INSTALLATION MANUAL
Z-LTE
Datalogger 4G + with built-in I/O, remote control functions,
embedded UPS,GPS and advanced programming
EN
EN
SENECA s.r.l.
Headquarters: Via Austria, 26 – 35127 – PADOVA – ITALY
Phone +39.049.8705355 - 8705359 - Fax +39.049.8706287
Manuals in other language and configuration software available at: www.seneca.it/products/z-lte
This document is property of SENECA Srl. Any duplication and reproduction are forbidden, unless authorized.
The contents of this documentation refers to the products and technologies described in it.
This informations may be modified or integrated for technical and / or commercial purposes.
MI00514-2-EN
THE ORIGINAL VERSION IS IN ITALIAN LANGUAGE
ENGLISH - 1/8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z-LTE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seneca Z-LTE

Summary of Contents for Seneca Z-LTE

  • Page 1 Phone +39.049.8705355 - 8705359 - Fax +39.049.8706287 Manuals in other language and configuration software available at: www.seneca.it/products/z-lte This document is property of SENECA Srl. Any duplication and reproduction are forbidden, unless authorized. The contents of this documentation refers to the products and technologies described in it.

  • Page 2: Module Layout

    MODULE LAYOUT 111 mm 35 mm Dimensions (L×H×W) 35 x 102.5 x 111 mm Weight 270 g. Case Material PA6, black. LED SIGNALLING ON FRONT PANEL Status LED meaning ON      GSM level 4 (maximum signal) ...
  • Page 3 LED SIGNALLING ON FRONT PANEL Status LED meaning Digital output 1, relay energized (Red) Digital output 1, relay de-energized Digital output 2, relay energized (Red) Digital output 2, relay de-energized  Blinking Slow 2.8s ON  0.4s OFF  RS485 or RS232 serial interface active RS485 or RS232 serial interface not used (Red) ...

  • Page 4: Technical Specifications

    LED SIGNALLING ON FRONT PANEL Status LED meaning SD card mounted correctly Medium Blinking  SD card activity 0.8 sec ON 0.8 sec OFF (Red) Blinking Fast  SD card error 0.2 sec ON 0.2 sec OFF SD card not found ETH LNK Blinking RJ45 connection active...
  • Page 5 PORTS autoswitch on RJ45 frontal socket and USB on MicroUSB side socket. 4G/LTE Model (Europe, Africa, Middle Est, Korea, Thailand, India) Contact Seneca for other countries.. GSM / GPRS/ EDGE Dual-band: 1800 / 900 Mhz MODEM 4G UMTS / HSPA+, Tri-band: WCDMA 2100 / 850 / 900 Mhz...

  • Page 6: Preliminary Warnings

    WARNING: Before performing any operation it is mandatory to read the full contents of this manual. The module may only be used by qualified and skilled electric installation technicians. Specific documentation is available for download at website: www.seneca.it/products/z-lte.  The symbol with the word WARNING identifies conditions and actions that pose hazard(s) to ...

  • Page 7: Electrical Connections

    USE OF Z-PC-DINAL ACCESSORY Don’t turn upside down the module and don’t force the insertion of the IDC10 connector into the Z-PC-DIN bus. The IDC10 connector located on the rear of the module will be inserted in a free slot of the Z-PC-DIN accessory.
  • Page 8 1 2 3 4 5 6 7 8         RS232 or RS485 configuration  ON  OFF on terminals 10-11-12 (serial port COM 2) DEBUG PORT  RS232  RS485 CONTACTS Technical support support@seneca.it Product Informations sales@seneca.it  ENGLISH -8/8...
