Port PRT2 Configuration
(Jumper JW2)
Publication 1746-UM004A-US-P
Table B.1 Port PRT1 Configuration
Port Configuration
PRT1 RS-232/423
RS-422
RS-485
What to Do Next: Give a copy of this worksheet to the hardware installer. Store
this worksheet with your application program for future reference.
See Figure 3.1 on page 3-1 for the locations of the four jumpers.
See Figure 3.3 on page 3-3 for jumper JW2 pin assignments and settings.
Specify the configuration of port PRT2 on your module by filling in the table
below.
Table B.2 Port PRT2 Configuration
Port Configuration
PRT2 RS-232/423
RS-422
RS-485
What to Do Next: Give a copy of this worksheet to the hardware installer. Store
this worksheet with your application program for future reference.
Selection Corresponding Jumper Position on JW1
Across pins 1 and 2, 3 and 4
Across pins 5 and 6, 7 and 8
Across pins 7 and 8, 9 and 10
Selection Corresponding Jumper Position on
JW2
Across pins 1 and 2, 3 and 4
Across pins 5 and 6, 7 and 8
Across pins 7 and 8, 9 and 10
