INSTALLATION MANUAL
Z-UMTS
HW2
HSPA datalogger + with built-in I/O, remote control functions
built-in UPS, GPS and advanced programming
EN
SENECA s.r.l.
Via Austria, 26 - 35127 - PADOVA – ITALY
Tel. +39.049.8705355 - 8705359 - Fax +39.049.8706287
For manuals and configuration software, go to www.seneca.it/products/z-umts
This document is the property of SENECA srl. Copies and reproduction are prohibited unless authorised.
The content of this document corresponds to the described products and technologies.
Stated data may be modified or supplemented for technical and/or sales purposes.
INSTRUCTIONS IN ORIGINAL LANGUAGE
MI00499-1-EN
ENGLISH - 1/8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z-UMTS HW2 and is the answer not in the manual?

Questions and answers

Related Manuals for Seneca Z-UMTS HW2

Summary of Contents for Seneca Z-UMTS HW2

  • Page 1 Tel. +39.049.8705355 - 8705359 - Fax +39.049.8706287 For manuals and configuration software, go to www.seneca.it/products/z-umts This document is the property of SENECA srl. Copies and reproduction are prohibited unless authorised. The content of this document corresponds to the described products and technologies.

  • Page 2: Module Layout

    MODULE LAYOUT Dimensions (LxHxD) 35 x 102.5 x 111 mm Weight 220 g Case PA6 material, black. LED SIGNALS ON THE FRONT PANEL Status LED meaning On n GSM level 4 nnnnnnnn (maximum signal) GSM level 3 nnn 3 flashes (good) LEVEL Flashing GSM level 2 nn...
  • Page 3 LED SIGNALS ON THE FRONT PANEL Status LED meaning Digital output 1, relay energised (Red) Digital output 1, relay de-energised Digital output 2, relay energised (Red) Digital output 2, relay de-energised Slow flashing nnnnnnnnnnnnnn n0.4s OFF  2.8s ON Activity in the RS485 or RS232 serial interface RS485 or RS232 serial interfaced not used (Red) Fast flashing...

  • Page 4: Technical Specifications

    LED SIGNALS ON THE FRONT PANEL Status LED meaning SD card mounted correctly Medium flashing n nnnnnnnn 0.8 sec ON 0.8 sec OFF Activity on SD card SD (Red) Fast flashing nnnnnnnn 0.2 sec ON 0.2 sec OFF SD card error No SD card ETH LNK Flashing...
  • Page 5 TECHNICAL SPECIFICATIONS POWER SUPPLY Voltage 19 – 40 Vdc or 19 – 28 Vac 50 – 60 Hz. Absorption < 6.5W. Number of channels 4. Configurable PNP or NPN. DIGITAL INPUTS Voltage OFF<4V, ON>8V (Max. 24Vdc). Max frequency 30Hz. Absorbed current 3mA @ 12Vdc 10mA @ 24Vdc. TOTALIZERS 4 x 32-bit totalizers on non-volatile memory COUNTERS:...

  • Page 6: Preliminary Warnings

    WARNING: The full content of this manual must be read before any operation. The module must only be used by qualified electricians. Specific documentation is available at www.seneca.it/products/z-umts. The word WARNING preceded by the symbol indicates conditions or actions that put the ⚠...

  • Page 7: Electrical Connections

    USE OF THE Z-PC-DINAL ACCESSORY Do not turn the module upside down and do not force the insertion of the IDC10 connector on the Z-PC-DIN bus. The rear IDC10 connector of the module must be inserted on a free slot of the Z-PC-DIN bus. The illustration shows the meanings of the various IDC10 connector pins if signals are to be sent via them directly.

  • Page 8: Inserting The Sim Card And Sd Card

    SETTINGS DIP-SWITCHES All DIP switches in OFF position. For further information, refer to the USER MANUAL. RS232 or RS485 configuration on terminals 10-11-12 (COM 2 serial port) RS232 RS485 CONTACT INFORMATION sales@seneca.it support@seneca.it Technical support Product information ENGLISH - 8/8...
