Compact motorized cylinder
Hide thumbs Also See for DRS2 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Compact motorized cylinder
DRS2 Series
Actuator
OPERATING MANUAL
1
Introduction ...................................2
2
Safety precautions ........................3
3
Preparation .....................................6
4
Precautions for use ........................8
5
6
7
Connection .................................. 25
Thank you for purchasing an Oriental Motor product.
This Operating Manual describes product handling procedures and safety precautions.
• Please read it thoroughly to ensure safe operation.
• Always keep the manual where it is readily available.
8
Maintenance ................................ 27
9
general specifications ................ 29
remedial action ........................... 31
HL-14082-4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRS2 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Oriental motor DRS2 Series

Summary of Contents for Oriental motor DRS2 Series

  • Page 1: Table Of Contents

    Installing the guide type ... 10 Installing the non-guide type .. 15 Connection ........25 Thank you for purchasing an Oriental Motor product. This Operating Manual describes product handling procedures and safety precautions. • Please read it thoroughly to ensure safe operation.

  • Page 2: Introduction

    Operating manuals for the DRS2 Series are listed below. With respect to the operating manual that does not supplied with the product, contact your nearest Oriental Motor sales office or download from Oriental Motor Website Download Page. Type of operating manual...

  • Page 3: Safety Precautions

    Safety precautions The precautions described below are intended to prevent danger or injury to the user and other personnel through safe, correct use of the product. Use the product only after carefully reading and fully understanding these instructions. It is prohibited to start operating the actuator (i.e., to operate the device in accordance with the specified purpose) when the machine in which the actuator is incorporated does not satisfy any relevant safety standards.
  • Page 4 • Do not use the product in explosive or corrosive environments, in the presence of flammable gases, locations subjected to splashing water, or near combustibles. Doing so may result in fire, electric shock or injury. • Do not transport, install the product, perform connections or inspections when the power is on.
  • Page 5 • Provide an emergency stop device or emergency stop circuit externally so that the entire equipment will operate safely in the event of a system failure or malfunction. Failure to do so may result in injury. • When the driver was replaced, set parameters such as the resolution, moving direction and others before operating the actuator.

  • Page 6: Preparation

    Verify the model number of the purchased product against the model number shown on the nameplate. DRSM 42 R G - 04 A 2 AZ M K Series name DRSM: DRS2 Series Frame size 42: 42 mm (1.65 in.) 60: 60 mm (2.36 in.) R: Right direction L: Left direction...
  • Page 7 Names of parts The moving part of the actuator is shown in gray color. „ Guide type Do not remove the joint from the ball screw shaft. Doing so may deteriorate the installation accuracy of the ball screw shaft, resulting in malfunction. In addition, if the joint is removed, the home position which has been set in the encoder (ABZO sensor) at the time of shipment may deviate.

  • Page 8: Precautions For Use

    Precautions for use This section covers limitations and requirements the user should consider when using the product. z General • Always use an accessory cable to connect the actuator and driver. • Be sure to provide an anti-spin mechanism for the non-guide type actuator. The actuator cannot be operated without the anti-spin mechanism because the ball screw rotates idly.
  • Page 9 z Temperature • In order to protect the encoder (ABZO sensor), use the actuator so that the surface temperature on the motor case does not exceed 80 °C (176 °F). If the surface temperature on the motor case may exceed 80 °C (176 °F), improve the operating conditions such as ambient temperature, operating speed, duty cycle and others.

  • Page 10: Installing The Guide Type

    Installing the guide type This section explains the installation location, installation method and load mounting method of the guide type actuator. Installation location The actuator has been designed and manufactured to be incorporated in general industrial equipment. Install the product in a well-ventilated location that provides easy access for inspection.
  • Page 11 „ Details of actuator mounting hole • Screw size: M4 • Tightening torque: 1.8 N·m (250 oz-in) Unit: mm „ Component part design The following shows the recommended design dimension of component part required for when the actuator is installed. z Mounting plate Perform machining for a through hole of 31±0.1...
  • Page 12 Installation using an accessory mounting plate The accessory mounting plate is a dedicated bracket (steel) to install the actuator onto a base plate. Screws to secure the actuator to the mounting plate are provided (M4, 4 pieces). „ Securing the actuator Secure the actuator to the mounting plate using the supplied screws (M4, 4 pieces).
  • Page 13 How to install a load Install a load to the load mounting holes in the joint using screws (not supplied). There are two load mounting surfaces, which are provided on the linear guide side and the ball-screw shaft side. „ When using load mounting holes in the linear guide side of the joint •...
  • Page 14 • Although the guide type actuator can receive a load moment, use it less than the specifications. Operating the actuator under an excessive load moment may cause malfunction or shorter service life of the actuator. Check on the Oriental Motor Website for the product specifications.

