Connecting Cart / Maintenance

CONNECTING CART TO TRACTOR

Place the cart frame (A, Figure 28) onto tractor brackets
and install the clevis pins (B) and springs clips (C).

MAINTENANCE

Cleaning Clear Tube

To clean the clear mid-tube on the SunStar and
Sovereign series collection systems, wash with warm
water and mild soap or detergent. Use a soft, clean
sponge or cloth. DO NOT use abrasive, alkaline, or
petroleum based cleaners.

Cover

The cover can be rinsed with a hose when dirty. A dirty
cover will inhibit the fast flow of grass clippings into the
cover. Do not leave grass or leaves in the cart for a long
period of time.

Wheels

Lubricate the wheel assembly before using the cart and
as necessary thereafter. A grease fitting is located at
swivel base. Use SAE multi-purpose type grease.

Tires

The tire pressure should be 30 psi.
Figure 28. Connecting Cart To Tractor
A. Cart Frame
B. Clevis Pin
The cover is subject to wear and deterioration.
Check the cover frequently. Use an approved
replacement cover.
Before opening the cover for any reason, engage
the parking brake, shut off the engine, remove
the key, and wait for all moving parts to stop.
12
C. Spring Clip
WARNING
WARNING
