Lumantek ez-SHV+ Operation Manual

Sdi to hdmi converter with display and scaler
Hide thumbs Also See for ez-SHV+:

Advertisement

Quick Links

Download this manual See also: Operating Manual
ez-SHV+
SDI to HDMI
Converter with
Display and Scaler
O P E R A T I O N
M A N U A L
ez- MANUAL
UPDATED SEPTEMBER. 2018

Advertisement

loading
Need help?

Need help?

Do you have a question about the ez-SHV+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lumantek ez-SHV+

Summary of Contents for Lumantek ez-SHV+

  • Page 1 ez-SHV+ SDI to HDMI Converter with Display and Scaler O P E R A T I O N M A N U A L ez- MANUAL UPDATED SEPTEMBER. 2018...

  • Page 2: Revision Number

    This document contains information that is proprietary to LUMANTEK.CO., LTD. The information in this document is believed to be accurate and reliable; however, LUMANTEK assumes no responsibility or liability for any errors or inaccuracies that may appear in this document, nor for any infringements of patents or other rights to third parties resulting from its use.

  • Page 3: Audio Out

    01. ez-SHV+ (SDI to HDMI Converter with Display and Scaler) Lumantek's ez-SHV+ is an SDI to HDMI converter with Display and Scaler. The ez-SHV+ does more than just coverting. Through its 2.7 inch TFT-LCD, it dislays the video input. The display also shows eye pattern for video quality monitoring, resolution of incoming / outgoing video, and approximate cable length relative to the quality of the video resolution and cable.
  • Page 4 02. Interface Specifications SDI OUT DC Input SDI Video loop output port DC Power Input +5V to +18V SDI IN DIP Switch SDI Video input port Resolution and other settings switch 2.7inch TFT LCD AUDIO OUT MODE Switch HDMI OUT Analog audio output port LCD Menu setting switch HDMI Video output port...
  • Page 5 02. Interface DIP Switch Settings VIDEO OUT : Video output resolution (Position 1, 2, 3, 4) - 720x480i@59.94 (DIP SW : 1111) - 720x576i@50 (DIP SW : 0111) - 1280x720p@50 (DIP SW : 1011) - 1280x720p@59.94 (DIP SW : 0011) - 1280x720p@60 (DIP SW : 1101) - 1920x1080i@50 (DIP SW : 0101) - 1920x1080i@59.94 (DIP SW : 1001)
  • Page 6 02. Interface LCD Display HDMI output resolution Output Resolution Input Resolution SDI Input resolution * Resolution configured * Shown as “Unknown” through DIP Switch where there is no input. * If input is 3G Level-B, 1080P60B will be displayed. 1080i30 1080P60 SHORT Input video...
  • Page 7 02. Interface LCD Display ① LCD Display ON/ OFF Turn off the display by pressing and holding the mode switch for less than 6 sec. Turn on the display by pressing the mode switch for less than 6 sec.
  • Page 8 02. Interface LCD Display ② SDI input eye pattern ON/ OFF Turn on the eye pattern by pressing the mode switch for less than 1 sec. Turn off the eye pattern by pressing the mode switch for less than 1 sec.
  • Page 9 02. Interface LCD Display ③ LCD monitor rotation (by 0 or 180 degrees) Rotate to 180 degrees by pressing and holding the mode switch for more than 6 sec. Rotate to 0 degrees by pressing and holding the mode switch for more than 6 sec.

  • Page 10: Product Configuration

    03. Product Configuration ez-SHV+ AC to DC adapter Adapter specifications AC in : AC100 to 240V,50/60Hz DC out : DC12V, 1A...

  • Page 11: Technical Specifications

    04. Technical Specifications ez-SHV+ Data Input Connections SDI Video Input: SD/HD/3G-SDI (BNC 75Ω) x1 Power : DC Power Input (DC Jack) x1 Video Formats: DIP Switch : (6 Pole) x1 Video In/Out Resolution, - 720x480i@59.94/60 Video Output Ratio, LCD Brightness - 720x576i@50 MODE : (Push Switch) x1 LCD ON/OFF, Menu - 1280x720p@50/59.94/60...
  • Page 12 LUMANTEK CUSTOMER SERVICES gs@lumantek.co.kr TEL(Dir) : +82-2-6947-7429 FAX: +82-2-6947-7440...