  • Page 15: Installing The Non-Guide Type

    Installing the non-guide type This section explains the installation location and installation method of the non-guide type actuator. Installation location The actuator has been designed and manufactured to be incorporated in general industrial equipment. Install the product in a well-ventilated location that provides easy access for inspection.
  • Page 16 Installation overview The non-guide type actuator cannot be operated without an anti-spin mechanism for the ball screw shaft because the shaft rotates idly. Be sure to provide an anti-spin mechanism such as a guide rail or a movable plate. Mounting plate Movable plate Anti-spin Guide block...
  • Page 17 „ Process of installation Install the non-guide type actuator according to the following process. Designing the parts ( p.18)  Installing the actuator ( p.20) Step1 Installing the positioning pin ( p.20)  Step2 Installing the guide rail ( p.20) ...
  • Page 18 Installation method The actuator can be installed in any direction. Install the actuator onto an appropriate metal flat mounting plate [thickness approximately 5 mm (0.2 in.) or more] having excellent vibration resistance and heat conductivity. If a high accuracy is required, design the thickness of the mounting plate in consideration of installation conditions such as load condition, rigidity, vibration, and others.
  • Page 19 z Mounting plate Perform machining of a flange pilot (counterbore or through hole) on the mounting plate. Design the flange pilot according to the centering shaft (jig) if the accuracy of component parts is not enough to perform centering. The figure shows an example for a through hole. Flange pilot section 0.02 (0.0008) 0.01 (0.0004)
  • Page 20 „ Installation procedure The installation procedure varies based on the accuracy of component parts of equipment. • If the accuracy of component parts enables centering without adjustment: Centering does not required. • If the accuracy of component parts is not enough to perform centering: Perform centering using jigs.
  • Page 21 Step3 Installing the mounting plate Place the mounting plate on the pins, and secure the mounting plate to the base plate with screws. Positioning pin for mounting plate Step4 Installing the movable plate Install the movable plate to the guide block. The installation method varies depending on the accuracy of component parts.
  • Page 22 z If the accuracy of component parts is not enough to perform centering 1. Secure the centering adjustment plate to the movable plate using screws. Centering adjustment plate Movable plate 2. Secure the movable plate to the guide block using screws. Guide block 3.
  • Page 23 4. Using the centering shaft to resemble the actuator, insert the centering shaft to the mounting plate. Loosen the screws securing the centering adjustment plate, and temporarily fix the screws so as to move slightly when touching the centering adjustment plate. Centering shaft Centering adjustment plate Mounting plate...
  • Page 24 Step5 Installing the actuator 1. Secure the actuator to the mount plate using screws. Secure with the provided screws (4 pieces) when using the accessory mounting plate. Model Screw size Tightening torque DRSM42 1.8 N·m (256 oz-in) DRSM60 5 N·m (710 oz-in) 2.

  • Page 25: Connection

    Connection This chapter explains the grounding method of the actuator as well as the method to release an electromagnetic brake. Grounding the actuator Since a grounding wire is included in the "cable for motor," you can ground it only to connect with a driver.
  • Page 26 „ When grounding the actuator Protective Earth Terminal (48 VDC only): Be sure to ground the Protective Earth Terminal of the actuator. • Grounding wire: AWG18 (0.75 mm ) or more • Screw size: M4 • Tightening torque: 1.2 N·m (170 oz-in) Grounding To ground the actuator, use a round terminal, bolt and washer.

  • Page 27: Maintenance

    Maintenance This chapter explains maintenance items to operate an actuator safely and efficiently. If an abnormal condition is noted, discontinue any use and contact your nearest Oriental Motor sales office. Inspection item and timing If the actuator is operated eight hours a day, perform maintenance according to the applicable period specified in the table.
  • Page 28 „ Internal inspection Visually check the items specified in table. Even if the grease has turned brown, lubrication condition is deemed appropriate if the running surface still appears glossy. Refer to "8-2 Grease lubrication" for how to apply grease. Item Description Remedial action Are there any deposits of foreign...

  • Page 29: Standards And General Specifications

    Standards and general specifications Standards „ EU Directives z Installation conditions Overvoltage category Protection against electric shock Class I equipment Pollution degree Noise level 70 dB or less (guide type only) z EMC Directive The driver combining with the actuator is affixed the CE Marking under the EMC Directive. For details about applicable standards and others, check with the "OPERATING MANUAL Driver"...
  • Page 30 Power supply capacity Electromagnetic Input power supply Model Current capacity brake voltage Not equipped 1.72 A or more DRSM42 Equipped 1.80 A or more 24 VDC±5% * 48 VDC±5% Not equipped 2.45 A or more DRSM60 Equipped 2.7 A or more * If the distance between the electromagnetic brake type actuator and the driver is extended to 20 m (65.6 ft.) using an accessory cable, use the power supply of 24 VDC±4%.

  • Page 31: 10 Troubleshooting And Remedial Action

    During actuator operation, the actuator may fail to function properly due to an improper setting or wiring. When the actuator cannot be operated properly, refer to the contents provided in this section and take an appropriate action. If the problem persists, contact your nearest Oriental Motor sales office. Phenomenon Possible cause...
  • Page 32 Oriental Motor branch or sales office. • Oriental Motor shall not be liable whatsoever for any problems relating to industrial property rights arising from use of any information, circuit, equipment or device provided or referenced in this manual.
