Rotabroach Element 30 Series Original Instructions Manual page 14

Element 30 Manual
PARTS LIST
1 RD43131
2 RD45607
3 RDA3032
4 RDA3031
5 RDA4201
6 RDA3029
7 RDA2002/1 (110) - RDA2002/3 (230)
8 RD45624
9 RDA3013
10 RDA3011/1 (110V) - RDA3011/3 (230V)
11 RD4078
12 RD4079
13 RD4277
14 RD4095
15 RD4098
16 RDA4005
17 RDA4021
18 RDA3001
19 RD45622
20 RDA3026
21 RD4312
22 RDA3092
23 RDA4006
24 RDA4004
25 RDA2004
26 RDA4029
27 RD33105
28 RDA3038
29 RDA3035
30 RD4092
31 RD4091
32 RDA3027
33 RDA3037
34 RDA2016
35 RDA4204
36 RDA4205
37 RDA3045
38 RDA4206
40 RDA5008
41 RD4206
42 RD4069
43 RD4068
44 RD45604
45 RDA3025
46 RDA3012
47 RD43117
48 RDA4207
49 RDA2008
50 RDA3015
51 RDA2020/1 (110V) - RDA2020/3 (230V)
52 RDA2007/1 (110V) - RDA2007/3 (230V)
53 RDA3071 (110V) - RDA3072 (230V)
54 RD4329
55 RD4088
56 RD43099
57 RD33153
58 RDA3105
59 RD4152
14
Original instructions
Screw M5 x 16 CSK HD
CSK Washer
Guard support
Slide channel
Screw M4 x 14 BTTN HD
Element 30 Guard
Motor assembly
Needle bearing HK3516
Bearing bracket
Magnet
M8 Washer
M8 Spring washer
Screw M8 x 50 CAP HD
M6 Spring washer
Screw M6 x 20 CAP HD
Cable bush
Screw M4 x 8 BTTN HD
Main Housing
Straight pin
Right side panel
Grub Screw M6 x 12
Bush
Capstan Washer
Circlip
Coolant bottle assembly
Screw M6 x 16 CAP HD
Gib Strip support
Gib strip 17.5mm
Slide
M5 Shake proof washer
Screw M5 x 22 CAP HD
Rack
Gib strip 13.5mm
Internal chain
Screw M3 x 8 CSK HD
M3 Nut
Cable chain attachment
Screw M4 x 12 CSK HD
Handle insert
Screw M6 x 40 CAP HD
M4 Washer
M4 Nut
Earth label
Left side panel
Capstan axel
Cable clamp
Screw M4 x 14 CAP HD
Capstan arm
Capstan hub
PCB assembly
Control panel assembly
Power cable
Safety belt
4mm hexagonal spanner
Chuck
Adapter
Safety Glasses
3mm hexagonal spanner
Dec 2014
2
2
1
1
2
1
1
1
1
1
2
2
2
4
4
1
17
1
2
1
5
2
2
2
1
1
1
1
1
4
4
1
1
1
8
4
2
2
1
2
1
2
1
1
1
1
2
3
1
1
1
1
1
1
1
1
1
1
