Simplicity Colt ZT2148T Parts Manual page 69

48" & 52" Mower Decks - Belts, Pulleys & Idler Arm
REF NO. PART NO.
1A 22667
1B 22148
2A 22622
* 23175
2B 22721
* 23178
3 50407-5
4 25318
5 25319
6 25056
7 25158
8 21976
9 47142
10 25017-24
11 25017-36
12 25150
13 45022
14 21541
15 3845106
16 20095
17 45023
18 21811
19 25017-28
20 3845200
21 25013-8
22 22788
23 25156
24 25096
25 25128
Footnotes:
The above parts group applies to the following Model Nos.:
ZT2148T
ZT2348T
ZT2352T
TP 400-7090-06-CT-D
QTY. DESCRIPTION
1 BELT (48" Deck)
1 BELT (52" Deck)
3 PULLEY, Spindle, Gold (48" Deck, S/N: 533 & below)
3 PULLEY, Spindle, Black (48" Deck, S/N: 534 & above)
3 PULLEY, Spindle, Gold (52" Deck, S/N: 585 & below)
3 PULLEY, Spindle, Black (52" Deck, S/N: 586 & above)
3 KEY, 1/4" x 1-1/4"
3 WASHER, Spring
3 NUT, Hex, Nylon Lock, 5/8-18
4 NUT, Hex, Nylon Lock, 1/2-13
3 WASHER, 1/2
3 PULLEY, Idler
2 SPACER, .52 x 1.25 x .70
2 CAPSCREW, Hex Hd, 1/2-13 x 3
1 CAPSCREW, Hex Hd, 1/2-13 x 4-1/2
2 WASHER, USS, 1/2
1 IDLER ARM PIVOT SHAFT
2 BUSHING, Flange
1 IDLER ARM
1 GREASE FITTING
3 SPACER, .52 x 1.00 x .44
1 EYEBOLT
1 CAPSCREW, Hex Hd, 1/2-13 x 3-1/2
1 SPRING ANCHOR
1 CAPSCREW, Hex Hd, 3/8-16 x 1
1 SPRING, Compression, 2"
1 WASHER, 3/8
1 NUT, Hex, Nylon Lock, 3/8-16
1 NUT, Hex, Serrated Flange, 3/8-16
63
