Summary of Contents for Hewlett Packard Enterprise StoreEasy 1X60
- Page 1 HPE StoreEasy 1X60 Storage Getting Started Guide Abstract This document contains setup, installation, and configuration information for the HPE StoreEasy 1x60 Storage systems. Part Number: P05626-001a Edition: 2...
- Page 2 Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
-
Page 3: Table Of Contents
Dual domain cabling diagrams with D6000 Disk Enclosures .............14 Dual domain cabling diagrams with D2000/D3000 Disk Enclosures ......... 15 Specifications and requirements............20 Websites....................22 Support and other resources...............23 Accessing Hewlett Packard Enterprise Support................. 23 Accessing updates........................23 Customer self repair........................24 Remote support.......................... 24 Warranty information........................24 Regulatory information........................25... -
Page 4: Overview
Hewlett Packard Enterprise and Microsoft management integration, including Microsoft Server Manager and System Center and Systems Insight Manager and Integrated Lights Out (iLO). The StoreEasy 1X60 Storage systems are based on the ProLiant server. The table identifies the ProLiant model for each StoreEasy 1X60 Storage product:... -
Page 5: Setup And Install
Setup and install Specific details about installing the StoreEasy platform are in the Getting Started Guide for the applicable server. Product SKU Product model Hardware platform Q2R92A HPE StoreEasy 1460 8TB SATA HPE ProLiant DL360 Gen10 Storage server Q2R93A HPE StoreEasy 1460 16TB SATA HPE ProLiant DL360 Gen10 Storage server... -
Page 6: D6000 Disk Enclosure
The following are the types of cables that you can use with the D3000 disk enclosures: • External 0.5m (1ft) Mini SAS HD 4x to Mini SAS HD 4x Cable • External 1.0m (3ft) Mini SAS HD 4x to Mini SAS HD 4x Cable •... -
Page 7: Single Domain Cabling Diagrams With D6000 Disk Enclosures
Single domain cabling diagrams with D6000 Disk Enclosures The following diagrams show different StoreEasy systems in a single domain configuration with D6000 disk enclosures. NOTE: The following diagram illustrates the cabling for StoreEasy 1X60 using the P822 controller. Single domain cabling diagrams with D6000 Disk Enclosures... - Page 8 Figure 1: StoreEasy 1x60 with the P822 controller 1. D6000 disk enclosure 1 2. D6000 disk enclosure 2 3. Connection between the P822 controller and SAS port 1 on the primary I/O module (Drawer 2) of D6000 disk enclosure 1 4.
-
Page 9: Single Domain Cabling Diagrams With D2000 Disk Enclosures
The following diagrams show different StoreEasy systems in single domain configurations with the D2000 Disk Enclosure. With these cabling diagrams, SAS daisy chains are used to connect the disk enclosures together. Figure 2: StoreEasy 1x60 with the P222 controller 1. D2600 disk enclosure 1 2. D2600 disk enclosure 2 3. - Page 10 8. Connection from port 1 of I/O module A on disk enclosure 3 to port 2 of I/O module A on disk enclosure 2 9. Connection from port 1 of I/O module A on disk enclosure 2 to port 2 of I/O module A on disk enclosure 1 Setup and install...
-
Page 11: D2600 Disk Enclosure
Figure 3: StoreEasy 1x60 with the P822 controller 1. Group 1 of 4 D2600 disk enclosures 2. Group 2 of 4 D2600 disk enclosures Table Continued Setup and install... - Page 12 3. Connection from P822 controller to port 2 of I/O module A on the top disk enclosure in Group 1 4. P822 controller 5. Connection from P822 controller to port 2 of I/O module A on the top disk enclosure in Group 2 6.
