Please read and comply with
these original instructions prior
to the initial operation of your appliance and
store them for later use or subsequent own-
ers.
Contents
Device elements . . . . . . . . . . . EN
Safety instructions. . . . . . . . . . EN
Proper use . . . . . . . . . . . . . . . EN
Safety Devices . . . . . . . . . . . . EN
Environmental protection . . . . EN
Before Startup . . . . . . . . . . . . . EN
Start up . . . . . . . . . . . . . . . . . . EN
Operation . . . . . . . . . . . . . . . . EN
Transport. . . . . . . . . . . . . . . . . EN
Storage . . . . . . . . . . . . . . . . . . EN
Care and maintenance . . . . . . EN
Troubleshooting . . . . . . . . . . . EN
Accessories and Spare Parts . EN
Warranty . . . . . . . . . . . . . . . . . EN
EU Declaration of Conformity . EN
Technical specifications . . . . . EN

Device elements

Please unfold the front picture side
1 Storage compartment for nozzles
2 Handle
3 High-pressure connection EASY!Lock
4 Pressure/ quantity regulation
5 Water connection
6 Oil level indicator
7 Oil tank
8 Cover
9 Power switch
10 Fastening screw for device hood
11 Storage compartment for hoses
12 Trigger gun storage clip
13 Marking of the nozzle
14 Nozzle
15 Spray lance EASY!Lock
16 Trigger gun EASY!Force
17 Safety catch
18 Trigger
19 Safety lever
20 High pressure hose EASY!Lock
21 Push handle
22 Cable clamp
23 Fastening screw for push-handle
4
24 Detergent suction hose with filter
25 Dosage valve for detergent
26 Accessory compartment
27 Hose drum
28 Crank
- The operating elements for the cleaning
1
process are yellow.
1
- The controls for the maintenance and
2
service are light gray.
2
2

Safety instructions

3
- Before first start-up it is definitely nec-
3
essary to read the operating instruc-
4
tions and safety indications Nr. 5.951-
5
949.0!
6
- Please follow the national rules and
6
regulations for fluid spray jets of the re-
6
spective country.
7
- Please follow the national rules and
7
regulations for accident prevention of
7
the respective country. Fluid spray jets
8
must be tested regularly and the results
of these tests must be documented in
writing.
- The appliance/accessories must not be
modified.
DANGER
Pointer to immediate danger, which leads
to severe injuries or death.
WARNING
Pointer to a possibly dangerous situation,
which can lead to severe injuries or death.
CAUTION
Pointer to a possibly dangerous situation,
which can lead to minor injuries.
ATTENTION
Pointer to a possibly dangerous situation,
which can lead to property damage.
Symbols on the machine
High-pressure jets can be danger-
ous if improperly used. The jet may
not be directed at persons, animals, live elec-
trical equipment or at the appliance itself.
- 1
EN
Colour coding
Hazard levels
