SDG6000X Service Manual
Channel Adjustment
The channel adjustment includes four parts: feedback channel adjustment,
channel self adjustment, vertical accuracy calibration and frequency counter
calibration.
1. Turn on the generator.
2. Connect the DMM, PC and SDG6000X generator as shown below:
3. Double click and run the script ChannelAdjust.py prepared previously.
Then Change the channel connection according to the prompt message.
Note:
If there is a problem in the process of the channel adjustment, you can
separately perform the four parts
adjustment has been completed, perform a self adjustment.
mentioned
above. After the feedback channel
56
WWW.SIGLENT.COM
