Disassembling and assembling PAHT and PAHT G 256-308

7. Mount the three screws as shown above.

Tighten them to a torque of 30 Nm ± 3 Nm.

9. Bleed the pump.

180R9268 / 521B1236 / DKCFN.PI.011.B3.02 / 01.2015

8. Remove the guide bolt. Mount the three

screws. Tighten them to a torque of

30 Nm ± 3 Nm.

Connect the pump to the rest of the

system.
