Quick Start

SDG800 Series

Function/Arbitrary Waveform Generator

QS02008-E02A

2014 SIGLENT TECHNOLOGIES CO., LTD

Table of Contents

Need help?

Do you have a question about the SDG800 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SIGLENT SDG800 Series

Page 1: Quick Start
Quick Start SDG800 Series Function/Arbitrary Waveform Generator QS02008-E02A 2014 SIGLENT TECHNOLOGIES CO., LTD...
Page 3 ● SIGLENT TECHNOLOGIES CO., LTD. All rights reserved. ● The information provided in this manual replaces all information printed before. ● SIGLENT Company has the rights to change the specification and the price. ● Contents in this manual are not allowed to be copied, extracted and translated without permission by the company.
Page 4: General Safety Summary
SIGLENT General Safety Summary Carefully read the following safety precautions to avoid person injury and prevent damage to the instrument and any products connected to it. To avoid potential hazards, please use the instrument as specified. Only qualified technician should perform service procedures...
Page 5 SIGLENT Safety Terms and Symbols Terms used on the instrument. Terms may appear on the instrument: DANGER: Indicates an injury or hazard that may be immediately happen. WARNING: Indicates an injury or hazard that may be not immediately happen. CAUTIO: Indicates that a potential damage to the instrument or other property might occur.
Page 6: Table Of Contents
SIGLENT Content General Safety Summary..................II Adjustment Handle....................1 The Front Panel ...................... 2 Back Panel....................... 6 User Interface......................7 Using In-line Help System..................9 Contact SIGLENT ....................10 IV SDG800 Quick Start...
Page 7: Adjustment Handle
SIGLENT Adjustment Handle When using the instrument, SDG800 permits users to adjust the handle to a needed position which make it easier to operate and observe. Adjustment Handle Carrying Position Horizontal Position SDG800 Quick Start 1...
Page 8: The Front Panel
SIGLENT The Front Panel The picture below shows SDG800 front panel composition: 5. Waveform Option Area 6. Number Keys 数 7. Knob 3. LCD Display 4. Back Key 2. USB 8. Arrow Host Keys 11. Mode/Utility 9. Channel 1. Power Key...
Page 9 SIGLENT Waveform Option Area Sine ---Sine Waveform Provide sine waveform output and its frequency ranges from 1μHz to 10MHz. The backlight of the key lights when the key is being chosen.  The “Frequency/Period”, “Amplitude/High level”, “Offset/Low level”,  “Phase” of the sine waveform can be adjusted.
Page 10 SIGLENT The backlight of the key lights when the key is being chosen.  The “Frequency/Period”, “Amplitude/High level”, “Offset/Low level”,  “Phase” of the arbitrary waveform can be adjusted. 6. Number Keys Those keys, including numbers from 0 to 9, radix points “.”, symbol keys “+/-”, are used to input parameters.
Page 11 SIGLENT Sweep This key is used to generate “sine waveform”, “square waveform”,  “sawtooth waveform” and “arbitrary waveform” sweep signals. It supports “Linear” and “Log” two kinds of sweep manners.  It supports “Internal” , “Manual” and “External” three kinds of trigger ...
Page 12: Back Panel
SIGLENT The Back Panel 1. AC Power Supply Input SDG800 can input two different kinds of specification AC power supply. AC power: 100—240V, 50/60 Hz or 100—127V, 50/60/440 Hz; Fuse: 1.25AL, 250V 2. USB Device Connect the instrument to a computer through the port, and use software EasyWave to control the SDG800.
Page 13: User Interface
SIGLENT User Interface SDG800 can only display one channel’s parameters and waveform. The picture below shows the interface when choosing sine waveform. The interface will have some difference when current function is different. 1. Current Function Display current function name. For example: “sine” shows that sine waveform function is being chosen.
Page 14 SIGLENT 5. Offset It shows each channel’s current waveform’s DC offset. After press corresponding Offset menu, use number keys or knob to change the parameter value. 6. Phase It shows each channel’s current waveform’s phase value. After press corresponding Phase menu, use number keys or knob to change the parameter value.
Page 15: Using In-Line Help System
SIGLENT Using Built-In Help System To obtain build-in help information of the product, please press Help key first, then use arrow keys to choose the help item you want, last press Select to obtain help information. Press Help key to open the common help information below: 1.
Page 16: Contact Siglent
SIGLENT Contact SIGLENT SIGLENT TECHNOLOGIES CO., LTD Address: 3/F, building NO.4, Antongda Industrial Zone, 3rd Liuxian Road, Bao’an District, Shenzhen, China Tel: +86- 755 -36615186 E-mail: sales@siglent.com http: //www.siglent.com QS02008-E02A 10 SDG800 Quick Start...
