CAUTION
Displaying a still image for a long time may cause
damage to the screen, resulting in a ghost image.
Damage incurred as a result of this is not covered by
the product warranty.
Image sticking does not occur when displaying
constantly changing images but may occur when
displaying a fixed image for an extended period of
time. Therefore, it is recommended that you use
the instructions below to decrease the likelihood of
image sticking occurring when using a fixed image. It
is recommended that you change the screen at least
once every 12 hours at the minimum; if done more
frequently, the prevention of image sticking is more
effective.
Recommended operating conditions
1
Change the background and the character colors at
the same time interval.
When changing colors, using complementary colors
helps to prevent image sticking.
BM
CF
CF
TFT Layers
ITO or MoTi Pixel Layer
I D : UPM123
PW : ******
Glass
BM
BM
CF
CF
OC
PI
LC
PI
Glass
I D : UPM123
PW : ******
2
Change the image at the same time interval.
Make sure that the characters or images before
changing the image remain in the same location after
changing the image.
What is image sticking?
When the LCD panel displays a static image for
an extended period of time, it can cause a voltage
difference between the electrodes that operate the
liquid crystals. When the voltage difference between
the electrodes builds up over time, liquid crystals have a
tendency to remain aligned in one direction. During this
process, a previously displayed image remains visible.
This phenomenon is referred to as the "image sticking" .
21
