Install the instrument

Recommended accessories

Accessory
GPIB to USB Adapter
Power Splitters
Amplifiers
Rack mount kit

Product options

Instrument
AWG5202
AWG5204
4
Enables GPIB control through USB B port
1.5 kHz - 18 GHz
DC-18 GHz
2.5 kHz - 10 GHz, 26 dB gain
0.01 - 20 GHz, 30 dB gain
Enables installation into an equipment rack
Option
AWG5200-225
AWG5200-250
AWG5200-2DC
AWG5200-2DIGUP
AWG5200-2AC
AWG5200-SEQ
AWG5202-ACCY01
AWG5200-SSD
AWG5200-425
AWG5200-450
AWG5200-4DC
AWG5200-4DIGUP
AWG5200-4AC
AWG5200-SEQ
AWG5204-ACCY01
AWG5200-SSD
Description
16 bit, 2 GSamples/channel record length, 2-channel arbitrary waveform
generator
2.5 GS/s
5 GS/s (10 GS/s interpolated)
High Bandwidth Amplified outputs
Digital up conversion (requires AWG5200-250)
AC Amplified outputs
Sequencing
USB mouse, compact USB keyboard, touch screen stylus
Additional (or replacement) preprogrammed solid state drive
16 bit, 2 GSamples/channel record length, 4-channel arbitrary waveform
generator
2.5 GS/s
5 GS/s (10 GS/s interpolated)
High Bandwidth Amplified outputs
Digital up conversion (requires AWG5200-450)
AC Amplified outputs
Sequencing
USB mouse, compact USB keyboard, touch screen stylus
Additional (or replacement) preprogrammed solid state drive
AWG5200 Series Installation and Safety Instructions
Part number
TEK-USB-488
Mini-Circuits ZX10-2-183-S
+
Picosecond Pulse Labs
5331
RF-Lambda
RAMP00G20GA
Mouser 565-72979
GF-RACK3U
