- Page 1 Instructions for use ARCUSevo Always be on the safe side.
- Page 2 Sales: Manufacturer: KaVo Dental GmbH Kaltenbach & Voigt GmbH Bismarckring 39 Bismarckring 39 D-88400 Biberach D-88400 Biberach Tel. +49 7351 56-0 www.kavo.com Fax +49 7351 56-1488...
-
Page 3: Table Of Contents
Instructions for use ARCUSevo Contents Contents Contents ................................1 1 User instructions ............................2 1.1 User guide ...............................2 1.1.1 Abbreviations ..........................2 1.1.2 Symbols ............................2 1.1.3 Target group ........................... 2 1.2 Service ..............................3 1.3 Warranty provisions ..........................4 1.4 Transportation and storage ........................5 1.4.1 Packaging ordinance of August 28,1998 .................. -
Page 4: User Instructions
Instructions for use ARCUSevo 1 User instructions 1.1 User guide 1 User instructions 1.1 User guide Requirement Read these instructions before the initial startup to prevent misuse and damage. 1.1.1 Abbreviations Short Explanation form Instructions for use Care instructions Assembly instructions... -
Page 5: Service
Instructions for use ARCUSevo 1 User instructions 1.2 Service 1.2 Service Service hotline: +49 7351 56-1600 Service.Zahntechnik@kavo.com Please indicate the product serial number in all requests. Additional information can be obtained at: www.kavo.com 3/24... -
Page 6: Warranty Provisions
Defects or their consequences that can be attributed to interventions on or changes made to the product by the customer or a third party not authorised by KaVo are excluded from the warranty. -
Page 7: Transportation And Storage
1.4.1 Packaging ordinance of August 28,1998 Note Only applicable for the Federal Republic of Germany. KaVo transport packaging must be disposed of and recycled by local disposal ser‐ vice providers and recycling companies in accordance with Dual System require‐ ments. - Page 8 1 User instructions 1.4 Transportation and storage Outside of Germany Note KaVo is not liable for damage arising from transportation. Immediately inspect the delivery after receipt! If external damage to the packaging is visible upon delivery, follow the procedure below: 1.
-
Page 9: Storage
Instructions for use ARCUSevo 1 User instructions 1.4 Transportation and storage 1.4.3 Storage Note Keep the packaging for returning the product for service or repairs . The symbols printed on the outside are for transportation and storage, and have the... -
Page 10: Safety
Instructions for use ARCUSevo 2 Safety 2.1 Description of safety instructions 2 Safety 2.1 Description of safety instructions 2.1.1 Warning symbol Warning symbol 2.1.2 Structure The introduction describes the type and source of the hazard. This section describes the potential consequences of non-observance. -
Page 11: Proper Use
The user must ensure that that the device works properly and is in a satisfactory condition before each use. This KaVo product is intended only for use in the field of dentistry. It is impermissible to use the product for a purpose for which it was not intended. -
Page 12: Product-Specific
Please direct all questions regarding the proper disposal of KaVo products to the nearest KaVo branch. 2.2.2 Product-specific The ARCUSevo facial bow records the position of the patient's maxilla. When crea‐ ting a prosthesis, a working or tooth model can be correctly positioned in an articulator. -
Page 13: Safety
Instructions for use ARCUSevo 2 Safety 2.3 Safety 2.3 Safety 2.3.1 General information Premature weary and malfunctions from improper servicing and care. Reduced production time. ▶ Perform regular proper care and maintenance. CAUTION Injury or damage from damaged functional parts. -
Page 14: Product Description
Instructions for use ARCUSevo 3 Product description 3.1 ARCUSevo 3 Product description 3.1 ARCUSevo ① Bow ⑦ Fastening nut of the bite fork support ② Fastening nut for the earbud ⑧ Adjustment wheel for adjusting the facial width ③ Earbud ⑨... -
Page 15: Technical Data
Instructions for use ARCUSevo 3 Product description 3.2 Technical data 3.2 Technical data Dimensions and weight Max. width 345 mm Depth 300 mm Height 100 mm Weight 250 g Weight of bite fork/bite fork support 100 g Information on the planes and reference points Frankfurter horizontal ②... -
Page 16: Scope Of Delivery
Instructions for use ARCUSevo 3 Product description 3.3 Scope of delivery 3.3 Scope of delivery Figure Designation ARCUSevo facial bow incl. Earbuds Nose support Reference pointer Bite fork support Bite fork Instructions for use 14/24... -
Page 17: Operation
Instructions for use ARCUSevo 4 Operation 4.1 Adapting the facial bow 4 Operation 4.1 Adapting the facial bow ▶ Turn the adjustment wheel ③. The earbuds ② move further apart. The bow ① can be placed on the patient. 15/24... -
Page 18: Mount The Facial Bow
Instructions for use ARCUSevo 4 Operation 4.2 Mount the facial bow 4.2 Mount the facial bow The facial bow is mounted with reference to the Frankfurter horizontal and the Cam‐ per's plane. Unapproved registration materials Endangerment of the patient ▶ Only use approved registration materials according to 93/42 EEC! CAUTION The reference pointer can contact patients. - Page 19 Instructions for use ARCUSevo 4 Operation 4.2 Mount the facial bow ▶ Remove the knurled screw ②. ▶ Shove the bite fork support ③ onto the bite fork ④. ▶ Suspend the bite fork support ③ on the facial bow and tighten it with the fastening nut ①.
-
Page 20: Removing The Facial Bow
Instructions for use ARCUSevo 4 Operation 4.3 Removing the facial bow 4.3 Removing the facial bow ▶ Open the lock lever ④ of the nose support ③, push back the nose support ③ and fix. ▶ Turn the setting wheel ⑤ to remove the earbuds ② of the facial bow ① from the ears. -
Page 21: Preparation Methods Din En Iso 17664
Instructions for use ARCUSevo 5 Preparation methods DIN EN ISO 17664 5.1 Cleaning 5 Preparation methods DIN EN ISO 17664 Note All of the components that contact the patient's mucous membrane must be steri‐ lized after use. The following components must be sterilized: ▪... -
Page 22: Disinfection
Instructions for use ARCUSevo 5 Preparation methods DIN EN ISO 17664 5.2 Disinfection 5.2 Disinfection 5.2.1 Manual disinfection Allowed disinfectants ▪ Microcide liquid (Schülke & Mayr) ▶ Wipe-disinfect all components. 5.2.2 Automated disinfection Not applicable. 20/24... -
Page 23: Sterilisation
Instructions for use ARCUSevo 5 Preparation methods DIN EN ISO 17664 5.3 Sterilisation 5.3 Sterilisation ▶ Sterilise the bite fork in a fractionated initial vacuum at 134°C ± 1°C, 3.04 bar for 4 minutes (sterilisable up to max. 138°C). 21/24... -
Page 24: Accessories
Instructions for use ARCUSevo 6 Accessories 6 Accessories Designation Material number 1 pair of adjustable axial pins 1.004.7640 22/24... -
Page 25: Spare Parts Sheet
Instructions for use ARCUSevo 7 Spare parts sheet 7 Spare parts sheet Verk.-Nr. Gesichtsbogen 11/2007 ARCUSevo 09.30 1.004.7623 1.004.7637 1.001.4046 0.622.0911 0.258.6030 0.622.2852 0.258.1442 0.622.2862 0.622.2762 0.622.2872 0.622.2192 0.622.2182 0.622.0931 0.252.4020 0.622.2752 0.252.3016 0.240.2240 0.622.2772 Zubehör 1.004.7640 23/24... - Page 26 Instructions for use ARCUSevo 7 Spare parts sheet 24/24...
