Options - Icom IC-A16E Basic Manual

Audio output power:
(At 10% distortion)
* Projections not included.
1
* Except operating frequency ±62.5 kHz in 25 kHz channel spacing.
2
* Except operating frequency ±20.825 kHz in 8.33 kHz channel spacing.
3
* Except for operating frequency ±1 MHz.
4

■ Options

D Battery packs
• BP-278/BP-279/BP-280 BATTERY PACKS
Battery pack Voltage
7.2 V 1130 mAh (minimum) 1190 mAh (typical)
BP-278
7.2 V 1485 mAh (minimum) 1570 mAh (typical)
BP-279
7.2 V 2280 mAh (minimum) 2400 mAh (typical)
BP-280
D Chargers/Adapters/DC cables
• BC-213 DESKTOP CHARGER + BC-123S AC ADAPTER
To rapidly charge a single battery pack.
• BC-214 MULTI CHARGER + BC-157S AC ADAPTER+ AD-130 CHARGER ADAPTER
To rapidly charge up to 6 battery packs.
• CP-23L CIGARETTE LIGHTER CABLE
Use when charging the battery pack from a 12 V cigarette lighter socket.
(Use with the BC-213)
• OPC-515L DC POWER CABLE
Used when charging battery packs using a 13.8 V DC power source instead of the
power adapter. (Use with the BC-213)
• OPC-656 DC POWER CABLE
Use with a 13.8 V power source instead of the power adapter. (Use with the BC-214)
D Others
• FA-B02AR ANTENNA
• OPC-2401 HEADSET ADAPTER
To connect a wired headset to the transceiver.
• HM-240 SPEAKER MICROPHONE
• MB-130 CHARGER BRACKET
Mounts the BC-213 desktop charger on a variety of places in a vehicle.
• MB-133 BELT CLIP
• MB-96F/MB-96FL/MB-96N BELT HANGERS
• VS-3 Bluetooth HEADSET
®
The Bluetooth headset with a [PTT] switch.
About the third party Bluetooth headsets:
Icom has checked the PTT operation with some 3M Peltor headsets, such as the WS Headset
XP, WS ProTac XP and WS Alert XP. (Compatibility not guaranteed.)
Some options may not be available in some countries. Ask your dealer for details.
All options and those specifications are subject to change without notice or obligation.
See the FULL MANUAL for the latest informations, if necessary. You can download the FULL
MANUAL from the Icom website.
http://www.icom.co.jp/world/support/download/manual
SPECIFICATIONS AND OPTIONS
Int. SP 1500 mW (Typical) into an 8 Ω load
Ext. SP More than 350 mW into an 8 Ω load
