presents serious injury Inventory hazards to untrained users. Read through this entire manual to become familiar with The following is a description of the main the controls and operations before starting components shipped with your machine. the machine! Lay the components out to inventory them. -
Page 13: Clean Up
Clean Up The unpainted surfaces are coated with a waxy oil to prevent corrosion during shipment. Remove this protective coating with a solvent cleaner or degreaser. For thorough cleaning, some parts must be removed. For optimum performance, clean all moving parts or sliding contact surfaces. -
Page 14: Open The Cover
Open the Cover Note: Must wipe on the pulley Lift the lock handle and counter clockwise, oil before installation . open the cover. See Figure 3 LOCK Figure 3 Install belt and Chang speeds Belt is not installed in the lathe, You need to install their own. -
Page 15: Test Run Lathe
11. Flip up the emergency stop button, the Test Run Lathe lathe stops. Allow the lathe to run for at least two full minutes to make sure it is running Before continuing to Operate, test run satisfactorily and the chuck is turning the lathe to make sure it runs properly. -
Page 16: Section 4: Operate
SECTION 4: OPERATE General The Model BD-12 will perform many types of operations that are beyond the scope of this manual. Many of these operations can be dangerous or deadly if performed incorrectly. The instructions in this section are written with the understanding that the operator has the necessary knowledge and skills to operate this machine. -
Page 17: Removing/Installing Chuck Or Faceplate
Removing/Installing Chuck or Faceplate The BD-12 lathe is shipped with a 3-jaw chuck installed, but also includes a 4-jaw chuck and 10" faceplate. The chucks and faceplate mount to the spindle with a D1-4 cam lock system, which uses a key to loosen and tighten cam locks for removal or installation. -
Page 18: Dead Centers
interlock when dirt or oil are present on the mounting surfaces. 3. Extend the quill approximately 1". 4. Slide the dead center into the tailstock quill as Shown in Figure 13 . Figure 10. locking chuck — If the cam lock mark stops outside of the Quick Lock “V”... -
Page 19: Tailstock Positioning
Tailstock Positioning Longitudinal Positioning To adjust the tailstock longitudinally, do these steps: 1. Loosen the tailstock Quick lock shown in Figure 14. 2. Slide the tailstock into position along the bed, then tighten the clamp nut to secure the tailstock in the new position. Offset Positioning Figure 14 .Tailstock positioning controls. -
Page 20: Cross Slide
4. Use the compound slide handwheel to move Cross Slide the tool back and forth along the axis of the The cross slide moves perpendicular to the new angle. Similar to adjusting the cross slide longitudinal axis and features a scale on the handwheel, make sure the threads are engaging handwheel that displays graduations of one and all backlash has been cleared before you set... -
Page 21: Carriage Handwheel
move the carriage manually or with the power Carriage Handwheel feed. The carriage handwheel (Figure 14)moves the carriage left or right along the bed. This manual control is necessary when setting up the machine for turning or when manual movement is desired during turning operations. -
Page 22: Threads And Change Gears
Threads and Change gears Figure 24 Change Gears Do not change direction when the lathe is running, please turn the stop button , then change the needed direction . If not ,you will be in danger. We advise you to adjust the speed to 125r/min when you make thread ,and the screw relief Figure 23 metric chart groove must be three times than screw pitch at... -
Page 23: Clutch Overload
Clutch Overload This machine is furnished with Clutch Overload protection device. When it’s loaded over or the slide touch Stopping plate , this device will work and stop the feeding of the cutter. Clutch overload protection device can adjust and rotate, The Adj. Nut can adjust the torch of the overload. See Figure 26 ，The Adj. -
Page 24: Section 5: Maintenance
SECTION 5: MAINTENANCE Lubrication Your lathe has numerous moving metal-to- metal contacts that require proper lubrication to help ensure efficient and long-lasting operation. Other than the lubrication points covered in this section, all other bearings are internally lubricated and sealed at the factory. Simply leave them alone unless they need to be replaced. -
Page 25: Feed Rate Gearbox Oil Reservoir
Feed Rate Gearbox Oil To change the oil in the reservoir: Reservoir Lubricant Frequency 1. DISCONN ECT LATHE FROM POWER! ISO 68 or Check/ Half-Way 2. Remove the reservoir fill plug (see Equivalent Fill Every 8 Mark in Figure 31). Lubricant Hours Sight Glass... -
Page 26: Gibs
Gibs There are three gib adjustments for the Model C8—the cross-slide gib, the compound slide gib, and the saddle gib. Cross-slide Gib—The gib on the cross-slide is adjusted by tightening or loosening the five gib screws located on the right-hand side of the slide (shown in Figure 32). -
Page 27: Bearing Preload
Bearing Preload 6. Place a wooden block over the outboard end of the spindle, and hit it soundly with This lathe is shipped from the factory with the the heavy dead blow hammer (see Figure spindle bearing preload properly adjusted. If 37). - Page 28 6. Turn the spindle OFF, disconnect the lathe from power, then check the temperature of the spindle. — If the spindle nose is slightly warm to the touch, you have correct bearing preload. — If the spindle nose is hotter than you can comfortably keep your hand on, the preload is too tight and you must repeat the bearing preload adjustment procedure.
- Page 29 Garantie Wir gewähren Ihnen auf den unten eingetragenen Artikeln Garantie auf die Dauer von 24 Monaten ab Laufdatum. Einzige Voraussetzung: die- eingesandten Maschine beigefügt sein. Par ce document nous nous engageons à réparer l‘article mentionné ci- dessous en garantie pendant une période de 24 mois à partir de la date plété...
