- Page 1 EN8 – H.264 8CH HD Video over IP Encoder User Manual ez-Caster EN8 8CH HD Video over IP Encoder H.264 HD Encoder...
- Page 2 This publication may contain technical issues, inaccurate information or typos. These will be revised in revised edition, if there is any. No part of this publication is subject to be reproduced, stored in retrieval system, or transmitted in any forms, or any means without the prior consent by Lumantek. Trademarks...
- Page 3 Avoid wearing loosened clothes or accessories during installation/Operation. Avoid any unnecessary actions that may damage/harm system or personnel. Do NOT open the system unless advised by Lumantek representative. Lumantek takes no responsibility on units with broken RMA seals. Power Precautions Please check cable overload before connecting the system to the power supply.
-
Page 4: Table Of Contents
EN8 – H.264 8CH HD Encoder / Manual Contents 1. Introduction ---------------------- 2. Specification --------------------- 3. Product Description ---------------- 3.1. Product Parts Name 3.2. Components 4. Product Operation ------------------ 4.1. Status LED 4.2. NMS Control Appendix #1 : Input and Output Resolutions --- Appendix #2 : GOP Structure -------------- Appendix #3 : Audio codec &... -
Page 5: Introduction
EN8 – 8CH H.264 Video-IP Encoder H.264 8CH HD Encoder 1. Introduction ez-Caster EN8 is 8 channels H.264 HD Encoder. It consists of HDMI inputs and IP output. it supports H.264 Video compression and MPEG-1 Layer2, MPEG-2 AAC,MPEG-4 AAC for Audio compression. -
Page 6: Specification
EN8 – H.264 8CH HD Encoder / Manual 2. System Specification System Delay TS MUX/ Normal mode : 150ms + (300ms/500ms/1000ms) System Low latency mode : 120ms TS Bit-rate : 4 ~ 20 Mbps Support Input Resolutions - 1920x1080@60i/59i/50i/30p/29p/25p/24p/23p - 1280x720@60p/59p/50p - 720x480@60i/59i - 720x576@50i Automatic Resolution Detection... -
Page 7: Product Description
③ ALARM LED : light up when problem occurs. ④ NMS : LAN port for device control (10BaseT/100BaseTX half/full duplex). ⑤ SERVICE : Port for firmware update (USB2.0). ⑥ PWR LED : POWER LED(PWR A/PWR B). < ez-Caster EN8 Main frame – Rear > ① ② ③... -
Page 8: Components
EN8 – H.264 8CH HD Encoder / Manual 3.2. Components This product is composed of followings ① ez-Caster EN8 Main Frame. ② AC Power Cord : 220V AC Power Cord. ez-Caster EN8 Main Frame AC power cord... -
Page 9: Product Operation
EN8 – H.264 8CH HD Encoder / Manual 4. Product Operation 4.1. Status LED Normal, Status LED is GREEN and RED indicate Alarm. CH 1/2 LED - indicates LAN active Status of CH1 and CH2. CH 3/4 LED - indicates LAN active Status of CH3 and CH4. CH 5/6 LED - indicates LAN active Status of CH5 and CH6. -
Page 10: Nms Control
EN8 – H.264 8CH HD Encoder / Manual 4.2. NMS control Execute NMS software to connect the device and change the setting. (Further information and operation will be added later) 1) UI Description ① Device selection, using ”+” user can add device.. ②... - Page 11 EN8 – H.264 8CH HD Encoder / Manual 2) NMS Connection • COM port(USB) connection ① Connect PC and EN8 by USB cable ② On Connection Tab click COM(A). ③ Chose available Com port from drop box (B). ④ Click Connect(C). ※When user connecting to EN8 for the first time, user may need to to set NMS IP.
- Page 12 EN8 – H.264 8CH HD Encoder / Manual 3) EN8 IP Setting • EN8 IP setting ① NMS Setting : EN8 NMS socket setting for Window NMS Program Press “Setting” Button in the NMS Setting section. Enter setting value of EN8 NMS socket and press “Apply”.
- Page 13 EN8 – H.264 8CH HD Encoder / Manual ※ Setting for Port each channel. • (A) Above IP Address were already set in previous “Host setting” therefore it can not be change in this section. • (B) Source port for each channel. ※...
- Page 14 EN8 – H.264 8CH HD Encoder / Manual Enter Destination IP Address and Port and then press “Apply”. ※ Make sure that Destination IP address or port are different for each channels. - Need to set the IP differently, or set the Port for a different value.
- Page 15 EN8 – H.264 8CH HD Encoder / Manual B) Output Resolution Setting - Clicking on “Output Resolution” drop box, it will display list of the resolutions that can be output from the detected input. (refer to Appendix - If user do not specified the output resolution, the output resolution will follow default resolution. The default values are set according to the following rules: a.
- Page 16 EN8 – H.264 8CH HD Encoder / Manual C) Bit-rate Setting A: Entire bit-rate of TS B: Video rate(ES standard ) C: Audio rate(ES standard) - Please refer to Appendix C for configurable Audio codec. ※ A > B + C must be satisfied, B and C are ES standard whereas A is TS standard. Therefore A should be set a little bit more value for the margin.
- Page 17 EN8 – H.264 8CH HD Encoder / Manual D) Encoder Mode Setting Set the delay mode between the Encoder input and output. - Normal mode: default mode, Delay is controlled by CPB Delay(Refer to CPB Delay Setting). - Low Delay Mode: there are few constrains but this mode is minimum latency.
- Page 18 EN8 – H.264 8CH HD Encoder / Manual - GOP Size value should be set between 6~63. - When GOP Adaptive value is 0 If GOP Structure is IBBP or IPPP then the GOP Size should be a multiple of 3. If GOP Structure is IBP, then the GOP Size should be a multiple of 2.
-
Page 19: Appendix #1 : Input And Output Resolutions
EN8 – H.264 8CH HD Encoder / Manual APPENDIX #A. Supported input and output resolutions 59.94, 29 => 29.97, 23 => 23.98... -
Page 20: Appendix #2 : Gop Structure
EN8 – H.264 8CH HD Encoder / Manual #B. GOP Structure - Frame Type I-Frame - Construction of a single complete image without using prediction. - The best quality picture, but the largest capacity (file size). P-Frame - Use Forward Prediction. - Contains the data of the part where the change occurred in previous I- frame or P-frame.
