- Page 1 ez-MD+ HDMI/SDI Cross Converter with Audio Mux/Demux Operation manual MANUAL UPDATED NOVEMBER. 2018...
-
Page 3: Revision Number
Lumantek’s products comes with One(1) year limited warranty. Please contact below if you need more information. HDCP Protection LUMANTEK products comply with HDCP, thus we will not allow any HDCP connection. If the input video source is protected by HDCP, then no video source will be displayed through LUMANTEK products. -
Page 5: Audio Out
01. Introduction Lumantek’s ez-MD+ is a cross-converter supporting both SDI and HDMI as inputs and outputs. It has many functionalities other than converting like audio mux and demux through XLR, reference in (genlock), scaler, and audio delay control. Features ① Inputs & outputs... - Page 6 02. Interface a. Specifications [Top] Ref Reference input signal Link LED - Free Running Mode : LED off - Input Lock Mode : Lock/LED on, Unlock/LED blink - Genlock Mode : Lock/LED on, Unlock/LED blink DC Input SDI IN REF IN Link DC Power Input SDI Video...
- Page 7 02. Interface a. Specifications [Bottom] Mode Mode setting DIP Switch 10 Position Audio Delay Audio Delay setting Rotary Switch 10 Position...
-
Page 8: Mode Settings
02. Interface b. MODE Settings VIDEO OUT : Video output resolution (Position 1, 2, 3, 4) - 720x480i@59.94 (DIP SW : 1111) - 720x576i@50 (DIP SW : 0111) - 1280x720p@50 (DIP SW : 1011) - 1280x720p@59.94 (DIP SW : 0011) - 1280x720p@60 (DIP SW : 1101) - 1920x1080i@50 (DIP SW : 0101) - 1920x1080i@59.94 (DIP SW : 1001) -
Page 9: Audio Gain
02. Interface b. MODE Settings RATIO : Video output screen ratio(Position 5) - FULL 16:9 (DIP SW : 1) - Latter 4:3 or Pillar Box (DIP SW : 0) VIDEO IN : Video input selection (Position 6) - SDI input mode (DIP SW : 1) - HDMI input mode (DIP SW : 0) AUDIO IN : Audio input selection (Position 7) - Internal audio input mode (DIP SW : 1) - Page 10 02. Interface b. MODE Settings GENLOCK Mode SDI IN SDI OUT RX Block Scaler TX Block HDMI IN HDMI OUT REF IN INT. SYNC Compatible REF Input signals Output resolution REF IN resolution 720x480i59.94 NTSC 720x576i50 1280x720p50 PAL, 720p50, 1080p50 1280x720p59.94 NTSC, 720p59.94, 1080p59 1280x720p60...
- Page 11 02. Interface b. MODE Settings Free Running Mode SDI IN SDI OUT RX Block Scaler TX Block HDMI IN HDMI OUT REF IN INT. SYNC Input Lock Mode SDI IN SDI OUT RX Block Scaler TX Block HDMI IN HDMI OUT REF IN INT.
-
Page 12: Audio Delay Settings
02. Interface c. AUDIO DELAY Settings Rotary Switch AUDIO DELAY min. 50ms Step 0ms Delay (Position : 0) 50ms Delay (Position : 1) 100ms Delay (Position : 2) 150ms Delay (Position : 3) 200ms Delay (Position : 4) 250ms Delay (Position : 5) 300ms Delay (Position : 6) 350ms Delay (Position : 7) 400ms Delay (Position : 8) -
Page 13: Product Configuration
03. Product Configuration AC to DC adapter ez-MD+ Adapter specifications AC in : AC100 to 240V,50/60Hz External audio gender cable DC out : DC12V, 1A Cable specifications d’ sub 9PIN (Male) x 1 Audio Input : XLR(Female) x 2 Audio Output : XLR(Male) x 2... - Page 14 03. Product Configuration d’ sub 9PIN RIGHT 1 (-) RIGHT 1 (+) LEFT 1 (-) LEFT 1 (+) RIGHT 2 (-) RIGHT 2 (+) LEFT 2 (-) LEFT 2 (+) Audio Input : XLR(Female) x 2 Audio Output : XLR(Male) x 2 LEFT 2 (XLR FEMALE) LEFT 2 (XLR FEMALE) INPUT...
-
Page 15: Technical Specifications
04. Technical Specifications ez-MD+ Data Input Connections SDI Video Input: SD/HD/3G-SDI (BNC 75Ω) x1 Power : DC Power Input (DC Jack) x1 HDMI Video Input: SD/HD/3G (HDMI Type A) x1 Update : Debug (Micro-USB) x1 Reference Input: B.B , TRI (BNC 75Ω) x1 DIP Switch : (10 Pole) x1 Audio Input: D-SUB 9PIN (Female) x1 Video Output Resolution, Video Output Ratio, Video... - Page 16 EASY FOR EVERYONE. FULL HD SWITCHER 4 Channel video switcher Internal scalers (output to any HD resolution up to 1080p) Multiview and Program screens 2 x Logo Luma/Chroma 18 Transition effects! SAVE YOUR LIVE EVENT! ez-SHV+ SDI TO HDMI CONVERTER WITH DISPLAY AND SCALER Display Monitoring Eye Pattern...
