4. Getting to know your Sentry
Setting up your Sentry
To set up the Sentry
1. Assemble the base plate and the camera arm by using the bolt
and screw provided.
2. Place the assembled unit and the control panel nearby your
monitor on a steady surface.
3. Connect the cable of the Sentry
connection at the rear of the control panel (look at the picture on
page 11).
English
+
[HD]
+
[HD] please follow the steps described below:
Sentry
+
[HD]
+
[HD] camera arm to the camera
+ +
/ Sentry HD