-
Page 13: D2600 Disk Enclosure
Figure 4: Alternate single domain configuration for better fault tolerance 1. Group 1 of 2 D2600 disk enclosures 2. Group 2 of 2 D2600 disk enclosures Table Continued Setup and install... -
Page 14: Dual Domain Cabling Diagrams With D6000 Disk Enclosures
3. Group 3 of 2 D2600 disk enclosures 4. Group 4 of 2 D2600 disk enclosures 5. Connection from P822 controller to port 2 of I/O module A on the top disk enclosure in Group 1 6. P822 controller 7. Connection from P822 controller to port 2 of I/O module A on the top disk enclosure in Group 4 8. -
Page 15: Dual Domain Cabling Diagrams With D2000/D3000 Disk Enclosures
1. D6000 disk enclosure 2. Connection between the P822 and SAS port 1 on the secondary I/O module (Drawer 2) 3. P822 controller 4. Connection between the P822 and SAS port 1 on the primary I/O module (Drawer 2) 5. Connection between the P822 and SAS port 1 on the primary I/O module (Drawer 1) 6. - Page 16 Figure 6: StoreEasy 1660 with the P822 controller in a dual domain configuration (best fault tolerance) 1. Group 1 of 4 D2600 disk enclosures 2. Group 2 of 4 D2600 disk enclosures Table Continued Setup and install...
- Page 17 3. Connection from the P822 controller to port 1 of I/O module B on the bottom D2600 in Group 1 4. P822 controller 5. Connection from the P822 controller to port 1 of I/O module B on the bottom D2600 in Group 2 6.
- Page 18 Figure 7: StoreEasy 1860 with the P822 controller in a dual domain configuration (best performance) Setup and install...
- Page 19 1. Group 1 of 4 D2600 disk enclosures 2. Group 2 of 4 D2600 disk enclosures 3. Connection from the P822 controller to port 2 of I/O module B on the top D2600 in Group 1 4. P822 controller 5. Connection from the P822 controller to port 2 of I/O module A on the top D2600 in Group 1 6.
-
Page 20: Specifications And Requirements
Specifications and requirements Table 3: StoreEasy 1460 Storage Dimension (H x W x D) 8 SFF - 1.69 x 17.11 x 23.92 inches (4.29 x 43.46 x 60.76 cm) 4 LFF - 1.7 x 17.1 x 23.9 inches (4.29 x 43.46 x 60.76 cm) Weight (approximate) Maximum (all hard drives, power 33.04 Ib (15kg) - Page 21 Input Requirements (per power 100 to 120 VAC, Rated Line Voltage supply) Rated Input Current For 350W & 550W Power Supply: 8A (at 100~240 VAC) Rated Input Frequency 50 to 60 Hz Rated Input Power For 550W Power Supply: 639W (at 100 VAC), 605W (at 200 VAC) For 350W Power Supply: 427W (at 100 VAC), 427W (at 200 VAC)
-
Page 22: Websites
Websites General websites Hewlett Packard Enterprise Information Library www.hpe.com/info/EIL Single Point of Connectivity Knowledge (SPOCK) Storage compatibility matrix www.hpe.com/storage/spock Storage white papers and analyst reports www.hpe.com/storage/whitepapers For additional websites, see Support and other resources. Websites... -
Page 23: Support And Other Resources
Accessing Hewlett Packard Enterprise Support • For live assistance, go to the Contact Hewlett Packard Enterprise Worldwide website: http://www.hpe.com/assistance • To access documentation and support services, go to the Hewlett Packard Enterprise Support Center website: http://www.hpe.com/support/hpesc Information to collect •... -
Page 24: Customer Self Repair
Customer self repair Hewlett Packard Enterprise customer self repair (CSR) programs allow you to repair your product. If a CSR part needs to be replaced, it will be shipped directly to you so that you can install it at your convenience. -
Page 25: Regulatory Information
Documentation feedback Hewlett Packard Enterprise is committed to providing documentation that meets your needs. To help us improve the documentation, send any errors, suggestions, or comments to Documentation Feedback (docsfeedback@hpe.com). When submitting your feedback, include the document title, part number, edition, and publication date located on the front cover of the document.
