PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M10 Locknut
(62)–1
M8 x 18mm
Screw (84)–2
M10 x 15mm
Screw (67)–6
M8 Washer
(83)–2
M8 x 76mm Shoulder Screw (63)—2
M10 x 20mm
Screw (79)–3
M10 x 82mm Screw (70)–4
M4 x 12mm
Screw (77)–4
M10 x 75mm Bolt (61)–1
