Seneca Z-LOGGER User Manual

Multi-protocol datalogger/rtu with gsm/gprs modem and embedded i/o / multi-protocol datalogger/rtu with embedded i/o
Hide thumbs Also See for Z-LOGGER:
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
Z-GPRS2-SEAL
Z-LOGGER-SEAL
Multi-protocol Datalogger/RTU with GSM/GPRS modem and embedded I/O
Multi-protocol Datalogger/RTU with embedded I/O
SENECA s.r.l.
Via Austria 26, PADOVA – ITALY
Tel. +39.049.8705355 – 8705359 Fax. +39.049.8706287
Web site:
www.seneca.it
Customer service:
(Other)
Commercial information:
(Other)
This document is property of SENECA srl. Duplication and reproduction of its are forbidden
(though partial), if not authorized. Contents of present documentation refers to products and
technologies described in it. Though we strive for reach perfection continually, all technical data
contained in this document may be modified or added due to technical and commercial needs;
it's impossible eliminate mismatches and discordances completely. Contents of present
documentation is anyhow subjected to periodical revision. If you have any questions don't
hesitate to contact our structure or to write us to e-mail addresses as above mentioned.
Z-GPRS2-SEAL
Z-LOGGER
supporto@seneca.it
(IT),
commerciale@seneca.it
MI003574_EN
Page 1
support@seneca.it
(IT),
sales@seneca.it

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z-LOGGER and is the answer not in the manual?

Questions and answers

Related Manuals for Seneca Z-LOGGER

Summary of Contents for Seneca Z-LOGGER

  • Page 1 (Other) This document is property of SENECA srl. Duplication and reproduction of its are forbidden (though partial), if not authorized. Contents of present documentation refers to products and technologies described in it. Though we strive for reach perfection continually, all technical data contained in this document may be modified or added due to technical and commercial needs;...
