- Page 1 EN3 : MPEG2/H.264 HD Encoder / Manual Manual ez-Caster EN3 (Encoder/ATSC Modulator) MPEG2/H.264 HD Encoder (for IP/ATSC/8VSB)
- Page 2 This publication may contain technical issues, inaccurate information or typos. These will be revised in revised edition, if there is any. No part of this publication is subject to be reproduced, stored in retrieval system, or transmitted in any forms, or any means without the prior consent by Lumantek. Trademarks...
-
Page 3: Table Of Contents
EN3 : MPEG2/H.264 HD Encoder / Manual Contents Introduction ----------------------------------------------- Specifications --------------------------------------------- Product Description ------------------------------------- 3.1. Product Parts Name 3.2. Components 3.3. Installation Precaution Product Operation --------------------------------------- 4.1. Status LED 4.2. Front Control Panel 4.2.1. Category Structure Summary 4.2.2. Setting category Summary 4.2.3. -
Page 4: Introduction
The ‘ez-Liveshow’ is a new Audio/Video system brand with AV encoding and multiplexing technology from Lumantek designed for small studio applications. EN3 is one of the ‘ez-Liveshow’ series enabling a simultaneous video/audio encoding technology and modulation in a single device once. Optimized for Korean terrestrial TV environment, supporting Mpeg-2 Video and AC3 Audio technology as well as the 8VSB modulation. -
Page 5: Specifications
EN3 : MPEG2/H.264 HD Encoder / Manual 2. System Specifications HD Encoder + 8VSB Modulator Type SD/HD-SDI, BNC 75Ω 1ea HDMI 1.4a 1ea (HDCP not supported) Component, YCbCr, 170MHz 12bit ADC, RCA 3ea Inputs Composite, CVBS, 3D Comb Filter, RCA 1ea Analog Stereo Audio (Left/Right), RCA 2ea 1920x1080 @ 60p, 59.94p Automatic Convert to interlaced format... -
Page 6: Product Description
EN3 : MPEG2/H.264 HD Encoder / Manual 3. Product Description 3.1. Product Part Name < EN3 Main frame – Front> Status Arrow Setting and Power Keys cancel button <EN3 main frame – Rear> IP Output HDMI input RF output... -
Page 7: Installation Precaution
Avoid wearing loosened clothes or accessories during installation/Operation. Avoid any unnecessary actions that may damage/harm system or personnel. Do NOT open the system unless advised by Lumantek representative. Lumantek takes no responsibility on units with broken RMA seals. Power Precautions Please check cable overload before connecting the system to the power supply. -
Page 8: Product Operation
EN3 : MPEG2/H.264 HD Encoder / Manual 4. Product Operation 4.1. Status LED Status LED- blue, geen and red, total of three colors available. Each color indicates the following status. • System Booting • Applying setting value • Changing resolution •... -
Page 9: Front Control Panel
EN3 : MPEG2/H.264 HD Encoder / Manual 4.2. Front Control Panel Control and configure system settings with LCD screen, Arrow, settings and ESC keys at Front Control Panel ** Move cursors / Change settings Settings value (Number) Increase settings value (Number) -
Page 10: Category Structure Summary
EN3 : MPEG2/H.264 HD Encoder / Manual 4.2.1. Category Structure Summary Main Menu category settings 동작 상태 메인 메뉴 서브 메뉴 항목 별 설정 Operation Status Sub- menu Press ‘Set’ to move Set 버튼 이동 (Press ‘ESC’ to move opposite (ESC 버튼으로... - Page 11 EN3 : MPEG2/H.264 HD Encoder / Manual Main Menu Sub- menu category settings Operation Status 동작 상태 메인 메뉴 서브 메뉴 항목 별 설정 (*option)
-
Page 12: Setting Category Summary
EN3 : MPEG2/H.264 HD Encoder / Manual 4.2.2. Setting Category Summary Sub Menu Setting Categories Value, range Features Location CVBS Select video input port COMPONENT (*when selected, the audio input port HDMI is automatically changed to VIDEO IN appropriate input port.) - Page 13 EN3 : MPEG2/H.264 HD Encoder / Manual Sub Menu Setting Categories Value, range Features Location Enable IP Output Enable/Disable Disable XXX.XXX.XXX.XXX Output destination IP address DSI IP ADDRESS setting 1 ~ 65535 Output destination UDP port DST UDP PORT number setting XXX.XXX.XXX.XXX...
-
Page 14: Location And Operation Description
EN3 : MPEG2/H.264 HD Encoder / Manual 4.2.3. Location and Operation Description Left: Input port 1) Operation Status Right: Version I:HDMI V:1V00C Left : Input resolution R:1080I60 C:04-001 Right : Virtual channel number F:04CH_KT 069MHz Output frequency setting status P:+00.0dBm T:045`C... - Page 15 EN3 : MPEG2/H.264 HD Encoder / Manual 2) Main Menu INPUT >> MAIN MENU << Sub menu >INPUT ENCODER ENCODER PSIP Sub menu MODULATOR IP-OUT (*Option) SYSTEM PSIP Sub menu MODULATOR Sub menu IP-OUT Sub menu (*option) SYSTEM Sub menu Setting ◀,▶...
