A. SAFETY
As with all deep Fat Fryers the major safety concern associated with the Ultrafryer Par3-14 CE Gas Fryer is
burns from hot shortening. In order to prevent serious burns, good housekeeping habits are required. The floor
in front of and the area around the fryer should be kept clean and dry. Whenever anything is placed in to a fryer
vat, care should be used not to splash the hot shortening. Product should always be "PLACED" into the short-
ening, NOT THROWN. Safety goggles, neoprene insulated gloves and an apron must be worn while filtering
or boiling-out a fryer vat. Electrical controls on all Ultrafryer CE Fryers operate on 230 volts single phase elec-
trical power. No adjustments or replacement of electrical controls should ever be attempted without first dis-
connecting electrical power. The fryer should never be operated with wet hands or while standing in water. To
do so can result in serious electrical shock or death.
This appliance is for Professional use and is to be used only by Qualified Personnel
B. DESCRIPTION / SPECIFICATIONS
The Ultrafryer Gas Fryer is constructed from 16 & 18 gauge, stainless steel, and is equipped with an Ultrastat
23 Cooking Computer. In addition, the fryer is equipped with the NEWLY developed Hard Dock Filtration
System that uses a stainless steel Filter Screen. The Customer has the option of ordering a Magnepad Filter
Screen that uses a Magnesol impregnated Filter Pad or a Paper filter pad in lieu of the S/S filter screen. The
dimensions, specifications and gas ratings are as follows:
SPECIFICATION ITEM
Overall Width
Overall Depth
Work Height
Size Vat Container
Shipping Cube
Shipping Weight
Power Input
C. OPERATIONAL REQUIREMENTS
MODEL PAR-3-14HE CE OPERATIONAL REQUIREMENTS
ITEM
Shortening Capacity High Level
Shortening Capacity low Level
Gas Valve Pressure Setting
Orifice Drill Size
Inlet Gas Pressure
Energy Input
NOTE: See European Pressures, Gases and Categories Table on page 4a-4c.
GENERAL INFORMATION
14" x 14" (356 x 356 mm)
230 Volt 6 Amp 50 Hz 1 Ø
230 V 6 AMPS 50 HZ 1 Ø
Page 1
14" PAR-3-H CE
15 5/8" (397 mm)
25 1/4" (641 mm)
35 3/4" (908 mm)
9.0 FT3 (.26 M3)
215 lbs (113 kgs)
PAR-3-14HE CE
45 lbs. (22.5 liters)
35 lbs. (17.5 liters)
See Note Below
See Note Below
See Note Below
30A134
