These operating instructions apply for:
Important note:
Before use of the pneumatic piston vibrators series NTP read this operating instruc-
tion carefully and store afterwards.
Netter GmbH does not assume any liability for damage to property and persons if
the product has been technically modified or if the notes and regulations of these
operating instructions have not been observed.
This documentation is copyrighted. All rights, e.g. for translation into other lan-
guages, reprinting and copying of these operating instructions or parts hereof re-
main strictly reserved.
Netter GmbH
www.Netter Vibration .com
NetterVibration
Operating Instructions for
Netter Pneumatic Piston Vibrators
Series NTP
Germany
Fritz Ullmann Straße 9
55252 Mainz Kastel
Tel. +49 6134 2901 0
Fax +49 6134 2901 33
info@Netter Vibration .de
NTP 25
NTP 32
NTP 48
United Kingdom
2 Sandpiper Close
Station Road
Hednesford, WS12 4RN
Tel. +44 1543 424990
Fax +44 1543 423196
info@Netter Vibration .co.uk
June 2007
BA No. 803 E
Page 1/16
Switzerland
Erlenweg 4
4310 Rheinfelden
Tel. +41 61 8316200
Fax +41 61 8311291
info@Netter Vibration .ch

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for NetterVibration NTP Series

  • Page 1 NetterVibration Operating Instructions for June 2007 Netter Pneumatic Piston Vibrators BA No. 803 E Series NTP Page 1/16 These operating instructions apply for: NTP 25 NTP 32 NTP 48 Important note: Before use of the pneumatic piston vibrators series NTP read this operating instruc- tion carefully and store afterwards.
  • Page 2: Table Of Contents

    Contents GENERAL NOTES TECHNICAL DATA DESIGN AND FUNCTION SAFETY TRANSPORT AND STORAGE INSTALLATION START-UP / OPERATION SERVICE, MAINTENANCE TROUBLESHOOTING SPARE PARTS APPENDIX 11.1 Accessories 11.2 Disposal 11.3 Enclosures Scope of Delivery: Check the packaging for possible signs of transport damage. In the event of damage to the packaging, check that the contents are complete and undamaged.
  • Page 3: General Notes

    1 General Notes Netter pneumatic piston vibrators series The drive medium is compressed air or NTP comply with the EC machine nitrogen, at a pressure of 1 bar to 6 bar. directive 98/37/EG. Standards DIN EN Series NTP pneumatic piston vibrators ISO 12100 part 1 and part 2 have been can be used for food production and in particularly observed.
  • Page 4: Technical Data

    2 Technical Data Drive medium: Clean (5 µm filter), lubricated compressed air or lubricated nitrogen Unfiltered compressed air will lead to breakdown of the vibrators. Operating pressure: 2 bar to 6 bar The operating pressures must not be exceeded or fallen short of. Timed operation is compulsory for NTP B+C vibrators (e.g.
  • Page 5 noise level pressure exceed dB(A), dependent on the surface upon which depending on the mounting surface it is mounted. As a rule, the noise level and the pressure. of the NTP 25 B (with silencer), at an hard-impacting installations operating pressure of 6 bar, lies below (without base plate), the noise level 80 dB(A).
  • Page 6: Design And Function

    3 Design and Function The vibration is generated by a freely If the device is required to produce oscillating differential pressure piston. hard impacts, either a steel plate is inserted into the base plate or the base In the basic version NTP B+C, the plate is completely removed.
  • Page 7: Safety

    4 Safety NTP vibrators operate using compressed air at a pressure of up to 6 bar. All hoses must therefore be securely connected. pressurized hose becomes loose it can cause injury. The compressed air must therefore be shut off before performing installation work. Jan.
  • Page 8: Transport And Storage

    Drive medium: Clean (5 µm filter), lubricated compressed air or lubricated nitrogen Unfiltered compressed air will lead to breakdown of the vibrators. Operating pressure: 2 bar to 6 bar The operating pressures must not be exceeded or fallen short of. Ambient temperature: Standard 5°C to 60°C The operating temperatures must not be exceeded or fallen short of.
  • Page 9: Installation

    6 Installation During installation, the safety regula- tions in chapter 4 and the safety pre- vention rules must be strictly observed! Ensure that the compressed air supply is shut off during installation or when working on the vibrator and air supply lines.
  • Page 10 The above diagram illustrates the possible applications: On vibration tables, for compaction, testing, etc. Under tables, on filters, for shaking, etc. On hoppers, for emptying, on vibrating troughs and sieves. Use lock screws and nuts and a liquid adhesive (e.g. Loctite) to prevent loosening.
  • Page 11 Air Supply Line: Air Discharge Line: The air resistance increases with the The exhaust air can be discharged length of the hose. The nominal widths through a hose. shown in the chart apply for hose In order for the piston vibrator to achieve lengths of up to 3 m.
  • Page 12: Start-Up / Operation

    Checklist for Installation Consider the expected operating temperature. Mount the unit. Secure fastening screws. Install the service unit (filter, mist lubricator, regulator, as required), valve and supply line. 7 Start-Up / Operation The start-up of the vibrators is possible „AIRPRESS 15“ oil for operating immediately after correct installation.
  • Page 13: Service, Maintenance

    When using dried compressed air and under extreme environmental conditions, installation upstream mist lubricator is compulsory. Regulation of Amplitude: Regulation of Frequency: The amplitude can be regulated by The frequency can be regulated by throttling the exhaust air (throttle fitted reducing the air pressure before it in air discharge line).
  • Page 14 Before starting inspection or service work, shut off the compressed air supply and protect it against unwanted activation! Jan. / Feb. / ... Regularly check the attachment of the vibrator, the compressed air supply and upstream service unit, as well as the silencer –...
  • Page 15: Troubleshooting

    9 Troubleshooting Fault Possible Cause Remedy Will not start Silencer Clean silencer Compressed air supply Check pressure on device! Is enough pressure available? Check valve. A 3/2 way valve is compulsory, so that the supply line to the device is vented. Cover loose An unsealed cover causes standstill Tighten screws.
  • Page 16: Appendix

    11 Appendix 11.1 Accessories The following accessories are available (upon request) for piston NTP vibrators: Description Remark Hose material and fit- For air supply and discharge, in various grades and di- tings mensions 3/2 way valves For electric, pneumatic and manual activation Throttle valves For amplitude regulation, manually adjustable or pneu- matically controllable (for remote control)
