4
Range
Channel
500m
Ultra Low
Video
Latency
5GHz
Frequency
Intercom*4
EU Environmental Protection
Waste electrical products should not
be disposed with household waste.
Please recycle where facilities exist.
Consult to your local authority or retailer
for recycling advice.
IP
Streaming
Full HD
High Definition
BeamLink-Ultimate
All-in-one Wireless Transmission
User Manual
This user manual applies to
professional products
:
Transmitter:7081
Receiver:3060+3081
CVW
User Manual V1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CVW BeamLink-Ultimate
Summary of Contents for CVW BeamLink-Ultimate
- Page 1 Range Channel 500m Ultra Low Video Streaming BeamLink-Ultimate Latency Full HD All-in-one Wireless Transmission 5GHz Frequency High Definition Intercom*4 User Manual EU Environmental Protection This user manual applies to Waste electrical products should not professional products be disposed with household waste.
-
Page 2: Table Of Contents
Contents About the User Manual Product Features Brief Introduction Packing List Machanism & Interface Wireless HD Transmitter 7081 Wireless HD Receiver 3060+3081 Product Installation Wireless HD Transmitter 7081 Wireless HD Receiver 3060+3081 Product Application OLED Display Description Functional Instructions Parameters Configuration Wireless Software Upgrade Specification Troubleshooting... -
Page 3: About The User Manual
Product Features Do not operate the product under vibration or strong magnetic fields. BeamLink-Ultimate is an upgraded version of the BeamLink Quad that adds voice intercom capabilities. It is a set of 4TX-to-1RX full-HD audio * Do not put conductive materials in the product vents. -
Page 4: Packing List
Beam-Forming Packing List Combined with 4×4 MIMO and Beam-Forming technology, this product has advantages over other WiFi products in the market in terms of transmission The following items are included in the product package distance and video resolution. Beam-Forming technology makes wireless signals more concentrated and stronger in the direction from which they are transmitted to the receiver, allowing them to transmit farther and be less susceptible to interference from other signals, thus making them more stable. - Page 5 3s receiver need to be in code matching status at the DC-IN same time for code matching. Power Switch BeamLink-Ultimate Standard and When switching to streaming mode, the word “RTSP” Press the “WPS streaming mode will be displayed on the OLED display, and the RTSP ”...
- Page 6 RX: 3060 Receiver Key Operation Operation Description Function Antenna Interface Channel number increases one cycle from Frequency Short press CH1 to CH11 when each short pressing. After channel receiver frequency switching, transmitters the “CH/WPS” switching button about 1S will automatically display the updated channel number.
- Page 7 Enter the broadcast call mode, the receiver Short press the Broadcast call speak, and all the transmitters listen. “ ALL” button BeamLink-Ultimate Intercom RX One-to one Short press one of Receiver makes a single full duplex call to the full-duplex call the 1~4”...
-
Page 8: Product Installation
1. Please install all the antennas on the transmitter and make them in a fan shape as shown in the picture. Distance>1m Distance>1m Distance>1m BeamLink-Ultimate BeamLink-Ultimate BeamLink-Ultimate BeamLink-Ultimate 3. Please connect the transmitter and camera with SDI or HDMI cable. - Page 9 B: Vertical placement Receiver Installation A: Horizontal placement 1. Please install all the antennas on the receiver, and make them in a fan shape as shown in the picture. Place the receiver at a height of around 1.5 to 2 meters above floor. install the affiliated metal stand...
-
Page 10: Product Application
4. The receiver can be powered by both the V-mount lithium battery and DC-IN port via Product Application the affiliated power adapter. If the mentioned two types of power supply are connected at the same time, the lithium battery is prioritized in power supplying, Standard mode and the battery will switch to the power adapter for power supplying automatically after the battery power is exhausted. -
Page 11: Oled Display Description
OLED Display Description Streaming mode In streaming mode, the four channel video sources are connec TX:7081 the four transmitters via HDMI or SDI cable respectively. The receiver will receive the four RTSP streamings from the four transmitters and send them to the switch console through the LAN port. You can also connect Gain mode Volume icon... - Page 12 RX:3060 Intercom Receiver:3081 Signal Icon Frequency Channel Transmitter ID Volume icon VIDEO Call status VIDEO Signal Icon Transmitter ID VIDEO Icon Content Status Video VIDEO Display the status of the corresponding Transmitter ID Numbers 1~4 transmitters respectively. When the phone is displayed, it indicates Telephone symbol that the channel voice call is connected.
-
Page 13: Functional Instructions
The DB9 header of the Tally input interface is Functional Instructions defined as follows: Tally function DB9_FEMALE Insert the Tally light into the transmitter’s Tally output interface first, then connect the switch console to the receiver’s Tally input interface, and then control the Tally light of the four transmitters through the switch console. - Page 14 Streaming Function RS232/RS422 transparent transmission When the receiver is set to streaming mode, the transmitter needs to Description: switch to streaming mode. At this time, the word “RTSP” is displayed This interface defaults to RS232 function. For RS422 function, contact the on the transmitter’s OLED display, the SDI and HDMI ports at the receiver sales staff in advance for customized information! have no video output, and the video is transmitted to the streaming media...
- Page 15 Open internet browser, and enter transmitter’s encoder or receiver’s decoder IP address in the address bar to enter the parameter settings page. All transmitter’s encoder and receiver’s decoders need to be configured one by one, please refer to the following configuration case. Transmitter Encoder Case (transmitter 2): IP ETHADDR Transmitter IP address(192.168.1.111~114).
-
Page 16: Wireless Software Upgrade
Wireless Transmission Module Upgrading First, connect the computer to the LAN port of the receiver; Then enter the device’s WiFi IP (wireless transmission module IP) in the Each transmitter has one wireless transmission module, and the software address bar to enter the login page: upgrading needs to be implemented on each transmitter. - Page 17 Product Specifications Select the “Upgrade” option in the “System” column. ITEM TX:7060 RX:3060/3081 5190 Hz(1), 5230 Hz(2), 5270 Hz(3), 5310 Hz(4), Frequency 5510 Hz(5), 5550 Hz(6), 5590 Hz(7), 5630 Hz(8), 5670 Hz(9), 5755 Hz(10), 5795 Hz(11) Antenna 4*4 MIMO 5dBi External antenna Modulation mode OFDM Transmission Power...
-
Page 18: Troubleshooting
Trouble Shooting Video Compression H.264 Format Remote control RS232/RS422 Trouble Solutions IO port signal return Support Tally signal return Lift the transmitter and receiver as high as possible, SDI in * 1; HDMI in * 1; SDI output *4; HDMI output *4; to 1.5-2m or more;... - Page 19 Precautions 1. If transmitter or/and receiver use HDMI cable:(a~f) a. Do not plug in or pull out the HDMI cable of the transmitter and receiver during normal use. b. Connect the transmitter to the video source and connect receiver to a monitor via HDMI and then power on the transmitter and receiver.
