Instruction

Disassembling and assembling PAHT and PAHT G 256-308

11. WARNING:

Ensure that the piston shoes and the

piston surfaces are not damaged during

removal. It is recommended to place the

pistons upside down on an even and

clean base/surface.

13. Inspect the piston liners. Replace any worn

parts.

180R9268 / 521B1236 / DKCFN.PI.011.B3.02 / 01.2015

12. Remove the retainer ring by sliding it

across the stop for the retainer ball. If

necessary, tilt the flange.
