Tube Assembly (Sunstar & Sovereign); Sunstar Hitch; Sovereign Hitch - Simplicity Turbo Turbo Wide Body Cart & Hitch Operator's Manual

5
4
3
2
1
Figure 2. Tube Assembly - Sunstar & Sovereign
1
10
9
8
7
Figure 3. Sunstar Hitch
Figure 4. Sovereign Hitch
7
6
3
2
2
3
1
4
5
6
11
5
Illustrations & Part Lists
No. Qty.Description
1 1 Clamp, 6"
2 1 Hose
3 4 Screw, Truss Hd. #10-32 x 1/2
4 4 Plain Washer
5 4 Hex Nut #10-32
6 1 Tube
7 1 Decal
No. Qty.Description
1 4 Capscrew, Hex Hd., 7/16-14 x 1-1/2
2 4 Lockwasher, 7/16
3 4 Nut, Hex, Full, 7/16
4 2 Nut, Hex, Full, 1/2-13
5 2 Lockwasher, 1/2
6 1 Bracket, Hitch (Frame)
7 2 Nut, Hex, Full, 5/8
8 2 Lockwasher, 5/8
9 2 Bracket, Hitch (Cart)
10 2 Capscrew, Hex Hd.,5/8-11 x 1-1/4
11 2 Capscrew, Hex, 1/2-13 x 1-1/4
No. Qty. Description
1 2 Locknut, 1/2-13
2 1 U-Bracket
3 3 Washer, Flat, 112x1 x9/64
4 1 Safety Clip
5 2 Clevis Pin, 7/16x 1-3/4
6 1 Support Bracket
7 2 Capscrew, Hex, 1/2-13x1-112
8 1 Spacer
9 2 Spring Clip
10 1 Clevis Pin, 112x718
