- Page 1 100T-CP Cathodic Protection Telemetry Module Installation Guide TDC-1344-000...
- Page 2 All product returns must be shipped by ground transportation. Modifications and Repairs To ensure system performance, this device and antenna shall not be changed or modified without the expressed approval of Itron. Any unauthorized modification will void the user's authority to operate the equipment.
- Page 3 Suggestions If you have comments or suggestions on how we may improve this documentation, send them to TechnicalCommunicationsManager@itron.com If you have questions or comments about the software or hardware product, contact Itron Technical Support: Contact Internet: www.itron.com • E-mail: support@itron.com •...
-
Page 5: Table Of Contents
100T-CP Telemetry Module Specifications ..................2 Related Documents ........................2 Installation Prerequisites ........................3 Chapter 2 Mounting the 100T-CP Module on the Test Station Post ......4 Mounting Screw Specifications ......................4 Mounting Installation Considerations ....................4 Mounting the 100T-CP Module on the Test Station Pipe ..............5 Chapter 3 Connecting the 100T-CP Module to the Test Station ...... -
Page 6: Before You Begin
Note A Note supplies generic information to the user. The user could ignore the information and continue a task without suffering any adverse consequences. Document Purpose This installation guide provides instructions for installing the 100T-CP cathodic protection telemetry module. TDC-1344-000 100T-CP Cathodic Protection Telemetry Module Installation Guide Proprietary and Confidential... -
Page 7: Chapter 1 100T-Cp Cathodic Protection Telemetry Module Overview
The 100T-CP telemetry module was developed in cooperation with the Gas Technology Institute. 100T-CP telemetry modules operate in two distinct modes which are mutually exclusive but similar to other 100S devices. It is possible to transition between mobile and fixed network modes using a command. -
Page 8: 100T-Cp Telemetry Module Specifications
100 Series Modules and CENTRON Bridge Meter Tamper Reference Guide TDC-1028-XXX* *The last three digits of the user and installation guides represent the document's revision level. The revision level is subject to change without notice. TDC-1344-000 100T-CP Cathodic Protection Telemetry Module Installation Guide Proprietary and Confidential... -
Page 9: Installation Prerequisites
100T-CP Cathodic Protection Telemetry Module Overview Installation Prerequisites The following tools are required to install, program, and check the 100T-CP module. Specific tools may be required for some installation locations. • Medium flat-blade screwdriver • Medium Phillips screwdriver • Hand pliers •... -
Page 10: Chapter 2 Mounting The 100T-Cp Module On The Test Station Post
Mounting Installation Considerations Mount the 100T-CP in a vertical position on the test station pipe with the telemetry module label directional arrow pointed upward. Caution Upright vertical positioning is very important because: •... -
Page 11: Mounting The 100T-Cp Module On The Test Station Pipe
The module's tilt tamper functionality is designed to operate with the module installed vertically. 1. Drill a 3/16" hole for the 100T-CP cable in the riser post 1-1/2" below the test station base. Caution Protect wires within riser post from damage when the hole is drilled. - Page 12 2. Remove the pipe bracket and band clamp from the hardware kit (Itron part number CFG-5006-701). 3. Loosen the band clamp screw until the end of the band releases. 4. Push the end of the clamp's band through the holes in the pipe bracket. Itron suggests orienting the pipe bracket as shown below.
- Page 13 9. Insert the adapter plate mounting screws. Tighten the screws in an alternating pattern. 10. Route the 100T-CP cable through the channel in the standoff on the backplate. 11. Route the cable on the left of the mounting post slot.
- Page 14 13. Slide the 100T-CP module mounting post slot onto the mounting post on the adapter plate. Align the 100T-CP mounting screw holes with those on the adapter plate. Verify the cable is on the left side of the mounting post slot.
- Page 15 Mounting the 100T-CP Module on the Test Station Post 15. Install the tamper seals in the screw mounting cups. A tamper seal is correctly seated when it is recessed 1/16" into the cup. TDC-1344-000 100T-CP Cathodic Protection Telemetry Module Installation Guide...
-
Page 16: Chapter 3 Connecting The 100T-Cp Module To The Test Station
This section provides the instructions to connect the 100T-CP to the cathodic protection test station. Buried Reference Cell Installation The 100T-CP must be connected to a Cu-CuSO4 reference cell designed for burial to measure pipe to soil voltage. The reference cell must be purchased from a third-party vendor and installed according to the manufacturer's specifications. - Page 17 Avoid eye contact. Avoid prolonged or repeated skin contact. Contact Itron Support for Material Safety Data Sheets (MSDS). 4. Insert the red wire from the lightning suppressor and the red wire from the 100T-CP into a gel connector. Crimp the connector.
-
Page 18: Programming The 100T-Cp
Program the Utility ID into the 100T-CP using the handheld computer. Optionally, you can program the 100T-CP to enable the enhanced security key, Test Station ID, and voltage reading Capture Hour. For all programming and Check Endpoint operations, hold the handheld within six feet of the target telemetry module and as close to vertical as possible.
