Seneca Z-UMTS Installation Manual

Datalogger hspa + with built-in i/o, telecontrol functions, embedded ups and advanced programming language
Hide thumbs Also See for Z-UMTS:

Advertisement

Quick Links

Datalogger HSPA + with built-in I/O, telecontrol functions,
embedded UPS and advanced programming language
EN
EN
Headquarters: Via Austria, 26 – 35127 – PADOVA – ITALY
Phone +39.049.8705355 - 8705359 - Fax +39.049.8706287
Manuals and configuration software are available at website: www.seneca.it/products/z-umts
This document is property of SENECA Srl. Duplication and reproduction are forbidden, if not authorized.
Contents of the present documentation refers to products and technologies described in it.
This informations may be modified or integrated for technical and / or commercial requirements.
MI004531-E
INSTALLATION MANUAL
Z-UMTS
SENECA s.r.l.
ENGLISH LANGUAGE INSTRUCTIONS
ENGLISH - 1/8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z-UMTS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Seneca Z-UMTS

  • Page 1 Phone +39.049.8705355 - 8705359 - Fax +39.049.8706287 Manuals and configuration software are available at website: www.seneca.it/products/z-umts This document is property of SENECA Srl. Duplication and reproduction are forbidden, if not authorized. Contents of the present documentation refers to products and technologies described in it.
  • Page 2: Module Layout

    1112 2324 13 1415 1 2 3 16 17 18 4 5 6 SENECA PWR/ ANTENNA Z-UMTS 19 2021 micro 22 23 24 10 11 12 Dimensions (L×H×W) 35 x 100 x 111 mm (with terminals). 250 g. Weight Case Material PA6, black color.
  • Page 3 Digital Input 4: Energized (GND closed contact) ON (PNP) Digital Input 4: Energized (+12V closed contact) (Red) Digital Input 4: De-energized (open contact) ON  Z-UMTS ON inactive log (status=ready) Slow Blinking  Z-UMTS active log (status=normal) 2.8 sec ON 0.4 sec OFF Slow Blinking ...
  • Page 4: Technical Specifications

    TECHNICAL SPECIFICATIONS EN61000-6-4 Electromagnetic emission, industrial environment. EN61000-6-2 Electromagnetic immunity, industrial environment. EN301 511 Harmonized standard for mobile stations STANDARDS EN301 489-1 ElectroMagnetic Compatibility for radio equipment EN301 489-7 Specific (EMC) conditions for mobile radio equipment EN60950 Safety of information Technology Equipment. IDC10 10 11 12 3000 V...
  • Page 5: Preliminary Warnings

    The module may only be used by qualified and skilled technicians in the field of electric installation. Specific documentation is available for download at website: www.seneca.it/products/z-umts. Only the Manufacturer is authorized to repair the module or to replace damaged parts. The product is susceptible to electrostatic discharge, take appropriate countermeasures during any operation.
  • Page 6 4 5 6 SENECA are polarized). 3) To secure the module to the IEC EN 60715 DIN rail, ANTENNA Z-UMTS 19 20 21 tighten the two hooks on the side of the IDC10 rear 22 23 24 10 11 12 connector as shown in fig.
  • Page 7: Electrical Connections

    ELECTRICAL CONNECTIONS Warning: When you turn On the module for the first time, the device must be supplied without any interruptions for at least 72 hours in order to charge the internal batteries Power off the module, with the PS1 button, before connecting the inputs and outputs. In order to satisfy the electromagnetic compliance requirements: - Use shielded cables for the signals transmission.
  • Page 8: Order Codes

    The picture shows how to Insert the RJ45 connector. USER MANUAL. For further information, refer to the ANTENNA Z-UMTS The module has a serial USB micro port on the lower side. 19 20 21 22 23 24 10 11 12 The picture shows how to Insert the micro USB plug into the micro USB side socket.
