10 MHz Clock Source Checking

There is a TXCO generating a 10 MHz 3.3 V LVCOMS clock source to the
entire channel board. Please check it referring to the marked point on the
channel board drawing.

FPGA Checking

To check if the FPGA is working properly, please observe the test point marked
with FPGA_LED on the channel board drawing. The LED light blinks at a 2 Hz
rate in normal operation. If it does not light cannot be lighted or blinks at an
incorrect frequency, then the FPGA may be fault.

Connector Checking

Table 5-5 Connectors of the Channel Board
Connector
CON_J4
CON_J5
CON_J13
CON_J2
CON_J8
CON_J12
Table 5-5 explains the function of all the connectors on the channel board. It is
important to ensure that all the connections are tight.
1 V
1.5 V
2.5 V
5 V
3.3 V
Function
Communication between the main board and the
channel board.
Communication between the channel board and the
interface board.
Power supply of the channel board.
USB HOST
Communication between the channel board and the Key
and LCD board.
Power supply of the fan.
± 5%
± 5%
± 5%
± 5%
± 5%
