Product upgrades

Upgrades
AWG5202
AWG52UP Opt SSD
AWG5200-2-2550
AWG5200-2DC
AWG5200-2AC
AWG5200-2DIGUP
AWG5200-SEQ
AWG5204
AWG52UP Opt SSD
AWG5200-4-2550
AWG5200-4DC
AWG5200-4AC
AWG5200-4DIGUP
AWG5200-SEQ
AWG5208
AWG52UP Opt SSD
AWG5200-8-2550
AWG5200-8DC
AWG5200-8AC
AWG5200-8DIGUP
AWG5200-SEQ
AWG5200 Series Installation and Safety Instructions
Option
AWG5200-825
AWG5200-850
AWG5200-8DC
AWG5200-8DIGUP
AWG5200-8AC
AWG5200-SEQ
AWG5208-ACCY01
AWG5200-SSD
Description
Provides an additional (or replacement) preprogrammed solid state drive
Increases sampling rate from 2.5 GS/s to 5 GS/s (10 GS/s interpolated)
Adds DC High Bandwidth Amplified outputs
Adds AC Amplified outputs
Adds digital up conversion (requires AWG5200-250 or AWG5200-2-2550)
Adds Sequencing
Provides an additional (or replacement) preprogrammed solid state drive
Increases sampling rate from 2.5 GS/s to 5 GS/s (10 GS/s interpolated)
Adds DC High Bandwidth Amplified outputs
Adds AC Amplified outputs
Adds digital up conversion (requires AWG5200-450 or AWG5200-4-2550)
Adds Sequencing
Provides an additional (or replacement) preprogrammed solid state drive
Increases sampling rate from 2.5 GS/s to 5 GS/s (10 GS/s interpolated)
Adds DC High Bandwidth Amplified outputs
Adds AC Amplified outputs
Adds digital up conversion (requires AWG5200-850 or AWG5200-8-2550)
Adds Sequencing
Description
16 bit, 2 GSamples/channel record length, 8-channel arbitrary waveform
generator
2.5 GS/s
5 GS/s (10 GS/s interpolated)
High Bandwidth Amplified outputs
Digital up conversion (requires AWG5200-850)
AC Amplified outputs
Sequencing
USB mouse, compact USB keyboard, touch screen stylus
Additional (or replacement) preprogrammed solid state drive
