Product Specifications

Item
Frequency 5.10~5.90 (GHz)
Modulation mode OFDM
20MHz
Channel bandwidth
HDMI protocol HDMI 1.4,HDCP 1.2
Power consumption 5.5W
System Latency 70ms
Antenna mode
2T2R
Transmission range
800ft
Operating voltage DC (7~36V) Battery: SONY NP-F970 or compatible series
Dimensions 100 x 68 x 22.5 (mm)
Video Formats
1080p, 1080i, 720p
Supported
Audio Formats
PCM
Supported
Temperature
0-50℃ (Operating)
* The Company continues to improve product performance.
Design and specifications are subject to change without prior notice.
15
7072 3072
4.8W
-40℃ - 80℃ (Storage)
Troubleshooting
Issue
Troubles & Possible Reasons
The transmitter is not powered.
The transmitter or receiver is not
placed upright.
The distance between the receiver
and the transmitter is too far.
The receiver and transmitter are
separated by multiple solid walls.
connecting
There are too many obstacles between
to
the receiver and the transmitter.
transmitter
Receiver and transmitter are not paired
There are other transmitters
working near the receiver.
Different operating modes
Different operating frequency channel.
The transmitter and player are
not connected.
The player is not turned on.
The player has not switched to the
HDMI output.
Link up with
transmitter
The transmitter's HDMI cable is
not well connected.
Please check
video soucre
The transmitter is working abnormally.
There is a problem with the HDMI cable
between the transmitter and the player.
The current player's output resolution
is not supported.
Receiver power is not turned on.
The receiver is not connected to the TV.
TV has
TV does not switch to HDMI input.
no signal
The HDMI cable of the receiver or
input
TV is not in good contact.
The TV goes into standby.
The receiver is working abnormally.
The HDMI cable of the receiver or
TV has blank
TV is not in good contact.
screen
The receiver is working abnormally.
without
any display
Receiver failure
The HDMI cable of the receiver or
TV is not in good contact.
TV screen
The HDMI cable of the transmitter or
color is
player is not in good contact.
abnormal
The transmitter or receiver is
working abnormally.
Solution
Turn on the transmitter power.
Insert the transmitter or receiver
into the base and keep it upright.
Move the receiver to a position closer
to the transmitter.
Reduce the number of solid walls between
the receiver and the transmitter.
Move the receiver to a position closer
to the transmitter.
Please re-pair the code.
Turn off other unrelated transmitters or
place the receiver away from other
sources of interference.
Set the transmitter and receiver to the same mode.
Set the transmitter and receiver to the
same frequency channel.
Connect the transmitter to the player via
the HDMI cable.
Turn on the power of the player.
Switch the player to the HDMI output.
Please re-plug the HDMI cable of the transmitter.
Restart the transmitter power.
Replace the HDMI cable.
Switch the player output resolution to
another mode.
Turn on the receiver.
Connect the receiver to the TV via an HDMI cable.
Switch the TV to the HDMI input.
Re-plug the HDMI cable of the receiver or TV.
Switch the TV to normal operation.
Restart the receiver power.
Re-plug the HDMI cable of the receiver or TV.
Restart the receiver power.
Please contact your dealer.
Re-plug the HDMI cable of the receiver or TV.
Re-plug the HDMI cable of the transmitter or player.
Restart the transmitter and receiver power.