- Page 16 EN3 : MPEG2/H.264 HD Encoder / Manual 3) INPUT Menu and Setting Categories >> INPUT << >VIDEO IN: HDMI AUDIO IN: HDMI RESOLUTION: AUTO PATTERN: BLUE Setting ◀,▶ ▲,▼ Features location INPUT Move to Move to Move to main...
- Page 17 EN3 : MPEG2/H.264 HD Encoder / Manual 4) ENCODER Sub Menu and Setting Categories >> ENCODER << >SYS DELAY : 650 ms TS ID : 00001 AUD DELAY : 0000 ms Setting ◀,▶ ▲,▼ Features location ENCODER Move to...
- Page 18 EN3 : MPEG2/H.264 HD Encoder / Manual 5) PSIP Sub Menu and Setting Categories >> PSIP << >PSIP OUT: ENABLE MAJOR CH: 04 ch MINOR CH: 001 ch NET NAME: ABC Setting ◀,▶ ▲,▼ Features location PSIP Move to...
- Page 19 EN3 : MPEG2/H.264 HD Encoder / Manual 6) MODULATOR Sub Menu and Setting Categories >> MODULATOR << >STAT: KOR-T, 04 ch SET FREQ SET FREQ BY KOR-T SET FREQ BY KOR-C POWER: 00.0 dBm Setting ◀,▶ ▲,▼ Features location...
- Page 20 EN3 : MPEG2/H.264 HD Encoder / Manual 7) IP-OUT Sub Menu & Setting Categories (*option) >> IP-OUT << >OUT: Enable DST IP ADDRESS DST UDP PORT: 01234 HOST IP ADDRESS HOST SUBNET MASK HOST GATEWAY HOST MAC ADDR DATA: Lock BTR : 19.6 Mbps...
- Page 21 EN3 : MPEG2/H.264 HD Encoder / Manual Setting ◀,▶ ▲,▼ Features location IP-OUT Move to Move to Move to category main menu selected menu category Change Apply Move to IP Output Enable/Disable selection selection menu DST IP Output destination IP address...
- Page 22 EN3 : MPEG2/H.264 HD Encoder / Manual 8) SYSTEM Sub Menu and Setting Categories >> SYSTEM << >VERSION: 1v00C LOAD DEFAULT RESET Setting ◀,▶ ▲,▼ Features location SYSTEM Move to Move to Move to category main menu selected menu...
-
Page 23: Appendix A. Pc Gui Control S/W
EN3 : MPEG2/H.264 HD Encoder / Manual Appendix A. PC GUI Control S/W A.1. Connect EN3 with PC GUI S/W PC GUI S/W is connected via USB Port. Connect with control PC via USB A.2. PC GUI S/W Driver installation and verification When PC and EN3 is connected, make sure that following driver is created PC. - Page 24 EN3 : MPEG2/H.264 HD Encoder / Manual A.3. PC GUI S/W Connection and Control Select a COM port Click ‘Connect’ which identified in Device Manager Read the Run Status monitoring value...
- Page 25 EN3 : MPEG2/H.264 HD Encoder / Manual You can change settings by clicking specific buttons.
- Page 26 EN3 : MPEG2/H.264 HD Encoder / Manual A.4. PC GUI S/W Firmware Update Click following button to open firmware update window.. Click Click ‘Open’ and choose specific file and click ‘Download’ to start the firmware update. Open file Run update...
-
Page 27: Appendix B. Frequency Table
EN3 : MPEG2/H.264 HD Encoder / Manual Appendix B. Frequency Table Korea Terrestrial Korea Cable Frequency Frequency Center Center Channel Number Range Channel Number Range Frequency (MHz) Frequency (MHz) (MHz) (MHz) 54-60 54-60 60-66 60-66 VHF LOW BAND 66-72... - Page 28 EN3 : MPEG2/H.264 HD Encoder / Manual Korea Terrestrial Korea Cable 300-306 306-312 312-318 318-324 324-330 330-336 336-342 342-348 348-354 354-360 360-366 366-372 372-378 378-384 384-390 HYPER BAND 390-396 396-402 402-408 408-414 414-420 420-426 426-432 432-438 438-444 444-450 450-456...
- Page 29 EN3 : MPEG2/H.264 HD Encoder / Manual Korea Terrestrial Korea Cable 656-662 660-666 662-668 666-672 668-674 672-678 674-680 678-684 680-686 684-690 686-692 690-696 692-698 696-702 698-704 702-708 704-710 708-714 710-716 714-720 716-722 720-726 722-728 726-732 728-734 732-738 734-740 738-744...
