GetKCubeTriggerParams
GetOutputLUTParams
GetOutputLUTTrigParams
GetOutputLUTValue
GetVoltOutput
GetVoltageOutputLimit
Identify
LLGetStatusBits
LLSaveHWDefaults
LoadParamSet
SaveParamSet
SetControlMode
SetDispIntensity
SetHubAnalogueChanIn
SetIPSource
SetJogStepSize
SetKCubePanelParams
SetKCubeTriggerParams
SetOutputLUTParams
SetOutputLUTTrigParams
SetOutputLUTValue
SetVoltOutput
SetPosOutput
SetVoltageOutputLimit
ShowEventDialog
StartCtrl
Sets the triggering parameters
Gets the output voltage waveform (LUT) operating
parameters.
Gets the output voltage waveform (LU T) triggering
parameters.
Gets a specific voltage output va lue in the voltage
waveform (LUT) table.
Gets the HV output voltage.
Gets the HV output voltage maximum limit.
Identifies the controller by flashing unit LEDs.
Gets the controller status bits encoded in 32 bit
integer.
Allows the current
parameters to b e saved into the onboard 'Flash'
memory of the hardware unit.
Loads stored settings for specific controller.
Saves settings for a specific controller.
Sets the loop operating mode (open/closed).
Sets the front panel LED display intensity.
Sets the hub analogue input channel used for close
loop operation.
Sets the HV amplifier input source.
Sets the jogging step size.
Sets various parameters for the top panel controls
Sets the triggering parameters
Sets the output voltage waveform (LUT) operating
parameters.
Sets the output voltage waveform ( LUT) triggering
parameters.
Sets a specific vo ltage output value in the voltage
waveform (LUT) table.
Sets the HV output voltage (open loop).
Sets the output position (closed loop).
Sets the HV output voltage maximum limit.
Shows the event dialog when it has previously been
disabled using the EnableEventDlg method
Starts the ActiveX Co ntrol (starts com munication
with controller)
K-Cube Piezo Driver
settings of the operation
