Specification - Rotabroach Element 30 Series Original Instructions Manual

Element 30 Manual

4) SPECIFICATION

Maximum hole cutting capacity in .2/.3C steel = 32mm dia. x 35mm deep
Arbor bore = 19.05mm (3/4") dia.
Motor Unit
Voltages
Normal full load
Electro Magnet
Size
Holding Force at 20°C with 25mm
minimum plate thickness
The use on any material less than 25mm thick will progressively
reduce the magnetic performance. If possible, substitute
material should be positioned under the magnet and work
piece to equate to a suitable material thickness. If this is not
possible, an alternative secure method of restraining the
machine MUST be used.
Total Load (magnet + motor)
Overall Dimensions
Height - maximum extended
Height - minimum
Width (including Capstan fitting)
Length Overall (including Guard)
Nett Weight
Vibration total values (triax vector sum) in accordance with
EN61029-1:
Level of sound pressure in accordance with EN61029-1:
Ear and eye defenders must be worn when operating this machine. Wear gloves to protect hands
when operating the machine.
These tools are UK designed and manufactured with globally sourced components and conform to the
requirements of EEC Document HD.400.1 and BS.2769/84
Suitable only for a single phase 50-60Hz A.C. power supply
Do not use your magnetic drill on the same structure when arc welding is in
D.C. current will earth back through the magnet and cause irreparable damage.
WARNING: THIS APPLIANCE MUST BE EARTHED!
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE
6
Original instructions
DO NOT USE ON D.C. SUPPLY
progress.
Dec 2014
110V 50-60Hz 230V 50-60Hz
8 A 850 W 4 A
0.6A 69W 0.3A
165mm long
80mm wide
8000N
919W
410mm
345mm
165mm
270mm
10.5kgs
Element 30/1 Element 30/3
Vibration emission value Vibration emission value
(a ):2.273m/s 2 (a
h
Uncertainty(K):1.5m/s² Uncertainty(K):1.5m/s²
Sound pressure(LpA): Sound pressure(LpA):
87.9 dB(A)
Acoustic power(LwA): Acoustic power(LwA):
100.9 dB(A)
uncertainty(K)：3dB(A) uncertainty(K)：3dB(A)
850 W
69W
919W
):1.935 m/s²
h
86.0 dB(A)
99.0 dB(A)
