Z-GPRS3
GSM/GPRS datalogger with built-in
telecontrol functions and advanced programming language
EN
EN
Headquarters: Via Austria, 26 – 35127 – PADOVA – ITALY
Phone +39.049.8705355 - 8705359 - Fax +39.049.8706287
Manuals and configuration software are available at website: www.seneca.it/products/z-gprs3
This document is property of SENECA rl. Duplication and reproduction are forbidden, if not authorized.
Contents of the present documentation refers to products and technologies described in it.
This informations may be modified or integrated for technical and / or commercial requirements.
MI004402-E
INSTALLATION MANUAL
SENECA s.r.l.
S
ENGLISH LANGUAGE INSTRUCTIONS
HW2
I/O
s,
ENGLISH - 1/8
Advertisement
Related Manuals for Seneca Z-GPRS3 HW2
Summary of Contents for Seneca Z-GPRS3 HW2
- Page 1 Phone +39.049.8705355 - 8705359 - Fax +39.049.8706287 Manuals and configuration software are available at website: www.seneca.it/products/z-gprs3 This document is property of SENECA rl. Duplication and reproduction are forbidden, if not authorized. Contents of the present documentation refers to products and technologies described in it.
-
Page 2: Technical Specifications
TECHNICAL SPECIFICATIONS EN61000-6-4 Electromagnetic emission, industrial environment EN61000-6-2 Electromagnetic immunity, industrial environment. EN301 511 Harmonized standard for mobile stations STANDARDS EN301 489-1 ElectroMagnetic Compatibility for radio equipment EN301 489-7 Specific (EMC) conditions for mobile radio equipment EN60950 Safety of information Technology Equipment. DI 1 Communication DI 2... -
Page 3: Preliminary Warnings
The module may only be used by qualified and skilled technicians in the field of electric installation. Specific documentation is available for download at website: .seneca.it/products/z- gprs3 Only the Manufacturer is authorized to repair the module or to replace damaged parts. - Page 4 13 14 15 1 2 3 (the insertion is one way only because the connectors 16 17 18 4 5 6 SENECA D 2 I are polarized). D 3 I D 4 I 3) To secure the module to the IEC EN 60715 DIN rail,...
-
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS Warning : The powersupply upper limits must not be exceeded in order to avoid serious damage to the module. Power off the module, with the PS1 button, before connecting the inputs and outputs. In order to satisfy the electromagnetic compliance requirements: - Use shielded cables for the signals transmission;... - Page 6 MODULE LAYOUT 35 mm Dimensions (L×H×W) 35 x 102,5 x 111 mm (with terminals). Weight 250 g. Case Material PA6, black color. LED SIGNALING ON FRONT PANEL Status LED’s meaning Digital output 1, relay energized (Red) Digital output 1, relay de-energized Digital output , relay energized (Red) Digital output , relay de-energized...
- Page 7 LED SIGNALING ON FRONT PANEL Status LED’s meaning ON (NPN) Digital Input 1: Energized ( closed contact ON (PNP) Digital Input 1: Energized ( +12V closed contact (Red) Digital Input 1: De-energized (open contact) ON (NPN) Digital Input : Energized ( closed contact ON (PNP) Digital Input : Energized (...
- Page 8 DIN rail with one slot support for rear connector P= 35 mm. EXTERNAL GSM For information on models of GSM and GPRS satellite antennas, access ANTENNA the website: www.seneca.it/products/z-gprs3 to the accessories section FD01 Photodetector for pulse counter, MAX frequency 10 Hz CONTACTS Technical support support@seneca.it...
