Brightness

Turning
pressing the adjacent Shift button allows you to
adjust the brightness of the Sentry
Turn the control anti-clockwise to decrease the
brightness. Turn the circular control clockwise
to increase the brightness.
Activating line markers / window blinds
Pressing this button cycles you through line markers,
window blinds and back to full screen. Horizontal line
markers and window blinds are used to make reading
easier.
Reading line and window shades adjustment
When line markers or window blinds are activated,
turning this circular control will change their orientation.

Reading line colours

By pressing the Shift key along with the Semi-
colours button you can change the reading line
colours. The photo mode can be change
separately. Black is the factory setting.

Key switch

This key enables additional functions. Pressing and
holding this key while rotating the upper adjustment
button allows you to change additional functions such as
line distance, window shade distance and changes in
brightness.

Picture switch

By pressing this button you can switch between the
image from the Sentry
If you have a footswitch available, you can control
switching the image by pressing the footswitch.

Reset

Press this button when the Sentry
Switch the Sentry
and keep the button pressed for 2 seconds. The Sentry
[HD] will now start with the original settings.
the button whilst
+
[HD] camera and the PC image.
+
+
[HD] on while pressing this button
+ +
Sentry / Sentry
simultaneously
+
[HD] image.
[HD] is switched off.
Page 15
