Rotabroach Element 30 Series Original Instructions Manual page 16

Element 30 Manual
PARTS LIST
7.1 RD4056
7.2 RA354
7.3 RDA3016
7.4 RD4066
7.5 RDA3019
7.8 RDA3020
7.9 RDA3044
7.10 RDA4033
7.11 RD43304
7.12 RDA4037
7.13 RDA3005
7.14 RM22880
7.15 RDA4208
7.16 RDA3043
7.18 RD45614
7.19 RD43305
7.20 RD43306
7.21 RDA3041
7.22 RD43087
7.23 RDA3006
7.24 RM17134
7.25 RDA3060/1 (110V) - RDA3060/3 (230V)
7.26 RDA3068
7.27 RDA5004
7.28 RDA4032
7.29 RDA3066/1 (110V) - RDA3066/3 (230V)
9
7.30 RDA3064
7.31 RDA3067/1 (110V) - RDA 3067/3 (230V)
7.32 RDA3063
7.33 RDA4017
7.34 RDA4034
7.35 RDA5018
7.36 RD45613
7.37 RD35617
7.38 RD43118
7.39 RDA5002
7.40 RDA5003
7.41 RDA4035
16
Original instructions
Circlip
Button
Spring
Grub Screw M8 x 8
Arbor
Arbor spindle
Flat Key
Tapping Screw ST 4.8 x 40
Oil seal
Fluid elbow (black)
Gear box
Needle bearing HK071109
Gear Shaft Washer 7mm ID
Spindle Gear
Straight Pin
Roller Bearing 6003 RS
Circlip
Gear
Circlip
Gear plate
Roller Bearing 608 2RS
Armature
Bearing Sleeve
E30 baffle plate
Tapping Screw ST 4.2 x 50
Field coil
Brush cap
Carbon brush
Brush holder
Motor cable
Tapping Screw ST 2.9 x 8
Wire box cover
Screw M3 x 6 BTTN HD
Terminal
Capacitor
Motor housing
Top Cap
Tapping Screw ST 4.2 x 12
Dec 2014
1
1
1
6
1
1
1
4
2
1
1
3
1
1
1
2
1
1
1
1
2
1
1
1
2
1
2
2
2
1
4
1
4
2
1
1
1
2
