Seneca MyAlarm SEAL Installation Manual

Gsm/gprs datalogger with built-in i/os, telecontrol functions and advanced programming language

Advertisement

Quick Links

MyAlarm SEAL
GSM/GPRS datalogger with built-in I/Os,
telecontrol functions and advanced programming language
E
E
Tel. +39.049.8705355 - 8705359 - Fax +39.049.8706287
For manuals and configuration soft ware, visit www.seneca.com/myalarm-seal
This document is the property of SENECA srl. Copies and reproduction are prohibited unless authorised.
The content of this document corresponds with the products and technologies described. Data herein may
be modified or supplemented for technical and/or sales purposes.
MI00500-1-EN
INSTALLATION MANUAL
SENECA s.r.l.
Via Austria, 26 – 35127 – PADOVA – ITALY
INSTRUCTIONS IN ORIGINAL LANGUAGE
ENGLISH - 1/8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MyAlarm SEAL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Seneca MyAlarm SEAL

  • Page 1 Tel. +39.049.8705355 - 8705359 - Fax +39.049.8706287 For manuals and configuration soft ware, visit www.seneca.com/myalarm-seal This document is the property of SENECA srl. Copies and reproduction are prohibited unless authorised. The content of this document corresponds with the products and technologies described. Data herein may be modified or supplemented for technical and/or sales purposes.
  • Page 2: Preliminary Warnings

    Polycarbonate / ABS material. Weight Case LED SIGNALS ON THE FRONT PANEL STATUS LED MEANING Off MyAlarm SEAL off Network search  No signal  Fast flash (64 ms ON / 800 ms OFF) SIM card with incorrect pin ...
  • Page 3: Technical Specifications

    STANDARDS ETSI EN 301 489-7 - EN301 511 - EN301 489-1 - IEC / EN 60950 ENVIRONMENTAL CONDITIONS Seneca recommends use at 0 to 45 ° C for correct operation. Temperature With the power supply present: - 20 .. + 55 °C.
  • Page 4: Inserting The Sim Card And Sd Card

    INITIAL POWERING ON OF THE DEVICE MyAlarm SEAL is supplied in shipping mode. This mode allows you not to unnecessarily discharge the battery during transport and to prevent accidental switching on. In order to exit this mode, simply supply power to the device via USB cable or power supply cable.
  • Page 5: Installation Rules

    ASSEMBLY STANDARDS For optimum reception of the GPS signal from satellites, it is best to place the MyAlarm SEAL in an area not covered by metal structures. If this is not possible, an optional external antenna with 3m cable (code AGPS) is available.
  • Page 6: Electrical Connections

    ELECTRICAL CONNECTIONS INSERTION AND REMOVAL FROM THE TERMINALS WITH PUSH-WIRE CONNECTION Insertion of Insertion of Extraction a flexible cable of a cable a solid cable A Press down with A Press down with the screwdriver the screwdriver Push the Suggested wire down wire stripping: B Pull up...
  • Page 7 FUNCTIONS AND USE OF THE DISPLAY The main MyAarm SEAL display page provides the following informa on: A - GSM signal level B = Output 1 status C = Output 2 status D = Digital input 1 status E = Digital input 2 status F = Digital input 3 status G = Digital input 4 status H = Battery charge level...
  • Page 8: Order Code

    G = present S = special ACCESSORIES OPTIONAL ACCESSORIES A-GPS External GPS antenna with 3 m cable A-GSM/QUAD-N External GSM / QUAND-N antenna with 5 m cable NTC EXTERNAL TERMISTOR CONTACTS Technical support support@seneca.it Product information sales@seneca.it  ENGLISH - 8/8...
