5. Operation of the Sentry
Switch On / Off
Press the On / Off switch, located at the top right Corner of the
control panel to switch on the Sentry
indicator light will illuminate when the control panel is switched
on. The monitor needs to be switched on separately.

Setting the magnification

Wide screen mode – only at Sentry
English
Turning the Zoom control allows you to select the
desired magnification level. The Sentry
text and images from 1 to 70 times the original size on a
22-inch screen. Turning the circular control anti-
clockwise will decrease the magnification. Similarly,
turning the circular control clockwise will increase the
magnification.
By pressing the Shift key along with the overview
button you can switch between three views:
Widescreen, flexible widescreen and without
widescreen. Widescreen is the factory setting.
Sentry
+
[HD] control panel
+
[HD]. The On / Off
+
+ +
/ Sentry HD
+
[HD] magnifies
Page 13
